Castelgarden Spare Parts for Hedge Trimmer XHJ 550
€1.88
Tax included
Castelgarden Spare Parts for Hedge Trimmer XHJ 550
Distribution and Sale at attractive prices of Castelgarden Original Spare Parts. We guarantee low prices and a professional Licensed Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue fo Hedge Trimmer Castelgarden XHJ 550 - 252900003/2010.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Castelgarden Spare Parts for Hedge Trimmer XHJ 550
Distribution and Sale at attractive prices of Castelgarden Original Spare Parts. We guarantee low prices and a professional Licensed Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue fo Hedge Trimmer Castelgarden XHJ 550 - 252900003/2010.
In the following table, look for the model of the Chaisaw and the respective parts of the code.
| Hedge Trimmer Castelgarden XHJ 550 252900003/10 pag.1 | ||
| Pos. | Code | Descrition |
| 1 | 123120012/0 | Nut |
| 2 | 123878109/0 | Screw |
| 5 | 183082003/0 | Starter Cup |
| 7 | 123880014/0 | Flywheel - Obsolete code Replaced by 118802744/0 + 123020033/1 |
| 8 | 123878110/0 | Screw |
| 9 | 123657017/0 | Washer |
| 10 | 123657013/0 | Washer |
| 11 | 119035164/0 | Seal Ring |
| 12 | 112610002/0 | Snap Ring |
| 13 | 123685020/0 | Crank Case |
| 14 | 114215221/0 | Ball Bearing |
| 15 | 123020033/1 | Crankshaft |
| 17 | 123280077/0 | Crankcase Gasket |
| 18 | 123685021/0 | Crank Case |
| 19 | 119035165/0 | Seal Ring |
| 20 | 123657019/0 | Washer |
| 21 | 123445268/0 | Hub |
| 22 | 123657020/0 | Washer |
| 23 | 183215010/0 | Clutch Ass.Y |
| 26 | 123878111/0 | Screw |
| 27 | 123065045/0 | Spark Plug Cable |
| 30 | 123760006/0 | Piston Pin |
| 31 | 123044016/0 | Electronic Coil - Euro 1 |
| 32 | 123160063/0 | Spacer |
| 33 | 123652505/0 | Washer |
| 34 | 123235008/0 | Needle Bearing |
| 35 | 123202006/0 | Washer, Piston Pin | Circlip |
| 36 | 183590007/0 | Piston Assy |
| 37 | 123590012/0 | Piston |
| 38 | 123204016/0 | Piston Ring |
| 39 | 123280078/0 | Cilynder Gasket |
| 40 | 123878112/0 | Screw |
| 41 | 183740020/0 | Muffler |
| 42 | 123280079/0 | Muffler Gasket |
| 43 | 123600078/0 | Guard |
| 44 | 3210024 | Spark Plug |
| 45 | 123071023/0 | Cilynder |
| 46 | 123280080/0 | Intake Manifold Gasket |
| 47 | 123120013/0 | Nut |
| 48 | 123073518/0 | Intake Manifold |
| 49 | 123878113/0 | Screw |
| 50 | 123600079/0 | Grommet |
| 51 | 123600080/0 | Cylinder Cover |
| 52 | 123280081/0 | Carburetor Gasket |
| 53 | 123054036/0 | Carburetor |
| 54 | 123040005/0 | Air Cleaner Base |
| 55 | 123878114/0 | Screw |
| 56 | 123220017/0 | Air Filter |
| Hedge Trimmer Castelgarden XHJ 550 252900003/10 pag.2 | ||
| 1 | 123300014/0 | Front Handle |
| 2 | 123878121/0 | Screw |
| 3 | 118801430/0 | Muffler Cover,Grey |
| 4 | 123430606/0 | Spring |
| 5 | 123657022/0 | Washer |
| 6 | 123657017/0 | Washer |
| 7 | 123878120/0 | Screw |
| 8 | 123784008/0 | Case |
| 9 | 123430607/0 | Spring |
| 10 | 123790023/0 | Spring Cap, Black |
| 11 | 123878121/0 | Screw |
| 12 | 123109588/0 | Cover |
| 13 | 118801432/0 | Knob |
| 14 | 123700065/0 | Left Handgrip substituted by 118804986/0 |
| 15 | 118801433/0 | Spring |
| 16 | 123315099/0 | Lever |
| 17 | 118801435/0 | Safety Lever,Blue |
| 18 | 123430609/0 | Spring |
| 19 | 118801437/0 | Throttle Lever, Blue |
| 20 | 123700066/0 | Right Handgrip |
| 21 | 123303007/0 | Switch |
| 22 | 123202008/0 | Retainer |
| 23 | 123878115/0 | Screw |
| 24 | 123657023/0 | Grommet |
| 25 | 123044223/0 | Bushing |
| 26 | 123878124/0 | Screw |
| 27 | 123733006/0 | Fuel Tank |
| 27A | 123733006/0-Assy | Fuel Tank Assy |
| 28 | 123275031/0 | Grommet |
| 29 | 118801439/0 | Fuel Tank Cap |
| 36 | 183520009/0 | Intake Filter |
| 37 | 123867028/0 | Tube |
| 38 | 123044008/0 | Electronic Coil |
| 39 | 123878122/0 | Screw |
| 40 | 123867029/0 | Tube |
| 41 | 123275032/0 | Grommet |
| 42 | 118801440/0 | Starter Handle |
| 42A | 118804986/0 | Handle Assy XHJ 550 |
| 43 | 123234007/0 | Starter Cord |
| 45 | 183058040/0 | Starter Ass.Y |
| 46 | 123430610/0 | Starter Spring |
| 47 | 123604013/0 | Starter Pulley |
| 48 | 112728445/0 | Screw |
| 49 | 118801443/0 | Black Cylinder Cover |
| 49 | 123106038/0 | Red Cylinder Cover |
| 50 | 112735654/0 | Screw |
| 51 | 118801446/0 | Black Cylinder Cover |
| 51 | 123106040/0 | Red Cylinder Cover |
| 52 | 183065030/0 | Spark Plug Cable |
| 53 | 118801447/0 | Throttle Cable |
| Hedge Trimmer Castelgarden XHJ 550 252900003/10 pag.3 | ||
| 1 | 123050010/0 | Clutch Drum Assy |
| 2 | 123657013/0 | Washer |
| 3 | 123657017/0 | Washer |
| 4 | 123878115/0 | Screw |
| 5 | 123685022/0 | Upper Case |
| 6 | 123657018/0 | Washer |
| 7 | 123657021/0 | Washer |
| 8 | 123878116/0 | Screw |
| 9 | 123280082/0 | Crankcase Gasket |
| 10 | 123208418/0 | Flange - DISCONTINUED |
| 11 | 112379520/0 | Grease Dispenser |
| 12 | 114215222/0 | Ball Bearing |
| 13 | 123878117/0 | Screw |
| 14 | 112610003/0 | Snap Ring |
| 15 | 123570052/0 | Pinion |
| 16 | 114215223/0 | Bearing |
| 17 | 123664000/0 | Gear Assy |
| 18 | 123041502/0 | Connecting Rod |
| 19 | 123753003/0 | Pin |
| 21 | 123685023/0 | Lower Case |
| 22 | 123878081/0 | Screw |
| 23 | 123280083/0 | Gasket |
| 24 | 123878118/0 | Screw |
| 25 | 123208419/0 | Plate |
| 26 | 123878113/0 | Screw |
| 27 | 123294006/0 | Blade Holder |
| 28 | 123044222/0 | Bushing |
| 29 | 123305004/0 | Blade |
| 30 | 123120014/0 | Nut |
| 31 | 123600081/0 | Blade Guard |
| 32 | 123294007/0 | Blade Holder |
| 33 | 123208420/0 | Bracket |
| 34 | 123085002/0 | Blade Cover |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Castelgarden websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Castelgarden brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
