FIAC Spare Parts for Air Compressor Pump Unit AB 415
€48.84
Tax included
FIAC Spare Parts for Air Compressor Pump Unit AB 415
FIAC Genuine Spare Parts or replacements parts for to repair components for piston Air Compressors Pump units, AB 415 - 9700003004 - data validità - da 29/04/2014.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Spare Parts for Air Compressor Pump Unit AB 415
FIAC Genuine Spare Parts or replacements parts for to repair components for piston Air Compressors Pump units, AB 415 - 9700003004 - data validità - da 29/04/2014.In the following table, look for the model of the pumping unit and the respective parts code.
| Pumping Unit AB 415 validity date - 29/04/2014 | ||
| # | Part Num. | Description |
| 1 | 9105450240 | Conrod Ab 415 |
| 2 | 1129702097 | Screw T.E. M8X20zinc. |
| 3 | 1129704092 | Screw T.E. M8X40zinc. |
| 4 | 7012110000 | Screw 0 4,2X16 UNI-6954 |
| 5 | 7011040000 | Screw M6X20 UNI-5739 |
| 6 | 7030030000 | Washer 08 UNI-6592 |
| 7 | 7012220000 | Screw MSX 25 UNI-8112 |
| 8 | 1129700531 | Screw M5X18 UNI7687 |
| 9 | 7011460000 | M6X16 TAP-TITE screw |
| 10 | 7012090000 | Screw M5X12 UNI-8112 |
| 11 | 4080070000 | Piston Ring kit |
| 12 | 1129701300 | 8.5X30X4 washer |
| 13 | 1129704077 | Washer 08 |
| 14 | 7041410000 | Seeger 015 |
| 15 | 7050110000 | Pin 015X55 |
| 16 | 7051510000 | Tab 5X7.5 |
| 17 | 7060060000 | 6205 bearing |
| 18 | 7060150000 | Bearing 6206 |
| 19 | 1127070052 | 0-ring |
| 20 | 1129701392 | O_ring |
| 21 | 1129701393 | 0_ring |
| 22 | 7071130000 | Oil seal MM 30X47X7 |
| 23 | 1127070979 | seal |
| 24 | 7079800000 | Cylinder-Valve Plate Gasket |
| 25 | 7079820000 | Valve Plate - Head Gasket |
| 26 | 1129702582 | 1/4 "M cap |
| 27 | 9700000408 | Oil sight glass |
| 28 | 7198150000 | Valve reed 9,78x48x0,25 |
| 29 | 7201010000 | They fly |
| 30 | 7210680000 | Filter element |
| 31 | 7220090000 | Piston 65MM |
| 32 | 9700002651 | Chiller |
| 33 | 9100270280 | 0-ring 130 |
| 34 | 9105450010 | Carter |
| 35 | 9105450250 | Crankshaft |
| 36 | 9105450060 | Cylinder |
| 37 | 9105450070 | Front cover |
| 38 | 9105450080 | Rear cover |
| 39 | 9105450090 | Carter cover |
| 40 | 1129101582 | Filter cover |
| 41 | 1129101583 | Filter support |
| 42 | 9105450150 | Plate Gasket AB415 Copper Th. |
| 43 | 9105450170 | Valve plate |
| 44 | 9105450180 | Head |
| 45 | 7153140000 | Air conveyor Ab 415-425-525 |
| 46 | 9700001377 | Oil Filler Neck Komplett |
| 8A | 9701192003 | WASHER D5 |
| 100 | 4231260000 | Valve plate kit |
| 101 | 9700002940 | Piston Kit |
| 102 | 4250130000 | Intake filter kit |
| 103 | 4081990000 | Gaskets kit |
| 104 | 1129702939 | screw kit |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Fiac AB415 - 9700003004
