Castor Spare Parts for Brushcutter POWER 41 F (2007) 184122001
CASTOR authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter POWER 41 F (2007) 184122001.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
| ST. S.P.A. BRUSHCUTTER POWER 41 F (2007) 184122001 pag.1 | ||
| # | Part Num. | Description |
| 1 | 2135040 | Screw |
| 2 | 4540800 | Carter Support Transmission |
| 3 | 2432030 | Nut |
| 4 | 2132500 | Screw |
| 5 | 2312120 | Washer |
| 5 | 3211420 | Faston (Flex) |
| 6 | 3745530 | Grommet |
| 7 | 2653210 | Screw |
| 8 | 3654040 | Clutch Spring |
| 9 | 3L3660430/1 | Clutch Arm |
| 10 | 2321230 | Washer |
| 11 | 2135060 | Screw |
| 12 | 2321150 | Washer |
| 13 | 3211015 | Electronic Coil |
| 14 | 3211080 | Electronic Coil Cable |
| 15 | 3782040 | Cable Sleve |
| 16 | 3211415 | Earth Cable |
| 17 | 3L4251480/1 | Flywheel |
| 18 | 2670120 | Nut |
| 19 | 2135050 | Screw |
| 20 | 3121070 | Seal ring |
| 21 | 3745130 | Grommet |
| 22 | 8521010 | Motor Housing |
| 23 | 3151010 | Flywheel Key |
| 25 | 3116100 | Needle Bearing |
| 27 | 8250840 | Crankshaft |
| 28 | 3112240 | Needle Bearing |
| 29 | 3750280 | Cable guide |
| 30 | 3724050 | Engine Crankcase Gasket |
| 31 | 2432040 | Nut |
| 32 | 2123100 | Screw |
| 33 | 3654050 | Spring |
| 34 | 3749570 | Starter Link |
| 35 | 8540810 | Sterter Cup |
| 36 | 2135180 | Screw |
| 37 | 4563663 | Cylinder Cover Red |
| 38 | 4122120 | Muffler |
| 41 | 3724340 | Muffler gasket |
| 42 | 3744850 | Spark Plug Cap |
| 43 | 3657530 | Spark Plug terminal |
| 44 | 3210024 | Spark Plug |
| 45 | 2135150 | Screw |
| 46 | 3724260 | Cylinder gasket |
| 47 | 3123150 | Piston Ring |
| 48 | 3158260 | Piston pin |
| 49 | 3356050 | Circlip |
| 50 | 8541120 | Piston assembly Ø 38 |
| 51 | 8541110 | Cylinder - Piston assembly |
| 52 | 4253290 | Fuel Intake |
| 53 | 8745541 | Hose rubber assembly |
| 54 | 8741370 | Fuel Cap Set |
| 55 | 4252470 | Tank Assembly |
| 56 | 4122180 | Motor Support Flange |
| 57 | 2330020 | Washer |
| 58 | 2135010 | Screw |
| 59 | 2330060 | Washer |
| 60 | 2412180 | Nut |
| 61 | 2112310 | Screw |
| 62 | 8724340 | Gaskets Set |
| ST. S.P.A. POWER 41 F (2007) 184122001 pag.2 | ||
| 1 | 3724360 | Cylinder Manifold Gasket |
| 2 | 3750410 | Intake manifold - DISCONTINUED |
| 3 | 2670280 | Nut |
| 4 | 2135050 | Screw |
| 5 | 3724400 | Carburetor Manifold Gasket |
| 6 | 3785070 | Thermal Spacer |
| 7 | 1L4353270/1 | Carburetor |
| 8 | 8750390 | Air Filter Support |
| 9 | 2312090 | Washer |
| 10 | 2135250 | Screw |
| 11 | 3781600 | Air filter |
| 12 | 4563673 | Filter Cover Red |
| 13 | 2123100 | Screw |
| 14 | 3613420 | Washer |
| 15 | 4562220 | Starter Pulley |
| 16 | 3723640 | Disc For Spring Starter |
| 17 | 4611480 | Starter Spring |
| 18 | 8563650 | Starter Carter |
| 19 | 2135040 | Screw |
| 20 | 3784030 | Starter rope |
| 21 | 3750067 | Starter handle |
| 22 | 3745530 | grommet |
| 23 | 4252680 | Starter assembly |
| 24 | 3744870 | Primer |
| 25 | 4353150 | Carburettor Diaphragm-Seal Kit |
| 30 | 2461030 | Nut |
| ST. S.P.A. POWER 41 F (2007) 184122001 pag.3 | ||
| 1 | 4252360 | Backpack set |
| 2 | 8122080 | Backpack Frame Assembly |
| 3 | 4612280 | Motor Support Plate |
| 4 | 3112170 | Ball bearing |
| 5 | 4612020 | Bearing flange |
| 6 | 2112260 | Screw |
| 7 | 2312090 | Washer |
| 8 | 2432040 | Nut |
| 9 | 3654360 | Spring |
| 10 | 2132110 | Screw |
| 11 | 2312130 | Washer |
| 12 | 2432030 | Nut |
| 13 | 4252430 | Elastic Cord |
| ST. S.P.A. POWER 41 F (2007) 184122001 pag.4 | ||
| 1 | 3L8562620/1 | Rear Handle Assembly |
| 2 | 2123030 | Screw |
| 3 | 2123100 | Screw |
| 4 | 3743475 | Safety Lever |
| 5 | 3654300 | Spring |
| 7 | 3743465 | Throttle lever |
| 8 | 1L3654270/1 | Spring |
| 9 | 3612710 | Stop Plate |
| 10 | 2123070 | Screw |
| 11 | 3749270 | Knob |
| 12 | 3750290 | Reduction |
| 13 | 123066004/0 | Throttle Cable |
| 14 | 3782680 | Cables Sleve |
| 15 | 8211390 | Pair of Stop Cables |
| 16 | 8563600 | Front Handle Assembly |
| 17 | 2135050 | Screw |
| 18 | 2312090 | Washer |
| 19 | 2412030 | Nut |
| 23 | 3614980 | plate |
| 24 | 2135160 | Screw |
| 25 | 4252390 | Transmission Tube Assembly |
| 26 | 8630150 | Transmission Shaft Assembly |
| 27 | 3L4121861/1 | Clutch Drum assembly |
| 28 | 8540910 | Transmission Support Assembly |
| 29 | 3112170 | Ball bearing |
| 30 | 3353080 | Seeger |
| 31 | 3642420 | Pin |
| 32 | 3654170 | Spring |
| 33 | 3351050 | Lock Pin |
| 34 | 3642430 | Hub |
| 35 | 3L4122110/1 | Flexible shaft |
| 36 | 1L4253990/1 | Flexible Shaft J |
| 37 | 3749310 | Cable Stop Band |
| 38 | 3750270 | Handle Fixing Ring |
| 39 | 3643220 | Threaded Sleeve X Flex Ø28 |
| 40 | 3721540 | O-Ring |
| 41 | 3314040 | Centering Pin |
| 42 | 3L8563570/1 | Safety guard assembly |
| 43 | 2135030 | Screw |
| 44 | 3615000 | Wire Knife |
| 45 | 2312150 | Washer |
| 46 | 2432040 | Nut |
| 47 | 2312150 | Washer |
| 48 | 2135060 | Screw |
| 53 | 3642290 | Flex Coupling Fitting Ø28 Mm |
| ST. S.P.A. POWER 41 F (2007) 184122001 pag.5 | ||
| 1 | 3L4252790/1 | Head Assembly Ø28 Mm - SUBSTITUITED BY TECH636124+636131 |
| 7 | 2135050 | Screw |
| 8 | 2653090 | Screw |
| 9 | 2653460 | Screw |
| 15 | 3121170 | Sealing ring |
| 16 | 3641700/1 | Head Collar DC D = 26 05 |
| 17 | 3641640 | Upper ring |
| 18 | 3612640 | Lower ring |
| 19 | 4560610 | Fixed Cup |
| 22 | 4611880 | Disc 4 Tips |
| 31 | 4353240/1 | 2 Wire Head |
