Kawasaki Spare Parts for Bruschcutter KD3-530BP
€40.85
Tax included
Kawasaki AMA Spare Parts for Bruschcutter KD3-530BP
Distribution and Sale at attractive prices of Kawasaki Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Bruschcutter AMA Garden Powered Kawasaki KD3-530BP–90495.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Kawasaki AMA Spare Parts for Bruschcutter KD3-530BP
Distribution and Sale at attractive prices of Kawasaki Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Bruschcutter AMA Garden Powered Kawasaki KD3-530BP–90495.
In the following table, look for the model of the Bruschcutter and the respective parts of the code.
| BRUSHCUTTER AMA Garden Powered KAWASAKI (KD3-530BP) pag.1 | ||
| # | Part Num. | Description |
| 1 | 88490 | FRAME BACKPAK |
| 2 | 88491 | ENGINE HOLDER PLATE |
| 3 | 79870 | GROMMET |
| 4 | WASHER 10 | |
| 5 | WASHER 10 | |
| 6 | NUT M10 | |
| 7 | 88496 | CLUTCH COMPL. |
| 9 | 88497 | FLEXIBLE PIPE ASSY |
| 10 | 88492 | JOINING ASSY |
| 14 | 88498 | TUBE |
| 15 | 90418 | INSERT |
| 16 | 88499 | DRIVE SHAFT |
| 17 | 79952 | GEAR CASE ASSY |
| 19 | 88493 | SPOOL ASSY |
| 20 | 88500 | THROTTLE LEVER ASSY |
| 21 | 88402 | HANDLE ASSY |
| 22 | 79950 | BRACKET |
| 24 | 88619 | SAFETY GUARD ASSY |
| BRUSHCUTTER KAWASAKI (KD3-530BP) pag.2 | ||
| 11005 | 11005-2166 | CYLINDER-ENGINE |
| 11061 | 11061-2234 | GASKET,CYLINDER |
| 13272 | 13272-2044 | PLATE |
| 13272A | 13272-2049 | PLATE |
| 49120 | 49120-0713 | CRANKCASE |
| 34001 | 34001-2093 | STAND |
| 92033 | 92033-2202 | RING-SNAP |
| 92045 | 92045-2285 | BEARING-BALL |
| 92049 | 92049-2280 | SEAL-OIL |
| 92049A | 92049-2281 | SEAL-OIL |
| 92154 | 92154-2047 | BOLT |
| 92172 | 92172-2103 | SCREW,4X8 |
| 92172A | 92172-2122 | SCREW,5X40 |
| BRUSHCUTTER KAWASAKI (KD3-530BP) pag.3 | ||
| 13001 | 13001-2197 | PISTON-ENGINE |
| 13002 | 13002-2105 | PIN-PISTON |
| 13008 | 13008-6075 | RING-SET-PISTON |
| 13033 | 13033-2063 | BEARING-SMALLEND |
| 49119 | 49119-2248 | CRANKSHAFT-ASSY |
| 92026 | 92026-2364 | SPACER |
| 92033 | 92033-2200 | RING-SNAP |
| BRUSHCUTTER KAWASAKI (KD3-530BP) pag.4 | ||
| 16073 | 16073-2239 | INSULATOR |
| 21050 | 21050-2328 | FLYWHEEL |
| 21130 | 21130-2082 | CAP-SPARKPLUG |
| 21169 | 21169-2080 | TERMINAL |
| 21171 | 21171-2292 | COIL-ASSY-IGNITION |
| 26011 | 26011-2389 | WIRE-LEAD |
| 26011A | 26011-2399 | WIRE-LEAD |
| 92038 | 92038-2109 | KEY |
| 92070 | 92070-2122 | PLUG-SPARK |
| 92071 | 92071-0704 | GROMMET |
| 92153 | 92153-2138 | BOLT,4X20 |
| 92173 | 92173-0963 | CLAMP |
| 92210 | 92210-2136 | NUT 10MM |
| BRUSHCUTTER KAWASAKI (KD3-530BP) pag.5 | ||
| 11053 | 11053-2066 | BRACKET |
| 11060 | 11060-2111 | GASKET |
| 11061 | 11061-0763 | GASKET,INSULATOR-CYLINDER |
| 11061A | 11061-2054 | GASKET |
| 11061B | 11061-2237 | GASKET,CARBUR.-INSULATOR |
| 12021 | 12021-0706 | VALVE-ASSY-REED |
| 14043 | 14043-2051 | FILTER |
| 14090 | 14090-2017 | COVER,PRIMERPUMP |
| 15004 | 15004-2100 | CARBURETOR-ASSY |
| 16030 | 16030-2078 | VALVE-FLOAT |
| 16055 | 16055-2051 | LEVER |
| 16160 | 16160-0728 | BODY |
| 16160A | 16160-2101 | BODY |
| 21083 | 21083-2073 | ARM |
| 43028 | 43028-2067 | DIAPHRAGM |
| 43028A | 43028-2096 | DIAPHRAGM |
| 49043 | 49043-2067 | PUMP-PRIMING |
| 92043 | 92043-2094 | PIN |
| 92055 | 92055-2147 | RING-O |
| 92063 | 92063-0018 | JET-MAIN,#53 |
| 92144 | 92144-2308 | SPRING |
| BRUSHCUTTER KAWASAKI (KD3-530BP) pag.6 | ||
| 11013 | 11013-2242 | ELEMENT-AIR FILTER |
| 11038 | 11038-0705 | CASE-ASSY-AIRFILTER |
| 11061 | 11061-0822 | GASKET,MUFFLER |
| 11065 | 11065-2141 | CAP |
| 13168 | 13168-2521 | LEVER,AIRFILTER |
| 16126 | 16126-2250 | VALVE,AIRFILTER |
| 18020 | 18020-2096 | BAFFLE |
| 18077 | 18077-2144 | ARRESTER-SPARK |
| 49069 | 49069-2454 | MUFFLER-ASSY |
| 92055 | 92055-2222 | RING-O |
| 92153 | 92153-2137 | BOLT,SOCKET,5X16 |
| 92154 | 92154-2045 | BOLT,5X30 |
| 92172 | 92172-2112 | SCREW |
| 92172A | 92172-2114 | SCREW,5X14 |
| 92172B | 92172-2130 | SCREW,5X55 |
| 92172C | 92172-2136 | SCREW,3X10 |
| BRUSHCUTTER KAWASAKI (KD3-530BP) pag.7 | ||
| 13165 | 13165-2109 | PAWL,RECOIL-STARTER |
| 13169 | 13169-2386 | PLATE,RECOIL-STARTER |
| 32099 | 32099-0707 | CASE,STARTER-RECOIL |
| 46075 | 46075-2129 | GRIP,RECOILSTARTER |
| 49060 | 49060-0556 | CAM,PLATE |
| 49080 | 49080-0707 | PULLEY-STARTING |
| 49088 | 49088-0711 | STARTER-RECOIL |
| 59101 | 59101-0010 | REEL,STARTER-RECOIL |
| 59106 | 59106-0554 | ROPE,3.8X1000 |
| 92033 | 92033-2010 | RING-SNAP |
| 92145 | 92145-0837 | SPRING,SPIRAL |
| 92145A | 92145-0864 | SPRING,DAMPER |
| 92145B | 92145-2148 | SPRING |
| 92172 | 92172-0705 | SCREW |
| 92172A | 92172-0710 | SCREW,6X22 |
| BRUSHCUTTER KAWASAKI (KD3-530BP) pag.8 | ||
| 14069 | 14069-2088 | BREATHER |
| 49019 | 49019-2111 | FILTER-FUE |
| 51001 | 51001-2343 | TANK-COMP-FUEL |
| 51048 | 51048-2087 | CAP-ASSY-TANK |
| 92009 | 92009-2249 | SCREW,5X20 |
| 92071 | 92071-2169 | GROMMET |
| 92171 | 92171-2086 | CLAMP |
| 92173 | 92173-2022 | CLAMP |
| 92192 | 92192-2177 | TUBE,3X5X200 |
| 92192A | 92192-2225 | TUBE,3X5.5X100 |
| BRUSHCUTTER KAWASAKI (KD3-530BP) pag.9 | ||
| 49089 | 49089-0752 | SHROUD-ENGINE |
| 49089A | 49089-2781 | SHROUD-ENGINE |
| 59066 | 59066-2823 | HOUSING-FAN |
| 92043 | 92043-2275 | PIN |
| 92172 | 92172-2060 | SCREW,4X10 |
| 92172A | 92172-2125 | SCREW,5X16 |
| 92172B | 92172-2140 | SCREW,5X12 |
| 13081 | 13081-2224 | CLUTCH-ASSY |
| 13270 | 13270-2118 | PLATE |
| 13270A | 13270-2119 | PLATE |
| 49049 | 49049-2098 | SHOE-CLUTCH |
| 92043 | 92043-2210 | PIN,CLUTCH |
| 92144 | 92144-2373 | CLUTCH SPRING |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
