Femi Spare Parts for Band Saw SN105XL - 8483022
€41.74
Tax included
Femi Spare Parts for Transportable Band Saw SN105XL - 8483022
We are FEMI original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Transportable Band Saw for metal SN105XL - 8483022 JOBLINE.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Transportable Band Saw SN105XL - 8483022
We are FEMI original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Transportable Band Saw for metal SN105XL - 8483022 JOBLINE.
In the following table, look for the model of the Band Saw for metal and the respective parts of the code.
| Band Saw Femi SN105XL - 8483022 JOBLINE |
||
| # | Part Num. | Description |
| 1 | 0400513 | |
| 2 | 5181623 | PROTECTION |
| 3 | ||
| 4 | 5214019 | DRIVING WHEEL |
| 5 | 0155142 | THICKNESS WASHER |
| 6 | 0600607 | BALL BEARING |
| 7 | 5120638 | SPACER |
| 8 | 0174022 | NEEDLE |
| 9 | 0129004 | INOX STEEL WASHER |
| 10 | 0590624 | BALL BEARING |
| 11 | ||
| 12 | 0311080 | EXAGONAL HEAD SCREW |
| 13 | 0606202 | BALL BEARING |
| 14 | 7213003 | GEAR GROUP |
| 15 | 0570627 | BALL BEARING |
| 16 | 0155013 | ELASTIC RING |
| 17 | 0730810 | CAGE BEARING |
| 18 | 0155136 | THICKNESS WASHER |
| 19 | 7801654 | MOTOR D80 H40 V230 Hz50 |
| 20 | 5182597 | GEAR CASE COVER |
| 21 | 0320515 | |
| 22 | 5061051 | BALL BEARING SEAT 608 D26 sp.2 mm |
| 23 | 5024123 | STATOR – FIELD D80 H40 V230 Hz50 |
| 24 | 7013162 | ARMATURE ASSY FOR MOTOR D80 H40 V230 Hz50 |
| 25 | 5850115 | CARBON BRUSH WITH INSERT FOR MOTOR D80 H40 |
| 26 | 0816022 | INDUCTANCE FOR MOTOR D80 H40 |
| 27 | ||
| 28 | 5850010 | CARBON BRUSH HOLDER FOR MOTOR D80 H40 V230 Hz50 |
| 29 | 5112024 | MOTOR FAN |
| 30 | 0155140 | THICKNESS WASHER |
| 31 | 5182816 | MOTOR COVER |
| 32 | 0420677 | |
| 33 | 0102106 | CAP NUT |
| 34 | 0120206 | WASHER |
| 35 | 0123004 | NYLON WASHER |
| 36 | 5181869 | |
| 37 | 0120706 | PLAIN WASHER |
| 38 | 0730609 | CAGE BEARING |
| 39 | 0147000 | HAND LEVER |
| 40 | 0400601 | |
| 41 | 7213007 | GEAR GROUP |
| 42 | 7213001 | GEAR GROUP |
| 43 | 0816021 | THERMOSTAT FOR MOTOR D80 H40 |
| 44 | ||
| 45 | ||
| 46 | ||
| 47 | 5154103 | CABLE LOCKING DEVICE |
| 48 | 0400514 | |
| 49 | 0410657 | |
| 50 | 5181016 | BLADE CLEANER |
| 51 | 5130957 | BEARING FIXING SUPPORT |
| 52 | 5100064 | SCREW |
| 53 | 5100065 | SCREW |
| 54 | 0400604 | SCREW |
| 55 | 0179901 | NEEDLE |
| 56 | 5001572 | SECONDARY SHAFT NG |
| 57 | 5137914 | FREE WHEEL HOLDER NG |
| 58 | 0155152 | THICKNESS WASHER |
| 59 | 0596002 | BALL BEARING |
| 60 | 5120663 | SPACER |
| 61 | 0380615 | |
| 62 | 5124062 | WASHER |
| 63 | ||
| 64 | 5214225 | FREE WHEEL |
| 65 | 0400515 | |
| 66 | 5130734 | WHEEL GUIDE |
| 67 | 0124026 | THICKNESS WASHER |
| 68 | 5081005 | SPRING |
| 69 | 0100108 | |
| 70 | 0140074 | HANDWHEEL |
| 71 | 5100507 | BAND TENSIONER STUD |
| 72 | 5081021 | MOLLA A TAZZA DIN 2093 D.9,2X18X1 – 12 PZ |
| 73 | 5042877 | BANDSAW ARM 1330 YELLOW RAL 1018 BUCC |
| 74 | ||
| 75 | ||
| 76 | 5142070 | LEVER |
| 77 | 5181843 | SLIDING PROTECTION |
| 78 | 0129004 | INOX STEEL WASHER |
| 79 | 5870847 | CABLE |
| 80 | ||
| 81 | 0420465 | |
| 82 | 5130932 | BLADE GUIDE |
| 83 | 0120706 | PLAIN WASHER |
| 84 | 0147000 | HAND LEVER |
| 85 | 0802317 | SWITCH |
| 86 | 5050117 | HANDLE |
| 77 | 5181843 | SLIDING PROTECTION |
| 78 | 0129004 | INOX STEEL WASHER |
| 79 | 5870847 | CABLE |
| 80 | ||
| 81 | 0420465 | |
| 82 | 5130932 | BLADE GUIDE |
| 83 | 0120706 | PLAIN WASHER |
| 84 | 0147000 | HAND LEVER |
| 85 | 0802317 | SWITCH |
| 86 | 5050117 | HANDLE |
| 87 | 5182520 | SWITCH COVER |
| 88 | 802314 | SWITCH |
| 89 | 7890101 | CLAMP GROUP |
| 90 | 0400400 | |
| 91 | 0420682 | |
| 92 | 0802606 | SWITCH ON/OFF |
| 93 | ||
| 94 | 0816004 | RADIO INTERFERENCE SUPPRESSOR |
| 95 | 5870886 | CABLE |
| 96 | 5154501 | CABLE LOCKING DEVICE |
| 97 | 5182840 | SWITCH BOX |
| 98 | 0063027 | BUSHING |
| 99 | 5080116 | SPRING |
| 100 | 0155143 | THICKNESS WASHER |
| 101 | 0147002 | HAND LEVER |
| 102 | 7133629 | SWIVEL SUPPORT GROUP |
| 103 | 0120710 | PLAIN WASHER |
| 104 | 0100410 | |
| 105 | 102110 | CAP NUT |
| 106 | 5171043 | LOCKING PIN |
| 107 | 0140076 | HANDWHEEL |
| 108 | 0222021 | O-RING SEAL |
| 109 | 0151409 | SNAP RING |
| 110 | 402905 | RIVET |
| 111 | 5401319 | GRADUATE PLATE |
| 112 | 0320610 | |
| 113 | 5124029 | ECCENTRIC |
| 114 | 7130535 | ROD STOP ASS'Y |
| 115 | 0401001 | SCREW |
| 116 | 5138041 | |
| 117 | 0320816 | |
| 118 | 0120208 | |
| 119 | 0150701 | CYLINDRIC PIN WITH SLOT |
| 120 | ||
| 121 | 0101405 | |
| 122 | 0080261 | SPRING WASHER |
| 123 | 0063042 | SLEEVE |
| 124 | 7130680 | COMPLETE VICE |
| 125 | 0400520 | |
| 126 | ||
| 127 | 0410613 | |
| 128 | 0100106 | |
| 129 | ||
| 130 | 5133637 | ANGULAR PLASTIC FOOT |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi SN105XL - 8483022
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM CODE OR S/N FEMI:
- FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS
