Telwin Spare Parts for Flux Welding Mastermig 232 Duplex
€7.37
Tax included
Telwin Spare Parts for Flux Welding Mastermig 232 Duplex
We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for welding machine Flux and Mig-mag type : Mastermig 232 Duplex.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Spare Parts for Flux Welding Mastermig 232 Duplex
We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for welding machine Flux and Mig-mag type : Mastermig 232 Duplex.In the following table, look for the model of the welding machine and theirs spare parts codes.
| MASTERMIG 232 DUPLEX 230-400V cod.821067 Pag.1 | ||
| 1 | CHANGING VOLTAGE CARD | 112165 |
| 2 | RECTIFIER PROTECTION | 112182 |
| 3 | RECTIFIER | 112315 |
| 4 | POTENTIOMETER | 112363 |
| 5 | POTENTIOMETER - 113574 | 112380 |
| 6 | KNOB | 121394 |
| 7 | SWITCH | 121473 |
| 8 | CONTACTOR | 122459 |
| 9 | YELLOW PILOT LAMP | 122594 |
| 10 | ELECTRO-VALVE | 122682 |
| 11 | SWITCH | 122725 |
| 12 | THERMOSTAT | 122796 |
| 13 | SWITCH | 122826 |
| 14 | FUSE | 122879 |
| 15 | CABLE 16 MMQ 3 M - 25 | 123437 |
| 16 | MAINS CABLE 4G2.5 3 M | 132039 |
| 17 | FAN | 152054 |
| 18 | FAN MOTOR | 152110 |
| 19 | WIRE FEED MOTOR | 153033 |
| 20 | TRANSFORMER | 169754 |
| 21 | AUXILIARY TRANSFORMER | 164991 |
| 22 | REACTANCE | 169370 |
| 23 | TORCH CONNECTION PROTECTION | 312105 |
| 24 | REEL HANDWHEEL | 312137 |
| 25 | HINGE SET | 312382 |
| 26 | REEL | 322081 |
| 27 | SPACER | 322180 |
| 28 | WHEEL + SWIVEL SUPPORT | 322187 |
| 29 | HANDLE | 322590 |
| 30 | FRAME | 322736 |
| 31 | WHEEL | 322772 |
| 32 | WHEEL CAP | 322773 |
| 33 | COVER | 322814 |
| 34 | SWITCH KNOB SET | 323101 |
| 35 | WHEELS AXLE | 422020 |
| 36 | ARGON GAS BOTTLE IT ADAPTOR | 432036 |
| 37 | REEL SPRING | 452057 |
| 38 | FRONT PANEL | 642133 |
| 39 | TORCH HOOK | 644444 |
| 40 | BACK PANEL | 645485 |
| 41 | DIAPHRAGM | 645487 |
| 42 | BOTTOM | 645488 |
| 43 | BOTTLEHOLDER BRACKET | 645490 |
| 44 | WIRE FEEDER SUPPORT | 645491 |
| 45 | DOOR | 651164 |
| 46 | TOLEDO 250 WORK CLAMP 250A | 712030 |
| 47 | SOCKET DX 25 | 712035 |
| 48 | PLUG DX 25 | 712039 |
| 49 | GAS REGULATOR 2 MANOMETERS | 722119 |
| 50 | FEED ROLL D. 0,6-0,8 MM FE | 722225 |
| 51 | FEED ROLL D. 0,8-1 MM FE | 722227 |
| 52 | WIRE FEED ASSY | 723198 |
| 53 | ROLLERFIXING SCREW | 742397 |
| 54 | WIRE GUIDE INLET | 742064 |
| 55 | ADAPTER | 742166 |
| 56 | MT15 MIG TORCH 3 M 220 A | 742180 |
| 57 | FEED ROLL D. 0,8-1 AL | 742304 |
| 58 | LEFT ANCHOR FOR PRESSURE ROLLER | 742307 |
| 59 | RIGHT ANCHOR FOR PRESSURE ROLLER | 742308 |
| 60 | MOTOR DRIVE GEAR | 742348 |
| 61 | GEAR | 742495 |
| 62 | FEEDER TORCH CONNECTION | 723163 |
| 63 | WIRE GUIDE HOSE | 722525 |
| 64 | HANDLE KIT | 980082 |
| 65 | COVER KIT | 980866 |
| 66 | DOOR KIT | 980918 |
| 67 | TIMER CONTROL MODULE KIT | 981059 |
| 68 | GAS HOSE KIT | 990097 |
| 69 | REEL KIT | 990264 |
| 70 | KIT CABLE BUSHING + RING NUT | 990046 |
| Torcia MASTERMIG 232 DUPLEX 230-400V cod. 821067 Pag.2 | ||
| 1 | RING NUT | 722007 |
| 2 | LINER NUT | 722013 |
| 3 | SWAN NECK DIFFUSER | 722305 |
| 5 | NOZZLE SPRING | 722319 |
| 6 | DIFFUSER INSULATION | 722326 |
| 7 | TORCH HOLDER | 742172 |
| 8 | CONTACT TIP D. 0,8 MM FE | 722416 |
| 8 | CONTACT TIP D. 0,6 MM FE | 722415 |
| 10 | CYLINDRICAL NOZZLE | 722149 |
| 10 | CONICAL NOZZLE | 722423 |
| 11 | WIRE GUIDE HOSE D. 1-1,2 MM 3 M | 722689 |
| 11 | WIRE GUIDE HOSE D. 0,6-0,8 MM 3 M | 722437 |
| 13 | TORCH ASSY | 722441 |
| 14 | TORCH CONNECTION | 742175 |
| 15 | TORCH RING NUT | 742171 |
| 16 | TORCH CONNECTION | 722325 |
| 17 | TORCH CONNECTION INSULATION | 722693 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
MASTERMIG 232 DUPLEX - 821067
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM OR S/N CODE TELWIN:
- TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
