Hitachi Spare Parts for Rotary Hammer Drill DH28PCY2
€4.18
Tax included
Hitachi Spare Parts for Rotary Hammer Drill DH28PCY2
Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Rotary Hammer Drill DH28PCY2.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Rotary Hammer Drill DH28PCY2
Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Rotary Hammer Drill DH28PCY2.
In the following table , look for the model of the Rotary Hammer Drill and the respective parts of the code.
| Rotary Hammer Drill Hitachi - HIKOKI DH28PCY2 | ||
| # | Part Num. | Description |
| 1 | 306345 | FRONT CAP |
| 2 | 306340 | STOPPER RING |
| 3 | 374436 | GRIP |
| 4 | 374437 | BALL HOLDER |
| 5 | 374435 | HOLDER PLATE |
| 6 | 322812 | HOLDER SPRING |
| 8 | 335259 | OIL SEAL |
| 9 | 6805BB | BALL BEARING 6805 |
| 10 | 322789 | PUSHING BUTTON |
| 11 | 317223 | PUSHING SPRING |
| 12 | 334011 | CHANDE LEVER |
| 13 | 878885 | O-RING |
| 14 | 374624 | GEAR COVER |
| 15 | 375018 | GEAR COVER INCLUDING 14.17 |
| 16 | 335800 | SPRING (E) |
| 17 | 608VVM | BALL BEARING 608VVM |
| 18 | 374422 | SHAFT HOLDER (B) |
| 19 | 335300 | STEEL BALL D7.0 (10PCS) * GIVE HTR959156 |
| 20 | 374426 | CYLINDER |
| 21 | 335265 | SECOND GEAR |
| 22 | 374430 | SPRING (B) |
| 23 | 301679 | WASHER (A) |
| 24 | 948310 | RETAINING RING TYPE C FOR D.30 SHAFT |
| 25 | 335262 | OIL SEAL (A) |
| 26 | 374431 | HAMMER HOLDER (B) |
| 27 | 374427 | HOLDER SLEEVE |
| 28 | 374432 | SECOND HAMMER |
| 29 | 374429 | HAMMER HOLDER (B) |
| 30 | 322805 | DAMPER (A) |
| 31 | 322808 | O-RING (C) |
| 32 | 324524 | DAMPER HOLDER DH24PB3-PC3 |
| 33 | 322807 | STOPPER RING |
| 34 | 374443 | STRIKER |
| 35 | 372816 | O-RING |
| 36 | 372817 | PISTON |
| 37 | 335793 | PISTON PIN |
| 38 | 335794 | PISTON WASHER |
| 39 | 374434 | LOCK PLATE |
| 40 | 374440 | SECOND PINION |
| 41 | 323182 | CLUTCH SPRING |
| 42 | 375022 | CLUTCH |
| 43 | 331315 | WASHER DH22PH |
| 44 | 374439 | CHANGE PLATE© |
| 45 | 374438 | SECOND SHAFT |
| 46 | 335249 | RECIPROCATING BEARING |
| 47 | 374441 | FIRST GEAR |
| 48 | 374442 | BEARING WASHER |
| 49 | 335245 | O-RING D72.2 |
| 50 | 374625 | INNER COVER |
| 51 | 374627 | WEIGHT (A) |
| 52 | 335282 | LEAF SPRING |
| 53 | 374628 | WEIGHT (B) |
| 55 | 334008 | AIR CAP |
| 56 | 324543 | FELT PACKING (A) |
| 57 | 374626 | SPRING HOLDER |
| 59 | 322816 | FELT PACKING |
| 60 | 322818 | PACKING WASHER DH24PM |
| 61 | 876796 | O-RING P.22 |
| 62 | 608DDM | BALL BEARING 608DDM |
| 63 | 982631 | WASHER |
| 64 | 361108E | ARMATURE (B) 220V-230V |
| 66 | 341028K | STATOR (A) 220V-230V |
| 67 | 374622 | HOUSING |
| 68 | 955203 | BRUSH HOLDER |
| 69 | 999041 | CARBON BRUSHE (1 PAIR) |
| 70 | 999072 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 75 | 322853 | PUSHING BUTTON |
| 76 | 374610 | SWITCH 220V-240V |
| 78 | 714520 | CORD 5M 2X1.5 WITH PLUG (CORD ARMOR D8.8) |
| 79 | 953327 | CORD ARMOR D8.8 |
| 80 | 937631 | CORD CLIP |
| 82 | 930039 | NOISE SUPPRESSOR FOR EUROPE.RUS.NZL.CHN.TPE |
| 83 | 374623 | HANDLE COVER |
| 85 | 375363 | GRIP SET INCLUD. 1-6.19 |
| 501 | 374630 | CASE |
| 502 | 374447 | SIDE HANDLE |
| 503 | 303709 | DEPTH GAUGE |
| 504 | 402544 | CASE ASS'Y (STACKABLE 1) INCLUD.505-507 |
| 505 | 336472 | LATCH |
| 506 | 336473 | HANDLE |
| 507 | 336474 | HINGE |
| 508 | 337741 | INNER TRAY |
| 509 | 306885 | DUST COLLECTOR (B) ASS'Y DH24PB3-PC3-PD3 |
| 510 | 948310 | RETAINING RING FOR D30 SHAFT HIT-948310.A4 |
| 511 | 959150 | STEEL BALL D6.35 (10 PCS.) |
| 512 | 971787 | DUST CUP |
| 513 | 335781 | GREASE FOR ROTARY HAMMER (500G) |
| 514 | 335782 | GREASE FOR ROTARY HAMMER (60G) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
