FIAC AIRBLOK 40 Spare Parts

€330.49
Tax included

FIAC AIRBLOK40 Spare Parts

We are FIAC AIR COMPRESSORS original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to solve or repair issues for Super Silent Belt Drive Rotary Screw Compressor AIRBLOK40.
ITEM CODE: 7583440000
Quantity
on Demand Only

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

FIAC AIRBLOK40 Spare Parts

We are FIAC PROFESSIONAL AIR COMPRESSORS original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Super Silent Belt Drive Rotary Screw Compressor AIRBLOK40.

In the following table, look for the type of the Compressor and the respective parts of the code.
AIRBLOK 50-

FIAC AIRBLOK40 8 BAR 10 BAR 13 BAR - B170D SPARE PARTS Pag.1
Pos. Codice Descrizione
1 7380210000 Electric motor 400V compressor - Motore elettrico compressore 400V
1A 7383740000 Electric motor 230V compressor - Motore elettrico compressore 230V
2 7583440000 Fan connection - Mozzo ventola
3 7200011400 Fan - Ventola 50Hz
3A 7201310000 Fan - Ventola 60Hz
4 7030030000 Washer - Rondella Ø8
5 7031010000 Toothed washer - Rondella dentata Ø8
6 7011090000 Screw - Vite TE M8x20
7 7014190000 Screw - Vite STEI M8x30
8 7020070000 Nut - Dado M8
9 7011660000 Screw - Vite TE M18x50
10 7423230000 Air end - Vite completa B170D
11 7020140000 Nut - Dado M18
12 7030610000 Washer - Rondella Ø18
13 7012800000 Screw - Vite TE M18x30
14 7030600000 Toothed washer - Rondella dentata Ø18
15 7172130000 Support - Supporto motore
16 7510780000 Support - Piastra trasmissione motore
17 7234020000 Hose - Tubo iniezione
18 7020100000 Nut - Dado M12
19 7030140000 Washer - Rondella Ø12
20 7459440000 Guide - Guida molla
21 7160280000 Tensioning spring - Molla tensionatore
22 7459430000 Guide - Guida piastra
23 7011620000 Screw - Vite TE M16x35
24 7010050000 Screw - Vite TCCE M8x20
25 7018650000 Screw bolt - Perno tenditore
26 7024200000 Nut - Dado M16
27 7030490000 Toothed washer - Rondella dentata Ø16
28 7030730000 Washer - Rondella Ø16
29 7583100000 Connection - Mozzo
30 7371450000 Belt - Cinghia (50Hz)
30A 7370890000 Belt - Cinghia (60Hz)
31 7407220000 Pulley - Puleggia vite Øp125 (8bar 50Hz)
31A 7407230000 Pulley - Puleggia vite Øp132 (10bar 50Hz)
31B 7407190000 Pulley - Puleggia vite Øp153 (13bar 50Hz)
31C 7407190000 Pulley - Puleggia vite Øp153 (8bar 60Hz)
31D 7407160000 Pulley - Puleggia vite Øp173   (10bar 60Hz)
31E 7409470000 Pulley - Puleggia vite Øp193 (13bar 60Hz)
32 7407230000 Pulley - Puleggia motore Øp 133 (8-10bar)
32A 7407220000 Pulley - Puleggia motore Øp 125 (13bar)
33 7511240000 Plate - Piastra
34 7583021400 Connection - Mozzo
35 7070650000 Or - Or flangia di mandata
36 7488290000 Delivery flange - Flangia di mandata
37 7010610000 Screw - Vite TCCE M12x85
38 4094540000 Oil seal kit (See kit assembling table) - Kit paraolio (Vedi tavola assemblaggio kit)
39 4094550000 Bearings kit+Oil seal kit (See kit assembling table)
- Kit cuscinetti+Kit paraolio (Vedi tavola assemblaggio kit)
40 7079630000 Gasket - Guarnizione valvola di aspirazione
41 7195850000 Suction valve - Valvola di aspirazione
42 7082600000 Suction valve maintenance kit (See kit assembling table)
- Kit manutenzione valvola di aspirazione (Vedi tavola assemblaggio kit)
43 7085940000 Joint - Riduzione
44 4111800000
7433780000
7566200000
7565170000		 Sensor - CHANGE - Control Panel - Sensor - TRASD.PRESS.AK252-1002
* Contact us for quote*
45 7080200000 Joint - Raccordo "L" 1/8" con ogiva
46 7085180000 Joint - Riduzione
47 7011480000 Screw - Vite TE M6x12
48 7030190000 Washer - Rondella Ø6x18
49 7010400000 Screw - Vite TCCE M12x40
50 7080890000 Joint - Raccordo "L" 1/4"x6
51 7043011500 Clamp - Fascetta
52 7080780000 Joint - Raccordo "L" 1/8"x6
53 7211690000 Air filter - Filtro aria
54 7211690010 Air filter cartridge - Cartuccia filtro aria
55 4094230000 Filters kit - Kit filtri
56 4094010000 Maintenance kit - Kit manutenzione
57 7473420000 Separator tank - Serbatoio separatore
58 7081031150 Joint - Nipplo 1"
59 7090430000 Plug - Tappo 1" con rondella
60 7030460000 Washer - Rondella
61 7180140000 Oil level sight glass - Spia livello olio
62 7562600000 Relief valve - Scaricatore olio 1/2"
63 7011160000 Screw - Vite TE M10x30
64 7030360000 Toothed washer - Rondella dentata Ø10
65 7030040000 Washer - Rondella Ø10
66 6002703438 Joint - Riduzione 3/4" 3/8"
67 7080010000 Joint - Raccordo "L" 3/8" MF
68 7192000000 Safety valve - Valvola di sicurezza 3/8" (11bar)
68A 7192520000 Safety valve - Valvola di sicurezza 3/8" (14,25bar)
69 7018620000 Spacer - Distanziale M6x35
70 7080870000 Joint - Raccordo "L" 1/8" MF
71 7250700000 Pressure switch for separator filter clogging
- Pressostato intasamento filtro disoleatore (8 bar)
71A 7250710000 Pressure switch for separator filter clogging
- Pressostato intasamento filtro disoleatore (10 bar)
71B 7250750000 Pressure switch for separator filter clogging
- Pressostato intasamento filtro disoleatore (13 bar)
72 7015380000 Screw - Vite STEI M12x60
73 7212210000 Separator cartdridge - Filtro disoleatore
74 7079650000 Gasket - Guarnizione
75 5158790008 Cover - Coperchio disoleatore
76 7191010000 Valve - Valvola flusso unidirezionale
77 7080180000 Joint - Raccordo "L" 1/4" MF
78 7240490000 Belt guard - Paracinghia
79 5166050008 Conveyor - Convogliatore
80 7230800000 Rilsan hose - Tubo Rilsan nero
81 7020080000 Nut - Dado M10
82 7090460000 Washer - Rondella 1"
83 7081710000 Joint - Nipplo 1"1/4x1"
84 7196290000 Minimum pressure valve - Valvola di minima pressione
85 7234010000 Hose - Tubo pescaggio olio
86 4093270000 Joint - Raccordo ad asta 1/4"
87 7239140000 Hose - Tubo recupero olio
88 7030750000 Toothed washer - Rondella dentata Ø12
89 7364530000 Shock absorbe - Antivibranti
90 7080780000 Joint - Raccordo "L"
91 7082300000 Joint - Raccordo "T" 1/8"x6
92 7080810000 Joint - Raccordo "L" 1/4"x8
93 7194330000 Solenoid valve - Elettrovalvola
94 7085600000 Joint - Raccordo 1/2" 1/4" MF
95 7084220000 Joint - Raccordo diritto 1/4"x6
96 7194340000 Solenoid valve - Elettrovalvola
97 7230010000 Rilsan hose - Tubo Rilsan
98 7232820000 Hose - Tubo mandata
99 7012290000 Screw - Vite T.C. M5x20
100 7155700008 Support - Staffa
101 7011480000 Screw - Vite TE M6x12
102 5160860008 Support - Staffa
103 7016220000 Screw - Vite S.T.E.I. M12x30
104 5165850008 Base - Base
105 7011270000 Screw - Vite TE M12x30
106 7084650000 Joint - Raccordo "L" 3/4"
107 7010520000 Screw - Vite T.C.C.E. M6x55
108 7195810000 Thermostatic - Termostatica
109 7081390000 Joint - Nipplo 3/4"
110 7211141300 Oil filter - Filtro olio
111 7081120000 Joint - Nipplo 3/4"
112 7235580000 Hose - Tubo mandata aria 1"
113 7081031150 Joint - Nipplo 1"
114 7081140000 Joint - Nipplo 1/4"
115 7564020000 Device for air filter clogging - Dispositivo intasamento filtro aria
116 7084010000 Joint - Raccordo 1/8" con ogiva
117 7180110000 Joint - Raccordo
118 7562600010 Valve - Valvola a resca
119 7233200000 Hose - Tubo recupero olio
120 7196540000 Thermostatic valve kit - Kit valvola termostatica
Pag.2
130 5118000008 Compressor base - Base compressore
131 5162360008 Panel - Pannello intermedio superiore nero
132 5165860008 Panel - Pannello intermedio inferiore nero
133 7413290000 Electric board - Apperecchiatura elettrica
134 7020070000 Nut - Dado M8
135 7031010000 Washer - Rondella Ø8
136 5166070008 Fan conveyor - Convogliatore aria
137 5160220008 Reduction - Riduttore ventola
138 7030030000 Washer - Rondella Ø8
139 7081100000 Screw - Vite TE M8x25
140 7111040000 Pressure gauge - Manometro
141 5165960008 Angular - Angolare posteriore superiore
142 7030560000 Washer - Rondella Ø5x20
143 5165980008 Angular - Angolare destro inferiore
144 7080800000 Joint - Raccordo a "L" 1/8"x6
145 7012240000 Screw - Vite M5x15
146 5165940008 Angular - Angolare inferiore anteriore/posteriore
147 5166040008 Column - Montante destro anteriore
148 7360340000 Shock absorber - Antivibranti
149 7020080000 Nut - Dado M10
150 7030040000 Washer - Rondella Ø10
151 5165950008 Angular - Angolare superiore anteriore
152 5165930008 Panel - Sportello cassetta elettrica
153 7018590000 Hinge - Cerniera
154 7014140000 Screw - Vite T.E. M6x22
155 7020060000 Nut - Dado M6
156 7458640000 Key hole - Serratura
157 7458650000 Key - Chiave
158 7500410000 Stretch eliminator - Pressacavo M40x1,5
159 7090440000 Plug - Tappo M20x1,5
160 5165920008 Electric box - Cassetta elettrica
161 4111810000 Pressure sensor - Sensore di pressione
162 7300230000 RESET Push-button - Pulsante RESET
163 7500440000 Stretch eliminator - Pressacavo M20x1,5
164 5166080000 Support - Supporto montanti
165 7080800000 Joint - Raccordo a "L" 1/8"x6
166 7230010000 Rilsan hose - Tubo Rilsan Ø6
167 7084310000 Joint - Raccordo diritto 1/8"x6 con ogiva
168 7239130000 Hose - Tubo rame aria
169 7080800000 Joint - Raccordo "L" 1/2"
170 7300080000 Emergency push-button - Interruttore a fungo
171 7012240000 Screw - Vite TC M5x15
172 7433090000 Electronic panel - Scheda elettronica
173 7500430000 Stretch eliminator - Pressacavo M16x1,5
174 5165970008 Angular - Angolare destro superiore
175 5162990008 Support - Supporto destro cruscotto
176 7070580000 Gasket - Guarnizione pannello portastrumenti
177 5164530008 Support - Supporto sinistro cruscotto
178 7155450000 Dashboard - Pannello portastrumenti
179 7510660000 Electric base - Base impianto elettrico
180 7564260000 Transformer - Trasformatore
181 7031010000 Washer - Rondella Ø8
182 7020070000 Nut - Dado M8
183 7433030000 Relay 400V compressor - Rele sequenza fasi compressore 400V KR
183A 7432770000 Relay 230V compressor - Rele sequenza fasi compressore 230V KR
184 7432280000 Contactor 400V compressor - Contattore compressore 400V K3
184A 7432300000 Contactor 230V compressor - Contattore compressore 230V K3
185 7432300000 Contactor 400V compressor - Contattore compressore 400V K1-K2
185A 7432390000 Contactor 230V compressor - Contattore compressore 230V K1-K2
186 7432470000 Thermal relay 400V compressor - Rele termico compressore 400V F1
186A 7432490000 Thermal relay 230V compressor - Rele termico compressore 230V F1
187 7432840000 Contact - Contatti ausiliari
188 7432720000 Fuse - Fusibile 1A ritardato
189 7431640000 Fuse - Fusibile 1A rapido
190 7432730000 Fuse - Fusibile 630mA ritardato
191 7432760000 Fuse carrier - Portafusibili
192 5166350008 Column - Montante destro posteriore
Pag.3
200 5166020008 Panel - Pannello destro apribile
201 5166010008 Panel - Pannello posteriore fisso
202 7288030000 Handle - Maniglia
203 7459370000 Key hole - Serratura
204 7018590000 Hinge - Cerniera
205 7014140000 Screw - Vite M6x22
206 5166030008 Panel - Pannello superiore apribile
207 5166000008 Panel - Pannello aspirazione destro
208 7512170000 Oil level panel - Pannello spia olio
209 5165870008 Panel - Pannello aspirazione dx
210 5165910008 Panel - Pannello chiusura aspirazione
211 7517430000 Radiator - Radiatore
212 5165880008 Panel - Pannello aspirazione sinistro
213 5165910008 Panel - Pannello superiore radiatore
214 7014150000 Screw - Vite M5x15
215 7458650000 Key - Chiave
216 7014450000 Screw - Vite M5x50
217 5165890008 Panel - Pannello intermedio aspirazione nero
218 7011040000 Screw - Vite TE M6x20
219 7030020000 Washer - Rondella Ø6
220 7160800000 Spring - Molla a gas
221 7012240000 Screw - Vite M5x15
222 5161200008 Support - Supporto destro prefiltro
223 7173410000 Support - Staffa
224 5161190008 Support - Supporto sinistro prefiltro
225 7210830000 Pre-filter - Prefiltro
226 7014050000 Screw - Vite M4x25
227 7030180000 Washer - Rondella Ø4
AIRBLOK 60-B170D Pag,4
1 7082600000 Suction valve kit - Kit valvola di aspirazione
2 4094540000 Oil seal kit - Kit paraolio
3+2 1124090455 Oil seal kit+bearings kit - Kit paraolio+kit cuscinetti
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Fiac AIRBLOK40
6 Items

Data sheet

MORE INFO:
ON DEMAND ONLY
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
New

Download

Fiac AIRBLOK40 Drawing

Fiac AIRBLOK40 Drawing

Download (1.54MB)

You might also like

Comments (0)
No customer reviews for the moment.

16 other products in the same category:
