FIAC Spare Parts for Piston Air Compressor Unit CCS 245 FOR APOLLO 100
€349.56
Tax included
FIAC Spare Parts for Piston Air Compressor Unit CCS 245 FOR APOLLO 100
Fiac Genuine parts or replacement parts for to repair Piston Air Compressor Pump Unit CCS 245 FOR APOLLO 100 validity date - from 27/02/2003.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Spare Parts for Piston Air Compressor Unit CCS 245 FOR APOLLO 100
Fiac Genuine parts or replacement parts for to repair Piston Air Compressor Pump Unit CCS 245 FOR APOLLO 100 validity date - from 27/02/2003.
In the following table , look for the model of the pumping unit and the respective parts of the code.
| CCS 245 100 FOR APOLLO validity date - from 27/02/2003 | ||
| # | Part Num. | Description |
| 1 | 7015140000 | ROD M6X130 |
| 2 | 7640080000 | Cover |
| 3 | 7060010000 | Bearing 6203 ZZ 17:40:12 QE6 |
| 4 | 7500030000 | CABLE GUIDE |
| 5 | 7020070000 | Nut M8 UNI-5587 |
| 6 | 7310360000 | 60 uF capacitor - Repl. by 7310550000 |
| 7 | 4012930000 | Stator |
| 8 | 7660120000 | Rotor |
| 9 | 7580150000 | ELECTRIC CRANKSHAFT HP.2 |
| 10 | 7060010000 | Bearing 6203 ZZ 17:40:12 QE6 |
| 11 | 7160060000 | spring A 693 |
| 12 | 7021030000 | Nut M8 UNI-7473 |
| 13 | 7230060000 | Tube Rilsan Ø12X10 |
| 14 | 7090090000 | Cap M1 / 4 "Brass |
| 15 | 7100530000 | Pressure regulator |
| 16 | 7081090000 | Fitting 1/4 "MM |
| 17 | 7250360000 | Pressure Switch |
| 18 | 7110060000 | Manometer |
| 19 | 7084220000 | Fitting DIR.M1 / 4 "-6 QUICK |
| 20 | 5011060008 | BASE |
| 21 | 7360020000 | Rubber Ø16 |
| 22 | 7015290000 | ROD M6X130 |
| 23 | 7329070000 | Power cable |
| 24 | 7020200000 | Nut M6 UNI-5587 |
| 25 | 7012090000 | Screw M5X12 UNI-8112 |
| 26 | 7408530000 | Pulley Øp75 1 "A" F.16 - DISCONTINUED |
| 27 | 7012130000 | Screw Ø 4,8X22 UNI-6954 |
| 28 | 7200080000 | Cooler Fan |
| 29 | 7038080000 | Fan Washer |
| 30 | 7012060000 | Screw M4X12 UNI-8112 |
| 31 | 7151060000 | Carena plastic top |
| 32 | 7011420000 | Screw M6X16 UNI-5739 |
| 33 | 7011090000 | Screw M8X20 UNI-5739 |
| 34 | 7030270000 | Washer Ø8,5X30X4 UNI-6593 |
| 35 | 7051500000 | Tab 4X6,5 |
| 36 | 7408520000 | Pulley Øp160 1 "A" |
| 37 | 7371090000 | Belt SPZX 750 |
| 38 | 7151070000 | Plastic bottom HOUSING |
| 39 | 3020451000 | Pumping unit AB 245 |
| 40 | 7012200000 | Screw M8x35 UNI-8112 |
| 41 | 7640070000 | Cover - DISCONTINUED |
| 42 | 7051240000 | Tab "A 5X5X22" UNI 6604-69 |
| 43 | 7012240000 | Screw M5X15 UNI-8112 |
| 44 | 7311000000 | Headset condenser Ø45x65 |
| 45 | 7501050000 | Block Cable |
| 46 | 7151130000 | Carena plastic |
| 47 | 7012060000 | Screw M4X12 UNI-8112 |
| 48 | 7082700000 | Fitting "T" 3 / 8F-1 / 2M.SV-1 / 2M |
| 49 | 7196010000 | Valve Start M3 / 8 "1.5 bar |
| 50 | 7110010000 | Manometer |
| 51 | 7080180000 | Fitting "L" 1/4 MF |
| 52 | 7130010000 | Line cock M1 / 4 " |
| 010A | 4280710000 | Rotor |
| FIAC AB 245 CAST IRON Spare Parts | ||
