Makita Cordless Chain Saw BUC122 Parts
€19.23
Tax included
Makita Spare parts for Cordless Chain Saw BUC122
Makita original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Cordless Chain Saw BUC122.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare parts for Cordless Chain Saw BUC122
Makita original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Cordless Chain Saw BUC122.
In the following table, look for the model of the Cordless Chain Saw and the respective parts of the code.
| MAKITA BUC122 CORDLESS CHAIN SAW 115MM PARTS | ||
| # | Part Num. | Description |
| 1 | 158472-4 | KNOB 60 COMPLETE |
| C10 | 816905-2 | INDICATION LABEL |
| 2 | 267004-7 | FLAT WASHER 6 |
| 3 | 158471-6 | SPROCKET COVER COMPLETE |
| 4 | 961014-3 | STOP RING E-8 |
| 5 | 221527-9 | SPROCKET 9 |
| 6 | 267732-4 | LOCK WASHER 12 |
| 6-1 | 253442-9 | LOCK WASHER 12 |
| 7 | 232238-1 | LEAF SPRING |
| 8 | 265995-6 | TAPPING SCREW 4X18 |
| 9 | 265995-6 | TAPPING SCREW 4X18 |
| 10 | 450213-7 | BEARING HOUSING |
| 10-1 | 450213-7 | BEARING HOUSING |
| 11 | 323806-2 | SPINDLE |
| 12 | 211051-0 | BALL BEARING 609LLB |
| 13 | 226673-3 | HELICAL GEAR 50 |
| 14 | 450436-7 | CAM |
| 15 | 210033-9 | BALL BEARING 696ZZ |
| 16 | 450435-9 | CRANK |
| 17 | 213993-4 | O-RING 1.5 |
| 18 | 158571-2 | OIL PUMP COMPLETE |
| 19 | 421615-4 | CONNECTOR |
| 20 | 450288-6 | TANK CAP |
| 20-1 | 158810-0 | TANK CAP COMPLETE |
| 20-2 | 140L59-8 | TANK CAP COMPLETE |
| 21 | 423373-8 | PACKING |
| 22 | 158634-4 | OIL TANK COMPLETE |
| 23 | 188472-0 | HANDLE SET |
| D10 | INC. 40 | |
| 23-1 | 187237-7 | HANDLE SET |
| D10 | INC. 40 | |
| 23-2 | 187237-7 | HANDLE SET |
| D10 | INC. 40 | |
| 23-3 | 187238-5 | HANDLE SET |
| D10 | INC. 40 | |
| 24 | 231470-4 | COMPRESSION SPRING 6 |
| 25 | 416178-3 | LOCK-OFF BUTTON |
| 26 | 651956-6 | SWITCH TG72BD |
| 27 | 450212-9 | SWITCH LEVER |
| 28 | 643812-4 | TERMINAL |
| 28-1 | 643859-8 | TERMINAL |
| 28-2 | 644808-8 | TERMINAL |
| 28-3 | 644809-6 | TERMINAL |
| 29 | 257264-9 | RING 30 |
| 29-1 | 257363-7 | RING 30 |
| 30 | 265995-6 | TAPPING SCREW 4X18 |
| 31 | 619225-1 | ARMATURE |
| 32 | 638138-7 | YOKE UNIT |
| 33 | 638608-6 | ENDBELL COMPLETE |
| 34 | 188468-1 | MOTOR HOUSING SET |
| D10 | INC. 36 | |
| 35 | 864638-3 | BUC122 NAME PLATE |
| 36 | 188468-1 | MOTOR HOUSING SET |
| D10 | INC. 34 | |
| 37 | 266050-7 | TAPPING SCREW 4X30 |
| 38 | 191971-3 | CARBON BRUSH CB-430 |
| 39 | 643954-4 | BRUSH HOLDER CAP |
| 40 | 188472-0 | HANDLE SET |
| D10 | INC. 23 | |
| 40-1 | 187237-7 | HANDLE SET |
| D10 | INC. 23 | |
| 40-2 | 187237-7 | HANDLE SET |
| D10 | INC. 23 | |
| 40-3 | 187238-5 | HANDLE SET |
| D10 | INC. 23 | |
| 41 | 265995-6 | TAPPING SCREW 4X18 |
| 42 | 158474-0 | FRONT HAND GUARD COMPLETE |
| C10 | 810376-5 | CAUTION LABEL |
| 43 | 266050-7 | TAPPING SCREW 4X30 |
| 44 | 450217-9 | FRONT HANDLE |
| 45 | 266050-7 | TAPPING SCREW 4X30 |
| 46 | 265995-6 | TAPPING SCREW 4X18 |
| 47 | 259041-5 | PUSH NUT 8 |
| 48 | 443125-1 | FILTER |
| A01 | 158476-6 | GUIDE BAR 4.5 COMPLETE |
| C10 | 168450-6 | GUIDE BAR 4.5 |
| A01-1 | 158476-6 | GUIDE BAR 4.5 COMPLETE |
| C10 | 168450-6 | GUIDE BAR 4.5 |
| A02 | 416311-7 | GUIDE BAR CASE |
| A03 | 182229-1 | OIL SUPPLY 100CC |
| A03-1 | 199897-3 | OIL VESSEL SET |
| A04 | 744003-1 | FILE 4 |
| A05 | 194204-5 | BATTERY BL1830 SET |
| A05-1 | 194204-5 | BATTERY BL1830 SET |
| A05-2 | 194204-5 | BATTERY BL1830 SET |
| A05-3 | 194204-5 | BATTERY BL1830 SET |
| A05-4 | 197600-6 | BATTERY BL1830B SET |
| A05-5 | 197600-6 | BATTERY BL1830B SET |
| A06 | 450128-8 | BATTERY COVER |
| A07 | ***DC18RA | DC18RA FAST CHARGER |
| A07-1 | ***DC18RC | DC18RC FAST CHARGER |
| A08 | 824820-6 | PLASTIC CARRYING CASE |
| C10 | 163455-1 | LATCH |
| C20 | 419360-3 | HANDLE |
| A08-1 | 141494-1 | PLASTIC CARRYING CASE |
| C10 | 163455-1 | LATCH |
| C20 | 419360-3 | HANDLE |
| A09 | 806572-1 | BUC122RFE PLASTIC CASE LABEL |
| A10 | 791284-8 | CHAIN BLADE |
| A10-1 | 191G95-7 | 191G95-7 |
| E01 | 620098-7 | 620098-7 |
| E01-1 | 620265-4 | 620265-4 |
| E01-2 | 620G84-0 | 620G84-0 |
| E02 | 688172-7 | 688172-7 |
| E03 | 810111-1 | 810111-1 |
| E03-1 | 817D83-5 | 817D83-5 |
| E04 | 817D83-5 | 817D83-5 |
| F06 | 197944-4 | 197944-4 |
