Lavor Original Parts for Pressure Cleaner PLANET 160 - 81100015C
€6.84
Tax included
Lavor Original Parts for Pressure Cleaner PLANET 160 - 81100015C
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner PLANET 160 230-240~50/60 -G/GR- TS EU +SP.ROT.+L25 - 81100015CFix Your Pressure Cleaner. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner PLANET 160 - 81100015C
Fix Your Cold Water High Pressure Cleaner PLANET 160 230-240~50/60 -G/GR- TS EU +SP.ROT.+L25 - 81100015C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| 81100015C - IDRO PLANET 160 230-240~50/60 -G/GR- TS EU +SP.ROT.+L25 Pag.1 | ||
| # | Part Num. | Description |
| 0 | R50010832C | MTP.SP.PT'03 230/50 6'35 TS 14.5KG ASP.-TEST.T.FIL.S.PL. (8850) |
| 0 | R50110274 | ASS.SERBATOIO SPACE +TAPPO |
| 001 | 3.401.0178 | SWITCH 0/1 BLACK BOTTON IP55 12/10 |
| 002 | 5.011.0345 | ASSEMBLY FRONTAL COVER PLANET -LAVOR- (GREY/YELLOW) |
| 003 | 4.008.1149 | BLACK CAP FOR ELECTRICAL BOX STORM II (P80.0425) |
| 004 | 4.008.0721 | DX MOTOR CONVEYER |
| 005 | 4.012.0235 | CABLE H05VV-F 2X1,5 5,4MT SCHUKO PLUG |
| 006 | 4.008.2029 | GREY HANDLE SPACE FOR HOSE REEL RAL.7016 (PANT.432C) |
| 007 | 4.008.1484 | BLACK HALF HOSE SIDE REEL WITH PIN RAL.9011 020567/020561 (80007259) |
| 008 | 4.008.1483 | BLACK HALF LEVER SIDE REEL RAL.9011 FOR 020567/020561(80007168) |
| 009 | 5.011.0346 | KIT GREY HANDLE FOR SPACE/IKON W/HOSE REEL |
| 010 | 5.011.0274 | TANK + CAP (SPACE) |
| 011 | 4.008.1975 | YELLOW BACK ACCESSORY HOLDER SPACE (PANT.108C) |
| 012 | 4.008.1773 | GREY WHEEL WITH BLACK COAT SPACE |
| 013 | 4.013.0242 | GREY BACK CABINET FOR SPACE RAL.7016 (PANT.432C) (P80.0612) |
| 014 | 4.408.0008 | SUPPORT PAD |
| 015 | 5.001.0832C | MOTORPUMP PT'03 230/50 TS W/THERM.-SUCTION 6'35 THREAD CAPS HEAD (8850) |
| 016 | 4.008.0031 | INLET WATER FILTER H2O D.16 CONICAL |
| 017 | 7.100.2074 | MANUAL SPACE + CE LAVOR 27L A5 16F |
| 018 | 6.001.0130 | GUN S'09 W/INTEGRAL QUICK JOINT (GREY TRIGGER RAL.7046) |
| 019 | 4.018.0096 | HOSE 1/4 180BAR L=8000 M22x1,5 D.15-RAPID FIX |
| 020 | 6.002.0361 | LANCE S'12 WITHOUT NOZZLE HEAD + NOZZLE CLEANING PIN |
| 021 | 6.002.0638 | NOZZLE HEAD LANCE S'12 D.1,025 (BLACK) ADJUST.FAN JET W/QUICK COUPLING |
| 022 | 6.002.0346 | ROTOX NOZZLE HEAD LANCE S'12 D.1,025 WITH QUICK COUPLING |
| 023 | 6.002.0634 | SOAP HEAD LANCE S'12 W/QUICK COUPLING |
| 024 | 3.100.0082C | BLACK QUICK COUPLING INLET CONNECTOR (THREAD=9.5) |
| 025 | 3.601.0035 | ROTATING HYDRO BRUSH W/HANDLE |
| 026 | 3.601.0111 | YELLOW FLOOR BRUSH L25 D.1,1 W/EXTENSION |
| 81100015C - IDRO PLANET 160 230-240~50/60 -G/GR- TS EU +SP.ROT.+L25 Pag.2 | ||
| 001 | 4.008.1521 | BLACK PLUG FOR TANK -RAL.9011- (80007138) |
| 002 | 4.008.1776 | NEUTRAL TANK SPACE |
| 81100015C - IDRO PLANET 160 230-240~50/60 -G/GR- TS EU +SP.ROT.+L25 Pag.3 | ||
| 0 | R50090997C | GRUPPO C.GUIDA C/TS 14.5KG-ASP.+TEST.TAPPI FIL. PT'03-TPAV |
| 001 | 5.009.0924 | 8850 MOTOR 230/50 W/CAPACITOR-THERMAL 17AM-D 140G |
| 002 | 6.005.0180 | KIT 166 FOOTSTEP BEARING 3047 PT' 03-SD |
| 003 | 4.007.0205 | PIN 10X70 |
| 004 | 5.009.0946 | 6'35 WOBBLE PLATE ASSEMBLY W/PLASTIC INSERT+RING GEAR Z 50 |
| 005 | 4.007.0328 | THRUST BEARING 35X55X12 PT'03 |
| 006 | 5.009.0997C | BODY GUIDE+HEAD(TPAV) W/TS 14.5KG-SUCT.-THREAD CAPS-PL.CHECK VALVE SEAT |
| 81100015C - IDRO PLANET 160 230-240~50/60 -G/GR- TS EU +SP.ROT.+L25 Pag.4 | ||
| 0 | R50070281C | CORPO GUIDA PT'03 C/TS 14.5KG-ASP. |
| 0 | R50080298C | TESTATA PT'03 (TPAV) D.12 C/TAPPI FIL.ALL. |
| 001 | 5.007.0281C | PISTON BODY GUIDE PT'03 W/TS 14.5KG-SUCTION |
| 002 | 6.005.0282 | KIT 257 O-RING SEAL |
| 003 | 5.008.0298C | PT'03 HEAD (TPAV) D.12 W/ALUM.THREAD CAPS |
| 81100015C - IDRO PLANET 160 230-240~50/60 -G/GR- TS EU +SP.ROT.+L25 Pag.5 | ||
| 001 | 5.009.1022 | COMPLETED VALVE TS PT'03 CABLE L=530 SPRING 14.5KG (WHITE FASTON COVER) |
| 002 | 6.005.0183 | KIT 169 LW INJECTOR 1,7 |
| 002 | 6.005.0277 | KIT 252 |
| 003 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 004 | 6.005.0226 | KIT 209 O-RING |
| 005 | 4.005.0263C | PISTON BODY GUIDE PT'03 WITH SUCTION VALVE |
| 005 | 4.008.1176 | GASKET PISTON BODY GUIDE-HEAD PT'03 29.7X12.9X2.7 |
| 006 | 6.005.0181 | KIT 167 LW PISTON |
| 81100015C - IDRO PLANET 160 230-240~50/60 -G/GR- TS EU +SP.ROT.+L25 Pag.6 | ||
| 001 | 6.005.0315 | KIT 287 SUCTION/DELIVERY VALVE+ BRASS THREAD CAPS PT'03 |
| 002 | 4.005.0302 | PT'03 HEAD WITH THREAD FOR VALVE CAPS (TPAV) |
| 003 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
| 004 | 3.201.0020 | WATER SEAL 12X18X5 |
