DEWALT DWE4016-QS Small Angle Grinder Parts
search
  • DEWALT DWE4016-QS Small Angle Grinder Parts
  • DEWALT DWE4016-QS Small Angle Grinder Parts - Drawing

DEWALT DWE4016-QS Small Angle Grinder Parts

€60.23
Tax included

DEWALT DWE4016-QS Small Angle Grinder Spare Parts

DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DWE4016-QS Angle Grinder Spare Parts.
ITEM CODE: N358499
Quantity
on Demand Only Call Us Before

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

DEWALT DWE4016-QS Small Angle Grinder Spare Parts

DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DWE4016-QS Angle Grinder Spare Parts.

In the following table, look for the model of the hammer and the respective parts of the code.
DWE4016-QS Angle Grinder Spare Parts

DWE4016-QS TYPE 1 DeWalt Small Angle Grinder Spare Parts
# Part Num. Description
101 N358499 ARMATURE
102 N446377 FIELD 230V
102 N458913 FIELD 115V
103 N442171 SWITCH
104 1003859-00 BRUSH PAIR 230V
104 N082895 BRUSH PAIR 115V
105 N336999 CORDSET
106 N134466 OUTER FLANGE
107 391969-00 INNER FLANGE
108 330045-46 SCREW
109 N446378 CAPACITOR
110 N309548 GUARD SA
113 N308541 GEAR CASE COVER
114 N318739 SPINDLE
116 N542553 CORD PROTECTOR
116 N918736 CORD PROTECTOR
117 661244-00 GEAR & PINION
118 562097-01 SCREW
120 641893-00 FELT SEAL
121 562211-00 HANDLE SIDE SA
122 945299-00 FLANGE
123 945292-00 ANGLE GRINDER NUT
124 944575-00 ANGLE GRINDER BUTTON
125 562210-00 ANGLE GRINDER SPRING
126 944571-00 ANGLE GRINDER SPINDLE LOCK
127 605040-22 BEARING
128 641823-00 SLEEVE
129 401623-00 ANGLE GRINDER BAFFLE
130 949638-01 BUFFER
132 606574-01 BRUSH HOLDER
133 562204-00 BRUSH SPRING
134 609299-01 FIELDCASE
135 605040-03 BALL BEARING
136 394938-01 END CAP
137 N438051 SWITCH SUPPORT
138 N107295 HEX KEY 6 MM
139 562097-05 SCREW
140 401622-01 ANGLE GRINDER FLANGE
141 398906-00 ANGLE GRINDER SPACER INSULATING
145 562097-00 SCREW
160 N110359 BEARING
162 611737-01 SWITCH LINK
163 569624-01 SWITCH LINK BUTTON
164 562097-13 SCREW
165 N358559 GEARCASE
171 393799-00 O RING
172 N288581 STRAP
173 562160-02 SCREW
174 569639-00 WASHER SPRING
800 286436-00 GREASE
816 946194-00 BRAND LABEL
821 N452531 RATING PLATE
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
