Femi Spare Parts for Stationary Band Saws N215XL-8487020
€136.60
Tax included
Femi Spare Parts for Stationary Band Saws N215 XL-8487020
Femi Genuine spare parts or replacement parts for to repair Stationary Band Saws N215 XL - 8487020.Manual, single phase with induction motor
- Max cutting capacity Ø 175 mm - 200x75 mm
- Weight Kg 150
- Bandsaw blade mm. 2140 x19 x 0,9
- Ultra-low tension control panel 24 Volt
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Stationary Band Saws N215 XL-8487020
Femi Genuine spare parts or replacement parts for to repair Stationary Band Saws N215 XL - 8487020.
In the following table, look for the model of the Band Saw and the respective parts of the code.
| Band Saws N215 XL-8487020 | ||
| # | Part Num. | Description |
| 1 | 5130796 | STOP PLATE |
| 3 | 0147007 | HAND LEVER |
| 6 | 0147017 | HAND LEVER |
| 7 | 5182532 | COVER |
| 8 | 5152594 | VICE JAW |
| 9 | 5152593 | VICE JAW |
| 11 | 5130864 | VICE SCREW SUPPORT |
| 14 | 0152630 | ELASTIC PIN |
| 16 | 5152611 | VICE JAW |
| 17 | 5130863 | MOBILE VICE |
| 18 | 5159517 | INDEX |
| 20 | 0140059 | LEVER COVER |
| 22 | 5171040 | PIN |
| 25 | 0140073 | HANDGRIP |
| 26 | 5142057 | LEVER |
| 27 | 5171035 | BUSHING |
| 30 | 5124033 | WASHER |
| 31 | 0120708 | PLAIN WASHER |
| 34 | 5133703 | TANK BASE |
| 35 | 7113524 | ELECTRIC PUMP |
| 37 | 7130536 | ROD STOP GROUP |
| 38 | 5182533 | PUMP SUPPORT |
| 39 | 5182534 | TANK FILTER |
| 40 | 5124056 | WASHER |
| 43 | 0402905 | RIVET |
| 44 | 0124032 | PLAIN WASHER |
| 46 | 5171038 | VICE PIN |
| 47 | 0101716 | SELF-LOCKING NUT |
| 49 | 0606203 | BALL BEARING |
| 50 | 5137964 | SWIVEL SUPPORT |
| 51 | 0606306 | BALL BEARING |
| 52 | 5171039 | JOINT PIN |
| 53 | 5063036 | BUSHING |
| 60 | 5214224 | FREE WHEEL |
| 61 | 5130746 | GUIDE |
| 62 | 5001562 | SHAFT |
| 63 | 5081007 | SPRING |
| 64 | 5142058 | LEVER |
| 65 | 5100505 | BLADE TENSIONING SCREW |
| 66 | 5120661 | SPACER |
| 68 | 5122017 | SPRING CONTEINER |
| 69 | 5124030 | WASHER |
| 70 | 0064002 | BEARING FIFTH WHEEL |
| 71 | 0711528 | CAGE BEARING |
| 72 | 0140099 | BLADE TENSIONING KNOB |
| 73 | 0080260 | SPRING WASHER |
| 75 | 5222009 | SPRING DUST PROTECTION |
| 76 | 5066016 | BUSHING |
| 77 | 0801101 | MICROSWITCH |
| 78 | 5182842 | SWITCH BOX |
| 80 | 5143005 | MICROSWITCH BUTTON |
| 81 | 5142059 | LEVER |
| 82 | 5182531 | PLASTIC COVER |
| 84 | 0106120 | SELF-LOCKING RING NUT |
| 86 | 5214026 | DRIVING WHEEL |
| 87 | 0155149 | THICKNESS WASHER |
| 88 | 5130795 | WHEEL SUPPORT |
| 90 | 0606204 | BALL BEARING |
| 93 | 7213006 | GEAR GROUP |
| 94 | 0150139 | FEATHER |
| 95 | 0586200 | BALL BEARING |
| 96 | 5024118 | STATOR |
| 98 | 0606007 | BALL BEARING |
| 99 | 5124054 | SPACER |
| 100 | 5042810 | BAND SAW BODY |
| 101 | 7213010 | GEAR GROUP |
| 102 | 0731212 | CAGE BEARING |
| 103 | 0124026 | THICKNESS WASHER |
| 105 | 5850006 | BRUSHES SUPPORT |
| 106 | 1180304 | MICROSWITCH LEVER |
| 108 | 0168515 | PLASTIC CAP |
| 109 | 5133772 | COLUMN RIGHT |
| 110 | 5133773 | COLUMN LEFT |
| 113 | 5850111 | FAN WITH MAGNETIC RING |
| 131 | 0140077 | WING NUT |
| 132 | 5181858 | BLADE PROTECTION |
| 133 | 0123315 | RUBBER WASHER |
| 134 | 1855803 | COOLING LIQUID PIPE |
| 135 | 5181688 | CABLE PROTECTION |
| 138 | 5152596 | PROTECTION FIXING DEVICE |
| 139 | 7130567 | INTERNAL BEARING GROUP |
| 141 | 5050137 | HANDLE |
| 143 | 5050136 | HANDLE |
| 144 | 0802324 | SWITCH |
| 145 | 0241367 | PIPE FITTING |
| 146 | 5871058 | CABLE |
| 148 | 5154103 | CABLE LOCKING DEVICE |
| 150 | 5171037 | PROTECTION PIN |
| 153 | 0241443 | PIPE FITTING |
| 154 | 1855805 | COOLING LIQUID PIPE |
| 156 | 5142030 | LEVER |
| 159 | 5151506 | DAMPER FULCRUM |
| 161 | 5171041 | DAMPER PIN |
| 165 | 5173027 | TIE ROD |
| 166 | 5155155 | DAMPER |
| 167 | 5040010 | DAMPER BODY |
| 168 | 5124061 | WASHER |
| 169 | 5080139 | COMPRESSION SPRING |
| 170 | 5124038 | WASHER |
| 171 | 7130572 | COMPLETE DAMPER GROUP |
| 176 | 0241442 | PIPE FITTING |
| 179 | 5120638 | SPACER |
| 180 | 0600607 | BALL BEARING |
| 181 | 5100070 | SCREW |
| 182 | 5130943 | BLADE GUIDE SUPPORT |
| 183 | 0600626 | BALL BEARING |
| 185 | 0124027 | THICKNESS WASHER |
| 186 | 5130942 | MOBILE BLADE GUIDE |
| 187 | 5100069 | SCREW |
| 188 | 0063025 | BUSHING |
| 189 | 0124029 | PLAIN WASHER |
| 190 | 0147002 | HAND LEVER |
| 191 | 5181683 | SLIDING PROTECTION |
| 192 | 5181018 | BLADE CLEANER |
| 193 | 5181628 | PROTECTION |
| 195 | 5130747 | SUPPORT |
| 197 | 5181627 | PROTECTION |
| 198 | 5181017 | BLADE CLEANER |
| 200 | 5401964 | CONTROL PANEL PLATE |
| 201 | 0820010 | SPEED COMMUTATOR |
| 202 | 5137908 | CONTROL PANEL BASE |
| 203 | 5070002 | CONTROL PANEL SUPPORT |
| 204 | 0806007 | PUSH BUTTON WITH LOCK |
| 205 | 7213012 | GEAR GROUP |
| 207 | 5090119 | WHEEL GEAR |
| 210 | 0168513 | PLASTIC CAP |
| 211 | 5182545 | GEAR COVER |
| 213 | 7013626 | ROTOR |
| 214 | 5182866 | SWITCH BOX |
| 215 | 5081008 | SPRING |
| 218 | 7801103 | MOTOR BODY |
| 219 | 0112014 | MOTOR FAN |
| 220 | 5182849 | FAN COVER |
| 221 | 5182546 | SWITCH COVER |
| 223 | 0806027 | VOLTAGE COIL |
| 224 | 0811001 | MINI-CONTACTOR |
| 225 | 7820110 | BLADE TENSIONING DEVICE COVER |
| 226 | 0840202 | TRANSFORMER |
| 227 | 0810003 | MAGNETOTHERMIC SWITCH |
| 228 | 5137950 | CONTROL PANEL BASE |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi N215 XL - 8487020
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM CODE OR S/N FEMI:
- FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS
