FIAC Spare Parts for Compressors 383 SILVER 5.5-7.5-10 Stand Alone
search
  • FIAC Spare Parts for Compressors 383 SILVER 5.5-7.5-10 Stand Alone
  • FIAC Spare Parts for Compressors 383 SILVER 5.5-7.5-10 Stand Alone
  • FIAC Spare Parts for Compressors 383 SILVER 5.5-7.5-10 Stand Alone
  • FIAC Spare Parts for Compressors 383 SILVER 5.5-7.5-10 Stand Alone

FIAC Spare Parts for Compressors SILVER 5.5-7.5-10 Stand Alone

€408.71
Tax included

FIAC Spare Parts for Compressors SILVER 5.5-7.5-10 Stand Alone

Fiac Genuine spare parts or replacement parts for to repair Rotary Screws Compressors SILVER 5.5-7.5-10 2005 Stand Alone - Model SILVER-A 5,5.
ITEM CODE: 4093960000
Quantity
on Demand Only Call Us Before

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

FIAC Spare Parts for Compressors SILVER 5.5-7.5-10 Stand Alone

Fiac Genuine spare parts or replacement parts for to repair Rotary Screws Compressors SILVER 5.5-7.5-10 2005 Stand Alone - Model SILVER-A 5,5.

In the following table, look for the type of the Compressor and the respective parts of the code.
SILVER 5.5-7.5-10 2005 Stand Alone

383 - SILVER 5.5-7.5-10_2005_Stand Alone
Model SILVER-A 5,5
SILVER 5,5 8-10 BAR NK 40 1/2
SILVER 7,5 8-10-13 BAR NK 40 1/2
SILVER 10 8-10-13 BAR NK 40 1/2 Pag.1
# Part Num. Description
1 7130680000 Tap - Rubinetto a sfera
2 7030040000 Washer - Rondella
3 7011670000 Screw - Vite TE 10x40
4 7098090000 Oil plug - Tappo olio
5 7423020000 Air end - Vite completa NK40
6 7085990000 Joint - Riduzione per termostato
7 7085530000 Joint - Raccordo
8 7192000000 Safety valve - Valvola di sicurezza
9 7500560000 Stretch elimintator - Pressacavo
10 1127210112 Oil filter - Filtro olio
11 7211960000 Separator filter - Filtro disoleatore
12 7230010000 Rilsan hose - Tubo Rilsan
13 7084220000 Joint - Raccordo
14 7238150000 Hose - Tubo in rame
15 7407980000 Pulley - (HP 5,5 - 7,5) - DISCONTINUED
15 7407100000 Pulley - (HP10)
16 7371520000 Belt - SPZ-X 722(HP 5,5 10bar 50Hz)
16A  7371510000 Belt - SPZ-X 812(HP 7,5 10bar 50Hz)
16B  7371500000 Belt - SPZ-X 900 (HP 10 10bar 50Hz)
16C Belt - SPZ-X772(HP 5,5 8bar 50Hz)
16D Belt - SPZ-X850 (HP 7,5 8bar 50Hz - HP10 8bar 60Hz)
16E  7371090000 Belt - SPZ-X750 (HP 7,5 13bar 50Hz)
16F  7371010000 Belt - SPZ-X950 (HP 10 8bar 50Hz)
16G Belt - SPZ-X825 (HP 10 13bar 50Hz - HP10 10bar 60Hz)
16H  7371060000 Belt - SPZ-X737 (HP 5,5 8bar 60Hz)
16I Belt - SPZ-X687 (HP 5,5 10bar 60Hz)
16L Belt - SPZ-X800 (HP 7,5 8bar 60Hz)
16M  1120013908 Belt - SPZ-X762(HP 7,5 10bar 60Hz)
16N Belt - SPZ-X720 (HP 7,5 13bar 60Hz)
16O Belt - SPZ-X772(HP 10 13bar 60Hz)
17 7408550000 Pulley - (HP 5,5 10bar 50Hz)
17A  7408230000 Pulley - (HP 7,5 10bar 50Hz)
17B  7409960000 Pulley - (HP 10 10bar 50Hz)
17C  7407900000 Pulley - (HP 5,5 8bar 50Hz)
17D  7408440000 Pulley - (HP 7,5 8bar 50Hz)
17E  7409140000 Pulley - (HP 7,5 13bar 50Hz)
17F 7407500000 Pulley - (HP 10 8bar 50Hz)
17G Pulley - (HP 10 13bar 50Hz)
17H  7407820000 Pulley - (HP 5,5 8bar 60Hz)
17I  7407800000 Pulley - (HP 5,5 10bar 60Hz)
17L 7408230000 Pulley - (HP 7,5 8bar 60Hz)
17M  7407790000 Pulley - (HP 7,5 10bar 60Hz)
17N  7408550000 Pulley - (HP 7,5 13bar 60Hz)
17O Pulley - (HP 10 8bar 60Hz)
17P Pulley - (HP 10 10bar 60Hz)
17Q Pulley - (HP 10 13bar 60Hz)
18 7380850000 Electric motor compressor - 380V÷415V 50Hz (HP 5,5)
18A  7380850000 Electric motor compressor - 380V÷415V 50Hz (HP 7,5)
18B  7380200000 Electric motor compressor - 380V÷415V 50Hz (HP 10)
18E Electric motor compressor - 208V÷240V 50Hz (HP 5,5)
18F Electric motor compressor - 208V÷240V 50Hz (HP 7,5)
19 7020250000 Nut - Dado M10
20 7011160000 Nut - Dado
21 7457030000 Screw - Vite
22 7011410000 Guide - Slitta tenditrice
23 7238210000 Screw - Vite TE M10x20 C/ROND.
24 7564470000 Thermostat - Termostato
25 7081311150 Joint - Nipplo
26 7030400000 Washer - Rondella 1/2" ALL
27 7030400000 Washer - Rondella 1/2" ALL
28 7238200000 Hose - Tubo in rame
29 7085440000 Joint - Nipplo
30 7083940000 Joint - Raccordo a resca
31 7211360000 Air filter cartridge - Cartuccia filtro aria
32 7195760000 Suction valve (See kit assembling table)
33 7196570000 Suction valve kit (See kit assembling table)
34 7194390010 Solenoid valve coil - Bobina elettrovalvola
35 7194390000 Solenoid valve - Elettrovalvola
36 7196310000 Minimum pressure valve kit (See kit assembling table)
37 7196240000 Minimum pressure valve kit+gasket (See kit assembling table)
38 7060540000 Oil seal kit+bearings kit (See kit assembling table)
39 7071320000 Oil seal kit (See kit assembling table)
40 4094060000 Filters kit - Kit filtri
44 4093960000 Maintenance kit - Kit manutenzione
42 7085990000 Joint - Raccordo
43 7084270000 Joint - Raccordo
44 7023050000 Blocking nut - Controdado
45 7085540000 Joint - Riduzione
383 - SILVER 5.5-7.5-10_2005_Stand Alone PAG.2
100 5150550008 Tank - Serbatoio 200Lt
101 7090080000 Plug - T appo
102 7090030000 Plug - T appo
103 7130170000 T ap - Rubinetto a sfera 1/4"
104 7082050000 Joint - Raccordo "T"
105 7110180000 Pressure gauge - Manometro
106 7192090000 Safety valve - Valvola di sicurezza
107 7080160000 Joint - Raccordo
108 7080160000 Joint - Raccordo
109 7230480000 Hose - Tubo in rame
110 7414090000 Electric board - Apparecchiatura elettrica (HP 5,5)
110A 7414100000 Electric board - Apparecchiatura elettrica (HP 7,5)
110B 7414110000 Electric board - Apparecchiatura elettrica (HP 10)
111 7564340000 Transformer - Trasformatore
112 7435510000 Contactor - Contattore compressore K1
113 7432530000 Contactor - Contatto ausiliario
114 Bobbin - Bobina riarmo K5
115 7432530000 Contactor - Contatto ausiliario
116 7432550000 Contactor - Contattore compressore K2
117 7433510000 Contactor - Contattore compressore K3
118 7432700000 Timer - Temporizzatore KT1
119 7550180000 Relay - Relè ausiliario K4
120 7432720000 Fuse - Fusibile F2-F3
121 7433530000 Start button - Pulsante Start
122 7500560000 Stretch eliminator - Pressacavo
123 7301330000 Pushbutton - Pulsante ST ART
124 7300340000 Pushbutton - Pulsante RESET
125 7500560000 Stretch eliminator - Pressacavo
126 7084240000 Joint - Raccordo "L"
127 7250960000 Pressure switch - Pressostato
128 7300320000 Emergency push-button - Pulsante di emergenza
129 7130170000 Tap - Rubinetto a sfera
130 7563510000 Hour meter - Contaore
134 7110400000 Pressure gauge - Manometro
132 7433410000 Green warning light - Spia verde
133 7500650000 Stretch eliminator - Pressacavo
134 7080240000 Joint - Raccordo a "L"
135 7014450000 Screw - Vite M5x50
136 5168020008 Side panel - Pannello laterale
137 5168030008 Rear panel - Pannello posteriore
138 5168040008 Upper panel - Pannello superiore
139 5168000008 Base - Base
140 5168010008 Front panel - Pannello frontale
144 7011410000 Screw - Vite
142 7517510000 Radiator - Radiatore
143 7194330000 Electrical fan - Ventilatore
144 7514030000 Electric box - Cassetta elettrica
145 7514040000 Conveyor - Convogliatore
146 7194430010 Grid - Griglia per ventola
147 7082820000 Joint - Raccordo
148 7230020000 Rilsan hose - Tubo Rilsan
149 7082830000 Joint - Raccordo
150 7081140000 Joint - Raccordo
151 7081170000 Joint - Nipplo 1/2
152 7085690000 Joint - Riduzione 1/2" MF
153 7564460000 Thermostat - Termostato olio vite NK40
383 - SILVER 5.5-7.5-10_2005_Stand Alone PAG.3
1 7196240000 Minimum pressure valve kit+gasket
2 7195760000 Suction valve - Valvola di aspirazione
3+4 7060540000 Oil seal kit+bearings kit - Kit paraolio+kit cuscinetti
4 7071320000 Oil seal kit - Kit paraolio
5 7196570000 Suction valve kit - Kit valvola di aspirazione
6 7196310000 Minimum pressure valve kit
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
SILVER 5.5-7.5-10 Stand Alone
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS APPROX.
MORE INFO:
ON DEMAND ONLY
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
New

Download

Drawing Fiac SILVER 5.5-7.5-10

Drawing Fiac SILVER 5.5-7.5-10

Download (852.26KB)
