Femi Spare Parts for Band Saw NG120-8485020
€18.10
Tax included
Femi Spare Parts for Band Saw NG120-8485020
We have the original FEMI parts, the diagram and parts list and tool repair that help you need to get your tools running like new again.Fix Your Band Saw NG120 - 8485020. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Band Saw NG120-8485020
Fix Your Band Saw NG120 - 8485020. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Band Saw and the respective parts of the code.
| Band Saw NG120-8485020 | ||
| # | Part Num. | Description |
| 1 | 5100076 | SCREW |
| 2 | 5080116 | SPRING |
| 8 | 5130428 | SLIDING VICE PLATE |
| 12 | 5130416 | PLATE |
| 13 | 5130426 | PLATE |
| 14 | 5130815 | PLATE |
| 16 | 5181722 | GRADUATE SLIDE |
| 18 | 5124029 | ADJUST WASHER |
| 20 | 5171047 | PIN |
| 23 | 5081025 | SPRING |
| 25 | 7130552 | ROD STOP GROUP |
| 26 | 5043560 | BAND SAW BASE |
| 30 | 5137793 | REST FOOT |
| 33 | 5150005 | VICE PIN STOPPER |
| 34 | 5063034 | BUSHING |
| 35 | 5100321 | SCREW |
| 36 | 5142014 | LEVER |
| 37 | 5042754 | SLIDING VICE |
| 41 | 5152597 | VICE JAW |
| 45 | 5100507 | BLADE TENSIONING SCREW |
| 48 | 5050129 | LEFT HALF-HANDLE |
| 50 | 5130734 | WHEEL GUIDE |
| 51 | 5001572 | SHAFT |
| 52 | 5137914 | WHEEL SUPPORT |
| 54 | 5050128 | RIGHT HALF-HANDLE |
| 56 | 0802324 | SWITCH |
| 57 | 5181727 | CABLE PROTECTION |
| 58 | 5042752 | (included into code 5042845+7132512) |
| 60 | 5154103 | CABLE LOCKING DEVICE |
| 61 | 5124064 | WASHER |
| 64 | 7214212 | DRIVING WHEEL GROUP |
| 65 | 5124065 | WASHER |
| 67 | 5124066 | WASHER |
| 70 | 5181728 | ARM PROTECTION |
| 72 | 5214225 | FREE WHEEL |
| 73 | 5124062 | WASHER |
| 74 | 7130589 | COMPLETE BLADE TENSION DEVICE |
| 77 | 5081005 | SPRING |
| 78 | 5120663 | SPACER |
| 79 | 5181738 | BLADE CLEANER |
| 84 | 5130774 | BLADE GUIDE |
| 89 | 5100075 | SCREW |
| 90 | 5100074 | SCREW |
| 91 | 5100065 | SCREW |
| 92 | 5100064 | SCREW |
| 93 | 5181730 | BLADE GUIDE PROTECTION |
| 95 | 5120638 | SPACER |
| 98 | 5130732 | BLADE GUIDE -- > 7132502 - DISCONTINUED |
| 100 | 5182856 | MOTOR COVER |
| 101 | 5154501 | CABLE LOCKING DEVICE |
| 102 | 5870843 | CABLE |
| 104 | 5850008 | BRUSHES SUPPORT |
| 105 | 7013142 | ROTOR |
| 107 | 0816004 | RADIO INTERFERENCE SUPPRESSOR |
| 108 | 5850111 | FAN WITH MAGNETIC RING |
| 109 | 7820112 | ELECTRONIC SPEED REGULATOR |
| 110 | 5182857 | BOX COVER |
| 114 | 7213016 | GEAR GROUP |
| 115 | 5182542 | GEAR COVER |
| 118 | 5182006 | GREASE BAFFLE PLATE |
| 119 | 5063040 | THREADED BUSH |
| 123 | 5024115 | STATOR - FIELD |
| 124 | 5850112 | CARBON BRUSHE SET |
| 125 | 5061038 | RUBBER BUSHING |
| 126 | 7801817 | (included into code 7801851) |
| 127 | 7132503 | (included into code 7132527 |
| 128 | 7132502 | FRONT SLIDING GUIDE GROUP |
| 129 | 5182856 | MOTOR COVER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice.< We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi NG120 - 8485020
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM CODE OR S/N FEMI:
- FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS
New
