ARSG Parts for Pressure Washer PROLINER SV 1310 TSS RLW - 12319

€30.06
Tax included

ARSG Parts for Pressure Washer PROLINER SV 1310 TSS RLW - 12319

Fix Your Pressure Washer PROLINER SV 1310 TSS RLW - 12319. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
ITEM CODE: 1864
Quantity
Usually Ships in: 10/15 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

ARSG Parts for Pressure Washer PROLINER SV 1310 TSS RLW - 12319

Fix Your Pressure Washer PROLINER SV 1310 TSS RLW - 12319. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.
Pressure Washer PROLINER SV 1310 TSS RLW - 12319

Pressure Washer PROLINER SV 1310 TSS RLW - 12319
Casing SV 1310 TSS RLW - 12319 Pag.1
# Part Num. Description
1 2500044 Yellow Casing
2 2500340 Stopper
3 2500310 Knob
4 2500050 Hook
5 2500240 Bowl
6 1680880 Washer
7 2500320 Wheel
8 2500330 Tube Cleaner
9 2500100 Plate
10 1260470 Screw
11 2100300 Screw
12 2600100 Strain Relief
13 2100300 Screw
15 2500130 Rubber
16 880280 Screw
17 2180300 Washer
18 2500120 Axle
19 2500110 Tank
20 2500010 Base
21 42113 Pre-Assembly Plug
22 2500330 Tube Cleaner
23 2000230 Filter
24 2509000 Pre-Assembly Base
Pump SV 1310 TSS RLW - 12319 Pag.2
1 1260760 Screw
2 1269101 Cover
3 1260040 Oil Seal
4 1260780 Screw
5 1980740 Stopper
6 740290 O-Ring
7 1260012 Pump Body
8 1266740 Oil Seal
9 1260790 Ring
10 1320370 Bearing
11 1320330 Bush
12 1260460 Oil Seal
13 1260450 Watertight
14 1260420 O-Ring
15 1320351 Piston Guide
16 1780720 Watertight
17 1320340 Ring
18 820361 Stopper
19 180101 O-Ring
20 1320020 Head
21 1381550 Washer
22 680570 Screw
23 960160 O-Ring
24 1260162 Stopper
25 1269050 Complete Valve
26 880830 O-Ring
27 1343160 Junction
28 3226 Manometer
29 1260180 Shaft
30 1320370 Bearing
32 1260790 Ring
33 1260750 Ring
34 1380520 Tongue
35 1320140 Piston Rod
36 1260070 Piston
37 1260080 Thorn
38 1260091 Disk
39 480480 O-Ring
40 1260211 Piston
41 1260100 Washer
42 1260110 Nut
43 1269284 Pre-Assembly Head
A 1864 Valve Kit
B 2629 Piston Kit
C 1865 Oil Seals Kit
E 42479 Kit Held Water
F 2040 Seal Kit
Motor SV 1310 TSS RLW - 12319 Pag.3
1 1260300 Fan
2 1260970 Seal
3 480621 Screw
4 1260961 Shield
5 1260950 Bearing
6 1269100 Clamp
7 1260400 Gasket
8 1261560 Screw
9 1272010 Box
11 1272370 Switch
12 1271950 Cable Clamp
13 1269090 Cable Clamp
14 2360400 Condenser
15 1340280 Band
16 1260810 Screw
18 1270950 Cable
19 4553 Engine
20 1271660 Fan Cover
21 1261570 Screw
Valve SV 1310 TSS RLW - 12319 Pag.4
1 2500210 Knob
2 392840 Screw
3 1980300 Nut
4 2500540 Insert
5 1980220 Disk
6 1271070 Spring
7 1080041 Piston
8 1080070 Thorn
9 1080401 Ring
10 1080250 O-Ring
11 1080070 Thorn
12 1980210 Piston Guide
13 740290 O-Ring
14 800560 O-Ring
15 880830 O-Ring
16 1271170 Ring
17 1080190 O-Ring
18 1271160 Piston
19 1980200 Office
20 1470210 O-Ring
21 1540272 Screw
22 390080 O-Ring
23 1540660 Valve Body
24 1140450 O-Ring
25 1460430 O-Ring
26 1540170 Shutter
27 1080091 Spring
28 394280 O-Ring
34 1560490 Hose
35 480480 O-Ring
36 1250280 Sphere
37 1560520 Spring
38 1540570 Junction
39 1540300 Nut
41 1540280 Collector
42 1540630 O-Ring
44 880270 O-Ring
45 2260420 Screw
46 480440 O-Ring
47 1560900 Junction
48 1461470 Junction
50 1340260 Filter
51 1123960 Junction
52 1981190 Screw
53 1260820 O-Ring
54 1540881 Piston
55 1981320 Spring
56 2022201 Fork
57 2029753 Pre-Assembly Box TSS
58 660190 O-Ring
59 880840 O-Ring
60 1540870 Stopper
61 22075 Complete Valve
62 1120681 O-Ring
63 42458 Kit TSS
64 1080192 O-Ring
F 42451 Seal Kit
RLW S-SV 1310 TSS RLW - 12319 Pag.5
1 40644 Pre Mounting Hose Reel
2 40377 Hose Pre-Assembly
3 2360360 Screw
4 2360150 Lever
5 2100300 Screw
6 2500060 Stirrup
7 2500360 Pin
8 1681280 Screw
9 2360230 Disk
10 380420 Ring
11 2500390 High Pressure Tube
12 2360210 Pin
13 390080 O-Ring
14 2360220 Junction
15 2360320 Ring
16 2500070 Stirrup
17 820510 O-Ring
18 2360310 Junction
19 2360250 High Pressure Tube
20 2500020 Handle
Accessories SV 1310 TSS RLW - 12319 Pag.6
1 40925 Gun
2 40112 Lance + Nozle
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
PROLINER SV 1310 TSS - 12319
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:
AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
New

Download

Diagram AR Farmer's SV 1310 RLW

Diagram AR Farmer's SV 1310 RLW

Download (707.48KB)
