Lavor Original Parts for Pressure Cleaner Idro Vertigo 28 Plus
€14.81
Tax included
Lavor Original Parts for Pressure Cleaner Idro Vertigo 28 Plus
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner 80470016 - Idro Vertigo 28 Plus 230-240/50 -G/GR- TS EU C/AVV. LWS.Fix Your Pressure Cleaner. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner Idro Vertigo 28 Plus
Fix Your Cold Water High Pressure Cleaner 80470016 - Idro Vertigo 28 Plus 230-240/50 -G/GR- TS EU C/AVV. LWS. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| 80470016 - IDRO VERTIGO 28 PLUS 230-240/50 -G/GR- TS EU C/AVV. LWS pag.1 | ||
| # | Part Num. | Description |
| 0 | R50010812 | MOTOP.PT'03 125H110ALL 230-240/50 D.12-ACC. 12' TS IN.1,7 TEST.OTT. |
| 0 | R50090770 | ASSIEME SEMIAVVOLG.C/OCCHIELLO'11 +TUBO mt.8 |
| 0 | R50120475 | CORREDO VERTIGO 28 PLUS C/AVVOLG. (80470016) |
| 001 | 4.008.1467 | GREY FRONTAL COVER VERTIGO -RAL.7005- W/TAMPOPRINTING LAVOR |
| 002 | 4.008.1491 | SILVER LATERAL LEFT SHELL VERTIGO (PAINTED) |
| 003 | 4.008.1490 | SILVER LATERAL RIGHT SHELL VERTIGO (PAINTED) |
| 004 | 4.008.1429 | GREY LOW FRONTAL COVER VERTIGO-RAL.9006- |
| 005 | 4.013.0640 | BLACK FRONT SIDE CABINET VERTIGO |
| 006 | 4.008.1432 | BLACK SWITCH KNOB |
| 007 | 3.401.0225 | ROTARY SWITCH TWO GEARS BIPOLAR 16A (0-1) W/PIN 15 |
| 008 | 3.404.0095 | CAPACITOR 55mF 450V D.50X94 W/FASTON M |
| 009 | 4.008.1437 | BLACK CAP FOR ELECTRICAL BOX VERTIGO |
| 010 | 4.008.0922 | COVER FOR MOTOR FAN (MOTOR'96) |
| 011 | 4.008.1425 | BLACK HANDLE FOR VERTIGO |
| 012 | 4.008.1599 | GREY CABLE REEL VERTIGO -RAL.7005- |
| 014 | 4.008.1431 | TANK FOR VERTIGO |
| 015 | 4.013.0639 | BLACK BACK SIDE CABINET VERTIGO |
| 016 | 4.008.1434 | BLACK/GREY COATED WHEEL VERTIGO -RAL.9006- |
| 017 | 4.012.0150 | CABLE H05VV-F 3X1,5 MT.5,4 F/FSCHUKO PLUG |
| 018 | 6.001.0078 | GUN S'10Y WITH QUICK CONNECTION LAVOR |
| 020 | 6.002.0325 | LANCE L=500 W/NOZZLES HOLDER-TURNING QUICK JOINT-COGETIL FOR |
| 030 | 7.100.1962 | MANUALE SPECIFICO VERTIGO PLUS + CE LAVOR 27L A5 16F |
| 031 | 7.100.1962 | MANUALE SPECIFICO VERTIGO PLUS + CE LAVOR 27L A5 16F |
| 032 | 4.607.0651 | MOTORPUMP FIXING BRACKET |
| 033 | 5.001.0812 | MOTORPUMP PT'03 125 H110AL 230-240/50 D.12 12' TS INJ.1,7 BR |
| R80470016 - IDRO VERTIGO 28 PLUS 230-240/50 -G/GR- TS EU C/AVV. LWS pag.2 | ||
| 001 | 4.018.0101 | 1/4 HOSE 225BAR L=810 FOR CONNECTION HOSE REEL/MOTORPUMP |
| 002 | 6.005.0424 | KIT 369 HOSE REEL FOR VERTIGO |
| 003 | 4.018.0102 | HOSE 1/4 225BAR L=8000 INTEGRAL COUPLING-QUICK COUPLING FOR |
| R80470016 - IDRO VERTIGO 28 PLUS 230-240/50 -G/GR- TS EU C/AVV. LWS pag.3 | ||
| 004 | 4.008.0095 | BLACK DETERGENT TANK CAP WITHHOLE D.9 |
| 005 | 3.749.0472 | ROTARY NOZZLE 1/4F ALUM.THREADSIZE 035 + QUICK JOINT |
| 006 | 5.012.0478 | 5 NOZZLES KIT OF D.1,15 FOR QUICK JOINT GR.0-15-25-40FOAM |
| R80470016 - IDRO VERTIGO 28 PLUS 230-240/50 -G/GR- TS EU C/AVV. LWS pag.4 | ||
| 0 | R50070251 | CORPO GUIDA PT'03 P.D.12 TORN. C/ TS-VALV.COMP.C/ASP.-M.17KG |
| 0 | R50080234 | TESTATA PT'03 D.12 OTT.C/TAPPI FIL.(TEN.MARRONI TELATE) |
| 0 | R50091016 | ASS.MOTORE D.125H110ALL 230-240/50 2P +PIATT.12' |
| 001 | 6.005.0251 | KIT 168 LW RING+FAN |
| 002 | 5.009.1016 | ASS.MOTORE D.125H110ALL 230-240/50 2P +PIATT.12' |
| 003 | 3.001.0020 | RADIAL BEARING FOR POSTERIOR FLANGE 17X40X12 6203 2RS |
| 008 | 4.007.0416 | THRUST BEARING 35X58X12 PT'03(180BAR) |
| 009 | 5.007.0251 | PISTON BODY GUIDE PT'03 W-TS/COMP.VALVE/SPR.17KG/SUCTION |
| 010 | 6.005.0134 | KIT 125 O-RING SEAL |
| 011 | 5.008.0234 | COMPLETE BRASS HEAD |
| R80470016 - IDRO VERTIGO 28 PLUS 230-240/50 -G/GR- TS EU C/AVV. LWS pag.5 | ||
| 0 | R5Y090587 | FLANGIA ANTERIORE X PT'03 D.125H110 C/FILETTI |
| 001 | 5.002.0149 | Substituted by 5.009.1016 HOUSING '96 D125 H110AL 230-240/50 2P |
| 002 | 3.001.0020 | RADIAL BEARING FOR POSTERIOR FLANGE 17X40X12 6203 2RS |
| 003 | 5.005.0072 | Substituted by 5.009.1016 ROTOR D.65 H.110 x MOT.125AL PT' 03 |
| 004 | 5.Y09.0587 | FLANGE FOR PT'03 D.125H110 W/THREADS |
| 007 | 3.001.0002 | BALL OBLIQUE |
| 008 | 4.005.0225 | INCLINATED PLATE 12 DEGREE X PT'03 |
| R80470016 - IDRO VERTIGO 28 PLUS 230-240/50 -G/GR- TS EU C/AVV. LWS pag.6 | ||
| 001 | 4.Y05.0226 | FRONT FLANGE MOTOR D.125H110 PT'03 W/THREAD |
| 002 | 3.201.0001 | OIL SEAL 20/35/6/6,5 BABSL |
| R80470016 - IDRO VERTIGO 28 PLUS 230-240/50 -G/GR- TS EU C/AVV. LWS pag.7 | ||
| 001 | 5.009.0710 | BODY GUIDE ASS PT'03 D.12 CERAMIC S/V.COMP.IN.1,7 S/PORTAG. |
| 002 | 5.009.0596 | KIT TOTAL STOP TS PT'03 CABLEL=530 SPRING 17KG (GREEN FAST |
| 003 | 6.005.0254 | KIT 237 LW 3 PISTONS AISI 440 + SPRINGS PT'03 |
| 004 | 6.005.0226 | KIT 209 O-RING |
| 006 | 6.005.0277 | KIT 252 |
| 007 | 6.005.0079 | KIT 79 LW OIL SEALS |
| R80470016 - IDRO VERTIGO 28 PLUS 230-240/50 -G/GR- TS EU C/AVV. LWS pag.8 | ||
| 001 | 6.005.0315 | KIT 287 SUCTION/DELIVERY VALVE+ BRASS THREAD CAPS PT'03 |
| 002 | 4.006.0340 | BRASS HEAD |
| 003 | 6.005.0316 | KIT 288 WATER SEAL PT BRASS HEAD D.12 |
| 004 | 6.005.0134 | KIT 125 O-RING SEAL |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor Vertigo 28 Plus 80470016
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
