Lavor Pressure Cleaner ED 230/50 DELTA Parts
€7.50
Tax included
Lavor Original Parts for Cleaner ED 230/50 DELTA
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner ED 230/50 -N- DELTA JET TS + ROTOX - 8.027.0007.Fix Your Pressure Cleaner. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Cleaner ED 230/50 DELTA
Fix Your High Pressure Cleaner ED 230/50 -N- DELTA JET TS + ROTOX - 8.027.0007. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following tables, look for the spare part and its respective code.
| IDRO ED 230/50 -N- DELTA JET TS + ROTOX | ||
| Pag.1 | ||
| # | Part Num | Description |
| 0 | 5.001.0457 | MOTOR PUMP ED'97 D.110H75 230/5 0 1200W+TS |
| 1 | 4.008.0401 | ED FAN COVER |
| 2 | 4.008.0416 | AIR CONVEYOR LAVOR 12 |
| 3 | 4.008.0092 | FB80 FAN WITH HOLE D.16,5 (PARTNER) |
| 4 | 5.006.0141 | '99 CASING D.110 H60 230-240 /50 2P |
| 5 | 3.001.0020 | RADIAL BALL BEARING 6203 2RS |
| 6 | 5.006.0141 | ROTOR SHAFT D.55 H.60 CYL. |
| 7 | 3.002.0115 | TCEI SCREW M5X35 TRILOBATED ZNT |
| 8 | 4.005.0118 | D.110 MOTOR FLANGE LAVOR 12 |
| 9 | 3.200.0060 | OR GASKET 2325 82,28x1,78 NBR SH.70 |
| 10 | 3.200.0040 | OR GASKET 31,34x3,53 REF.4125 |
| 11 | 3.404.0032 | CAPACITOR 17mF 450V D.40x73 F/M |
| 12 | 4.008.0008 | CAPACITOR CABLE GLAND TUV |
| 13 | 4.008.0323 | CONDENSER HOLDER COVER+SWITCH. LAVOR12 |
| 14 | 5.009.0213 | EXT 0/1 BIP. SWITCH ASSEMBLY 12(10)A +TRANSPARENT PROTECTION |
| 15 | 3.201.0016 | OIL SEAL RING 17X28X7/7,5 WITH DUST SHIELD IN NBR LAVOR12 |
| 16 | 3.001.0022 | FRONT BEARING 17X40X12 RADIAL 6203 |
| 17 | 4.005.0119 | PLATE INC.9' STROKE.=6,65 LAVOR12 |
| 18 | 3.001.0023 | EXT WASHER AS3552 THRUST BEARING |
| 19 | 3.001.0024 | CAGE RETAINER AXK 3552 |
| 20 | 4.007.0138 | EXT WASHER D.54x28x4 FOR THRUST BEARING |
| 23 | 4.007.0163 | FORK VALVE BODY STOPPER LAVOR 12 |
| 24 | 3.200.0077 | OR GASKET 2262 64,39x1,78 NBR SH.70 |
| 25 | 5.009.0282 | STOPPER/PISTON ASSEMBLY DIAM.12 STAINLESS STEEL FOR LAVOR 12 |
| 26 | 4.007.0162 | PISTON RETURN SPRING LAVOR 12 IN C98 |
| 27 | 4.005.0127 | PISTON GUIDE BODY D.12 LAVOR 12 |
| 30 | 5.009.0475 | FLAT VALVE GROUP ASSEMBLY ED-SD ACETAL RESIN |
| 31 | 4.007.0229 | TCEI AUTOM. SCREW TRILOB.6X70 WITH FLANGE |
| 33 | 5.008.0186 | '99 ED HEAD FLAT VALVES |
| 34 | 4.008.0031 | SUCTION FILTER ORD H2O D.16 CONICAL |
| 35 | 3.201.0020 | WATER SEAL RING D.12X18X5 NBR SH.90 (SP2898N) |
| 36 | 4.008.0745 | LAVOR12 WIDE BLACK SUPPORT RING |
| 37 | 3.201.0014 | OIL SEAL RING D.12x20X5/7 |
| 42 | 5.009.0462 | BLIND ROD VALVE ASSEMBLY (PINK) DIRECT TS |
| 43 | 4.007.0169 | SPRING FOR TS ED Di.7,2 De.9,8 L= 18 WIRE D.1,3 |
| 44 | 4.007.0146 | SPRING Di.11,2 De.14,6 L=24,5 WIRE D.1,7 |
| 45 | 4.008.0467 | LOW TOTAL-STOP SPRING BLOCK FOR ED |
| 46 | 3.200.0021 | OR GASKET 6,75x1,78 NBR SH.70 |
| 47 | 5.009.0254 | CAP + OR GASKET TOTAL STOP VALVE ASSEMBLY |
| 48 | 5.009.0460 | MICRO+CABLE DIRECT TS ASSEMBLY (YELLOW LEVER) |
| 49 | 3.099.0049 | LOCK RING D.23 FOR FAN |
| 50 | 5.006.0141 | '99 MOTOR D.110 H60 230-240/50 2P |
| 51 | 5.007.0081 | PISTON GUIDE BODY LAVOR 12 PIST.D.12 |
| 52 | 5.008.0157 | FIBER HEAD ED'99 DIRECT TS |
| Pag.2 | ||
| 1 | 4.012.0157 | H05VV-F CABLE 3X0,75 MT.5,3 SCHUKO PLUG F/F |
| 2 | 3.100.0082 | BLACK 3/4 QUICK COUPLING WITH GASKET (THREAD L=11.5) |
| 3 | 4.013.0271 | BLACK ED INLET COVER |
| 4 | 4.013.0272 | BLACK ED OUTLET COVER |
| 5 | 3.002.0112 | HI-LO TC-TORX SCREW T15 3,9X25 ZNT |
| 6 | 6.002.0358 | '99 FOAM DIFFUSER FOR S'00V LANCE HEAD |
| 7 | 4.008.0803 | FOAM DIFFUSER TANK '99 -G- |
| 8 | 4.007.0114 | D.0,8 NOZZLE CLEANING PIN |
| 9 | 6.005.0321 | EXT S'00 GUN EXTENSION WITH INTEGRATED PNEUMATIC HOSE 3 MT REINFORCED |
| 11 | 6.002.0210C | EXT S'00V LANCE 1,10 GREEN |
| 12 | 6.002.0327 | EXT ROTOX S99 LANCE 1,10 (GREEN) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor ED 230/50 DELTA
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
