Makita Spare Parts for Brushcutter EBH341L 33,5CC 4T
€1.46
Tax included
Makita Spare Parts for Brushcutter EBH341L 33,5CC 4T
Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Brushcutter EBH341L 33,5CC 4T.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Brushcutter EBH341L 33,5CC 4T
Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Brushcutter EBH341L 33,5CC 4T.
In the following table, look for the model of Brush Cutter and the respective parts of the code.
| BRUSHCUTTER EBH341L 33,5CC 4T MAKITA pag.1 | ||
| # | Part Num. | Description |
| 1 | 961057-5 | RETAINING RING S17 |
| 2 | 922331-6 | HEXAGON BOLT CUT. 6X20 |
| 3 | 318421-5 | HOUSING CLUTCH EBH341U |
| 4 | 451157-4 | SPACER EBH341U |
| 5 | 210126-2 | BEARING 6003LLU |
| 6 | 962153-2 | RETAINING RING R35 |
| 7 | 165577-3 | CLUTCH DRUM EBH341U |
| 8 | 195144-0 | SUPPORT EBH341U |
| 9 | 911218-7 | CYLINDER HEAD SCREW M5x14 |
| 10 | 961151-3 | RETAINING RING S-32 EBH341U |
| 11 | 424204-4 | DAMPER EBH341U |
| 12 | 318453-2 | COVER CASE EBH341U |
| 13 | 922231-0 | BOLT M5X20 |
| 14 | 318454-0 | PIPE BRACKET EBH341U |
| 15 | 922331-6 | HEXAGON BOLT CUT. 6X20 |
| 16 | 922201-9 | SCREW HEAD HEX. M5X8 |
| 17 | 443146-3 | FELT RING 8 EBH341U |
| 18 | 195251-9 | LOOP HANDLE SET MS335.4C |
| 19 | 911253-5 | SCREW M 5 X 30 X JR3030T |
| 20 | 451596-8 | LOOP HANDLE 28 MS335.4C |
| 21 | 451597-6 | HANDLE CLAMP 28 MS335.4C |
| 22 | 451600-3 | SPACER 28 MS335.4C |
| 44 | 140042-3 | SHAFT PIPE COMPLETE /EM4350UH/EBH341U |
| 45 | 325675-7 | SHAFT EBH341U |
| 46 | 413143-3 | WASHER MS335.4C |
| 47 | 452259-9 | PROTECTOR EBH341U |
| 48 | 266326-2 | TAPPING SCREW 4X18 X MT601 |
| 49 | 347050-7 | CUTTER |
| 50 | 135753-3 | PROTECTOR EXTENSION ASSY/EM4350UH |
| 51 | 346072-4 | PROTECTOR CLAMP/EBH341U |
| 52 | 451090-0 | PROTECTOR COVER /EBH341U |
| 53 | 266280-0 | HEX SOCKET HEAD BOLT M6X30 /EM4350 |
| 54 | 922218-2 | H.S.H. BOLT M5X14 WITH WR/DPB181 |
| 55 | 123835-3 | GEAR CASE ASSEMBLY /EBH341L/EBH341U |
| 57 | 183K07-8 | CUTTER SHAFT SET |
| 58 | 210059-1 | BALL BEARING 6000 HR2010 |
| 59 | 211062-5 | BALL BEARING 6000 X9524NB |
| 60 | 961006-2 | RETAINING RING S10 |
| 61 | 257988-7 | RETAINING RING R26 RBC2510 |
| 62 | 922353-6 | SCREW M6 X30 X HM1202C |
| 63 | 265590-2 | SCREW M8X10 EBH341U |
| 64 | 210081-8 | BALL BEARING 629ZZ EBH341U |
| 66 | 125558-9 | HANGER ASSEMBLY /EM4350UH/EBH341U |
| 67 | 922232-8 | HEX SOCKET HEAD BOLT M5X20 |
| 68 | 210116-5 | BEARING 6201LLU EBH341U |
| 69 | 962151-6 | RETAINING RING R-32 /EM4350/DGA505 |
| 70 | 332114-0 | RECIEVE WASHER /EBH341U/EM4351UH |
| 71 | 346355-2 | CLAMP WASHER |
| 72 | 168526-9 | CUP /EM4350UH/UX360D/EBH252L/EM4351UH |
| 73 | 264025-0 | HEX NUT M10-17/EM4350UH/UX360D/EBH252L |
| BRUSHCUTTER EBH341L 33,5CC 4T MAKITA pag.2 | ||
| 23 | 125760-4 | CONTROL LEVER ASSEMBLY /EBH341L |
| 24 | 266130-9 | SCREW 3X16 X 6203/13 / 6313DW |
| 25 | 451595-0 | SWITCH COVER/ER2650LH/EBH341L |
| 26 | 451594-2 | SWITCH LEVER /ER2650LH/EBH341L |
| 27 | 232251-9 | LEAF SPRING/EM4350UH/EY2650H/ER2650LH |
| 28 | 188831-8 | LEVER CASE SET/EBH341L |
| 29 | 346249-1 | PIPE CLAMP 28 /EBH341L |
| 30 | 922218-2 | H.S.H. BOLT M5X14 WITH WR/DPB181 |
| 31 | 451593-4 | LOCK LEVER MS335.4C |
| 32 | 233541-3 | TORSION SPRING 7 EBH341U |
| 33 | 168549-7 | CONTROL CABLE MS335.4C - EBH341L |
| 34 | 233540-5 | TORSION SPRING 11 EBH341U - EM4350UH/ER2650LH |
| 35 | 451592-6 | THROTTLE LEVER MS335.4C - EBH341L/EM4350RH |
| 36 | 638676-9 | LEAD UNIT MS335.C - EBH341L |
| 37 | 638677-7 | LEAD UNIT MS335.4C - EBH341L |
| 38 | 451602-9 | CORRUGATE TUBE MS335.4C - EBH341L |
| 39 | 266326-2 | TAPPING SCREW 4X18 X MT601 |
| 40 | 188831-8 | LEVER CASE SET MS335.4C - EBH341L |
| BRUSHCUTTER EBH341L 33,5CC 4T MAKITA pag.3 | ||
| 89 | 318614-4 | FLYWHEEL HOUSING EBH341U |
| 90 | 922223-9 | SCREW M5X16 EBH341U EX2650LH |
| 93 | 253762-1 | WASHER 8 X LS1040 |
| 94 | 267832-0 | WAVE WASHER 10 EBH341U |
| 95 | 266571-9 | SCREW M8X23 EBH341U |
| 96 | 125757-3 | CLUTCH SHOE X EM3400L |
| 97 | AN02010C00 | TENSION SPRING 9 |
| 98 | 265577-4 | SCREW M6X16 EBH341U |
| 99 | 319035-3 | FLYWHEEL EBH341U |
| 100 | 168816-0 | IGNITION COIL EBH341U |
| 101 | 922138-0 | SCREW M4X20 |
| 102 | 324891-8 | SPARK PLUG PLUG CAP SPRING EBH341 - EM4350/HTR7610/ER2650 |
| 103 | 424105-6 | PLUG CAP EBH252L - EK7651H/PM7650H/EBH252L |
| 104 | 632E38-3 | LEAD UNIT EBH341U |
| 105 | 632E39-1 | LEAD UNIT EBH341U |
| 106 | 424313-9 | GROMMET EBH341U |
| 107 | 345963-6 | CLAMP EBH341U |
| 109 | 451876-2 | SPARK PLUG COVER EBH341U |
| 110 | 266572-7 | SCREW M5X8 EBH341U |
| 112 | 911213-7 | PAN HEAD SCREW M5X12 X 5143R EBH252L - DPB180/PM7650H |
| 113 | 451875-4 | CYLINDER COVER EBH341U - EW1060H |
| 114 | 266440-4 | HEX SOCKET HEAD BOLT M5X40 EBH341U - ER2650LH |
| 115 | 265184-3 | TRUSS HEAD SCREW M5X55 EBH341U - EBH252L |
| 116 | 345915-7 | MUFFLER COVER EBH341U - EBH252L |
| 117 | 168469-5 | EXHAUST MUFFLER EBH341U - EBH252L |
| 118 | 345916-5 | MUFFLER GASKET EBH341U - EBH251L/EBH341R/EPH1000 |
| 119 | 324980-9 | SPARK ARRESTER EBH341U - EBH252L |
| 120 | 922217-4 | H.S.H. BOLT M5X14 EBH341U - AN942/AN943/EBH341U |
| 121 | 140419-2 | ROCKER COVER COMPLETE EBH341U |
| 122 | 162307-3 | ROCKER COVER GASKET EBH341U/EW1060H |
| 123 | 168534-0 | SPARK PLUG NGK CMR4A EBH341U - ER2650LH/EBH252L |
| 124 | 162274-2 | CAM GEAR COVER GASKET EBH341 - ER2650LH/EBH252L |
| 125 | 318443-5 | CAM GEAR COVER/ER2650LH/EBH252L EBH341U |
| 126 | 922212-4 | H S HBOLT M5 X 12 /GF600/CC300D/AF502 |
| 127 | 450565-6 | OIL GUAGE /EBH252L/EW1060H - EBH341U |
| 128 | 424100-6 | OIL GUAGE GASKET /EBH252L/EW1060H EBH341U |
| 129 | 282020-8 | HOSE CLAMP EBH341U/ER2650LH/EBH252L/ |
| 130 | 424202-8 | OIL TUBE EBH341U /BHX2500/EBH252L |
| 131 | 325666-8 | OIL WEIGHT/EY2650H/ER2650LH/EBH252L/ EBH341U |
| 132 | 162308-1 | CASE GASKET /EBH341U/EW1060H-EBH341U |
| 133 | 318612-8 | OIL CASE EBH341U |
| 134 | 922217-4 | H.S.H. BOLT M5X14 /AN942/AN943/EBH341U-EBH341U |
| 135 | 266573-5 | HEX. SOCKET HEAD BOLT M5X33 EBH341U |
| 136 | 922222-1 | HEX. SOCKET HEAD BOLT M5X16 |
| 137 | 922112-8 | HEX. SOCKET HEAD BOLT M4X10 BPT350 |
| 138 | 318440-1 | RETAINING PLATE EBH341U - EBH252L |
| 139 | 346083-9 | LEAD VALVE /PM7650H/ER2650LH/EBH252L - EBH341U |
| 140 | 424201-0 | CHECK VALVE/EM4350/PM7650/ER2650/EBH252 - EBH341U |
| 141 | 123992-7 | CYLINDER BLOCK ASSEMBLY /EBH341U |
| 142 | 125554-7 | ROCKER ARM ASSEMBLY /ER2650LH/EBH252L - EBH341U |
| 143 | 325912-9 | SPRING RETAINER EBH341U |
| 144 | 234181-0 | COMPRESSION SPRING 13 EBH341U |
| 145 | 256200-2 | PIN 5/EB7650TH/EM4350/EK7651/PM7650 FOR 2704 |
| 146 | 256866-8 | ROD 2,5 EBH341U |
| 147 | 424200-2 | SPACER EBH341U/EM4350/ER2650LH/EBH252L/EY2650 |
| 148 | 268239-3 | PIN 4 EBH341U/ER2650LH/EBH252L/EY2650H |
| 149 | 313169-4 | CAM LIFTER /ER2650LH/EBH252L/BHX2500 - EBH341U |
| 150 | 325913-7 | EXHAUST VALVE EBH341U/EW1060H |
| 151 | 325914-5 | INTAKE VALVE /EBH341U/EW1060H |
| 152 | 125552-1 | CAM GEAR ASSEMBLY /ER2650LH/EBH252L - EBH341U |
| 153 | 268238-5 | /EM4350/ER2650/EBH252/EY2650 - EBH341U |
| 154 | 195141-6 | PISTON RING SET /EBH341U |
| 155 | 197454-1 | PISTON SET EBH341U/EW1060H |
| 156 | 257796-6 | PISTON PIN EBH341U |
| 157 | 233983-1 | CLIP /EM4350/EBH341/EW1060/EM4351 - EBH341 |
| 158 | 254040-2 | WOODRUFF KEY 3 /ER2650LH/EBH341U - EBH341U |
| 159 | 213537-0 | OIL SEAL 12/EM4350UH/EBH341U |
| 160 | 267425-3 | FLAT WASHER 26 EBH341U |
| 161 | 125756-5 | CRANKSHAFT ASSEMBLY /EBH341U |
| 162 | 213769-9 | OIL SEAL 10 /UK360D/ER/EX2650LH/EBH252L |
| 163 | 127108-6 | FUEL TANK CAP /PM7650H/EBH252L |
| 164 | 127109-4 | FUEL TANK CAP /EBH252L/EW1060H |
| 165 | 140436-2 | STRAP COMPLETE/HTR7610/EBH252L/EW1060H - EBH341U |
| 167 | 424104-8 | DAMPER /EBH252L/EW1060H - EBH341U |
| 168 | 451877-0 | FUEL TANK /EBH341U/EW1060H - EBH341U |
| 169 | 163447-0 | FUEL FILTER /EA3201S/PS-221TH/DCS231T - DCS230T |
| 170 | 345920-4 | HOSE CLAMP /EH7500W/EB7650TH/HTR7610 - EBH341U |
| 171 | 424103-0 | DAMPER EBH341U |
| 172 | 424102-2 | DAMPER EBH341U |
| 173 | 162309-9 | TUBE /EBH341U/EW1060H - EBH341U |
| 174 | 126475-6 | RECOIL STARTER SET |
| 175 | 168827-5 | RECOIL STARTER PULLEY |
| 176 | 266580-8 | TAPPING SCREW 5X10 /EBH341U/EW1060H - EBH341U |
| 177 | 451923-9 | REEL /EBH341U/EW1060H - EBH341U |
| 178 | 232257-7 | SPIRAL SPRING EBH341U |
| 179 | 424317-1 | STARTER KNOB EBH341U |
| 180 | 444018-5 | STARTER ROPE EBH341U |
| 181 | 911218-7 | P.H.SCREW M5X14 /DUH523/EBH341/BHX2500 |
| 183 | 162310-4 | TANK GUARD EBH341U |
| 184 | 266809-2 | P.H.SCREW M5X14 /DUH523/EBH341/BHX2500 |
| BRUSHCUTTER EBH341L 33,5CC 4T MAKITA pag.4 | ||
| 185 | 325915-3 | INTAKE PIPE EBH341U |
| 186 | 413120-5 | INSULATOR GASKET /EBH252/EW1060/BHX2500 - EBH341U |
| 187 | 213063-9 | O-RING 10 /EBH252L/EW1060H - HR2000 |
| 188 | 451874-6 | INSULATOR /EBH341U/EW1060H - EBH341U |
| 190 | 346261-1 | CARBURETOR INSULATOR/EPH1000/EBH341U - EBH341 |
| 191 | 922228-9 | H.S.H. BOLT M5X18 /DUR362L/UX360D/DUR187 - EBH341U |
| 192 | 413138-6 | CARBURETOR GASKET /EBH341/EW1060/BHX2500 - EBH341P02 |
| 193 | 450562-2 | CLAMP EBH341U - EBH252L |
| 194 | 922213-2 | H.S.H.BOLT M5X12 WITH WR EBH341U |
| 195 | 168561-7 | CARBURETOR EBH341U |
| 196 | 325922-6 | CARBURETOR SCREW EBH341U/EH7500W HTR7610/PM7650H/EM2500L |
| 197 | 413140-9 | WASHER /PM7650H/ER2650LH/EBH252L |
| 198 | 257964-1 | STOP RING E3 /PM7650H/ER2650LH - EBH341U |
| 199 | WJ00096364 | PAN HEAD SCREW M3X8/ER2650LH/EBH252L - DCS230T |
| 200 | 213538-8 | O RING 2/EH7500W/HTR7610/PM7650H/EM2500L - EBH341U |
| 201 | 5926007011 | JET # 36.5 /EBH341U |
| 202 | 234183-6 | CONICAL COMPRESSION SPRING 65-9 EBH341U - EM4350 |
| 203 | 442155-9 | PUMP GASKET/EH7500W/PM7650H/ER2650LH - EBH341U |
| 204 | WJ00009599 | PUMP DIAPHRAGM /EH7500W/HTR7610/PM7650H - DCS230T |
| 205 | 266582-4 | TAPPING SCREW 3X24/HTR7610/EM2500L EBH341U |
| 206 | 346270-0 | PRIMER PUMP COVER/HTR7610/EM2500/EBH252L - EBH341U |
| 207 | 424314-7 | PRIMER PUMP /HTR7610/EM2500L/ER2650LH - EBH341 (DA00001149) |
| 208 | 140438-8 | AIR PURGE BODY /ER2650LH/EY2650H - EBH341U |
| 209 | 168620-7 | METERING DIAPHRAGM/EM2500L/EBH252L - BHX2501 |
| 210 | 442154-1 | METERING DIAPHRAGM GASKET/HTR7610/EM2500 - EBH341 |
| 211 | 140437-0 | UMP BODY /ER2650LH/EBH252L/RBC3100/RBC3110 - EBH341U |
| 212 | WJ00014070 | CARBURETOR INLET SCREEN /EH7500W/EM4350/HTR7610 - DCS230T |
| 213 | 345918-1 | HOSE CLAMP/EM4350/EK7651/ER2650/EBH252 - EBH341U |
| 214 | 422055-9 | BREATHER PIPE /ER2650LH/EBH341U |
| 215 | 422042-8 | PIPE /EBH252L/EW1060H - EBH341U |
| 216 | 125468-0 | CLEANER PLATE ASSEMBLY /EBH252L - EBH341U |
| 217 | 451925-5 | CHOKE LEVER /EBH252L/EW1060H/BHX2500 - EBH341U |
| 218 | 213540-1 | O RING 15 /EN4951SH/ER2650LH/EBH252L - EBH341U |
| 219 | 424316-3 | CHECK VALVE/EM4350/PM7650/ER2650/EBH252 - EBH341U |
| 220 | 213539-6 | O RING 14 /EBH252L/EW1060H/BHX2500 - EBH341U |
| 221 | 451924-7 | CHECK VALVE PLATE |
| 222 | 424315-5 | CHECK VALVE /EBH252L/EW1060H/BHX2500 - EBH341U |
| 223 | 168577-2 | SEPARATOR GASKET /EBH252/EW1060/BHX2500 - EBH341UP01 |
| 224 | 168576-4 | SEPARATOR PLATE /EBH252L/EW1060H/BHX2500 - EBH341U |
| 225 | 450560-6 | CHOKE PLATE /EBH252L/EW1060H/BHX2500 - EBH341U |
| 226 | 423376-2 | GASKET /EBH252L/EW1060H/BHX2500 - EBH341U |
| 227 | 345919-9 | PLATE /EBH252L/EW1060H/BHX2500 - EBH341U |
| 228 | 265188-5 | SCREW M5X68 EBH341U |
| 229 | 443140-5 | AIR CLEANER ELEMENT /BHX2500/EBH252L - EBH341U |
| 230 | 443141-3 | AIR CLEANER ELEMENT /EBH252L - EBH341U |
| 231 | 450561-4 | AIR CLEANER COVER /EBH252/EW1060/BHX2500 - EBH341U |
| 232 | 911218-7 | P.H.SCREW M5X14 /DUH523/EBH341/BHX2500 |
| 234 | 325663-4 | ADJUST SCREW/EBH341L - MS335.4C |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita EBH341L
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 7/10 BUSINESS DAYS APPROX
- MORE INFO:
- info@bricoutensili.com
New
You might also like
Comments (0)
No customer reviews for the moment.
Viewed products
Customers who bought this product also bought:
16 other products in the same category:
