Lavor Pressure Washer HW24 - G Parts
€36.48
Tax included
Lavor Original Parts for Pressure Cleaner HW24 230/50 -G- EU LWS TS S/AVV. - 8.043.0001
Fix Your Hot Water High Pressure Cleaner HW24 230/50 -G- EU LWS TS S/AVV. - 8.043.0001. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner HW24 230/50 -G- EU LWS TS S/AVV. - 8.043.0001
Fix Your Hot Water High Pressure Cleaner HW24 230/50 -G- EU LWS TS S/AVV. - 8.043.0001. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full GuaranteeIn the following tables, look for the spare part and its respective code.
| Pressure Washer HW24 230/50 -G- EU LWS TS S/AVV. - 8.043.0001 | ||
| Pag.1 | ||
| # | Part Num | Description |
| 1 | 4.007.0272 | UPPER TUBE (HANDLE) HW |
| 6 | 4.007.0277 | HANDLE TUBE STOP SPRING HW |
| 8 | 4.008.0724 | UPPER SUPPORT FOR HW TANKS |
| 9 | 3.105.0006 | 3-WAY TAP WITH KNOB -G- PANT.108C (HW) |
| 11 | 4.008.0725 | HW NEUTRAL DETERGENT TANK |
| 12 | 4.008.0723 | LOWER SUPPORT FOR HW TANKS |
| 16 | 5.011.0068 | HW SIDE TUBE ASSEMBLY WITH SPRINGS INSERTED |
| 17 | 4.008.0732 | HW UPPER LANCE HOLDER |
| 18 | 4.008.0722 | HW PUMP SUPPORT |
| 19 | 3.003.0017 | M8 SELF-LOCKING NUT HIGH ZNT DIN 982 |
| 20 | 4.007.0276 | WHEEL PIN M8 D.12 X HW |
| 21 | 3.006.0033 | WHEEL D.200 HOLE 12 X HW (SPG200) |
| 24 | 3.099.0095 | WHEEL BOSS FOR SP200 -G- PANT.108C SMOOTH |
| 27 | 4.008.0730 | FRONT FOOT FOR HW TUBE |
| 28 | 4.007.0271 | LOWER TUBE (FOOT) HW |
| 29 | 3.100.0082 | QUICK CONNECTOR 3/4 BLACK WITH SEAL (THREAD L=11.5) |
| 30 | 4.008.0036 | HYDROCLEANING SUPPORT PAD L.PANNA P.V.C. Sh 70 |
| 31 | 5.001.0494 | MOTOR PUMP PT 230/50 D.12 9.16 125h110 W/REG.IN.D.1.8 TS(HW) |
| 32 | 5.009.0213 | EXT SWITCH ASSEMBLY 0/1 BIP. 12(10)A + TRANSPARENT PROTECTION |
| 33 | 4.008.0728 | ELECTRIC BOX LID HW |
| 34 | 3.404.0016 | 45mF 450V CAPACITOR D.45x90 F/M |
| 36 | 4.008.0726 | ELECTRIC BOX 2600W HW |
| 37 | 4.008.0581 | RUBBER CABLE GLAND D.15.5 |
| 38 | 4.013.0372 | HW FAIRING -G- PANT.108C |
| 39 | 4.007.0288 | HW MOTOR PUMP FASTENING BAND |
| 40 | 3.002.0386 | SELF-THREADING SCREW W/BORDER 6.3X50 UNI 6950 ZNT |
| 43 | 4.008.0172 | TRANSPARENT TUBE 6x9 L=510mm |
| 44 | 4.008.0444 | TRANSPARENT TUBE 6X9 L=340mm |
| 45 | 4.012.0150 | H05VV-F CABLE 3X1.5 MT.5.4 SCHUKO SPLASH-PROOF THREAD F/F |
| 47 | 6.001.0085 | EXT GUN S'01DR METAL EXTENSION |
| 48 | 4.018.0061 | EXT TUBE 1/4 18MPa L=8000 1/4F.GIR./M22x1,5K15 |
| 49 | 6.002.0183 | EXT LANCE SY'99 1,05 A/B (GREY) |
| 61 | 4.007.0114 | NOZZLE CLEANING NEEDLE D.0,8 ES P.04 |
| Motor Pump Pag.2 | ||
| 1 | 5.009.0213 | EXT SWITCH ASSEMBLY 0/1 BEEP. 12(10)A + TRANSPARENT PROTECTION |
| 2 | 3.406.0004 | CABLE GLAND PG.11 TEARPROOF |
| 4 | 3.002.0135 | SELF-TAPPING SCREW TC-TC 2.9X13 UNI 6 954 ZNT |
| 5 | 3.404.0016 | CAPACITATOR 45mF 450V D.45x90 F/M |
| 6 | 4.008.0768 | ROUND GASKET D.4 EPDM L=525 |
| 7 | 4.008.0583 | FAN COVER FOR '96 MOTOR WITHOUT GRID |
| 8 | 3.099.0049 | STOP RING D.23 FOR FAN |
| 9 | 4.008.0092 | FB80 FAN WITH HOLE D.16.5 (PARTNER) |
| 10 | 5.006.0197 | '96 CASING D125 h110 230/50 2P 2800W |
| 11 | 3.001.0020 | BALL BEARING 6203 2RS |
| 12 | 5.005.0029 | ROTOR SHAFT D.65 H.110 (125'96) |
| 13 | 3.002.0115 | TCEI SCREW M5X35 TRILOBATE ZNT |
| 14 | 5.009.0395 | FRONT FLANGE MOTOR D.125 H110 FOR PARTNER |
| 15 | 3.201.0001 | SEAL RING 20/35/6/6.5 BABS L |
| 16 | 3.001.0031 | RADIAL BALL BEARING 6304 (20X52X15) |
| 17 | 4.005.0125 | TAPERED PLATE INC.9.16 CORS =7.9-7.83 ROLLER BEARING |
| 18 | 3.001.0003 | EXT AXIAL BEARING RING AS4565 |
| 19 | 3.001.0025 | ROLLER CAGE TYPE AXK4565 - STEEL- |
| 20 | 4.007.0001 | EXT THRUST RING D.65x30x6 (C10Pb) FINISHED |
| 21 | 5.009.0452 | STOP/PISTON ASSEMBLY D.12 GROUND PARTNER |
| 22 | 3.200.0014 | OR SEAL 85 X 2.5 NITRILE |
| 23 | 4.007.0025 | RETURN SPRING FOR PISTON D.14- 12 |
| 30 | 6.005.0078 | ASSEMBLY ADJUSTMENT ROD COMPEN. VALVE FOR TS D.11 |
| 31 | 5.009.0283 | ASSEMBLY MICRO+CABLE L=580 FOR TS VALVE COMP. + CABLE GLAND FOR HW |
| 32 | 4.006.0170 | SEAL SEAT SPACER FOR OMNIA'97 VALVE |
| 33 | 5.609.0061 | SEAL SEAT L2 COMPLETE WITH OR |
| 35 | 3.005.0009 | BALL 11/32 INOX 420 B |
| 36 | 4.607.0095 | SPRING D.8X16 WIRE 0.8 |
| 41 | 6.005.0030 | HOSE HOLDER FOR SUCTION DETERG. COMP. L. OF OR |
| 42 | 3.005.0001 | BALL INOX 420 DIAM.5 (precision grade G 500) |
| 43 | 4.007.0014 | EXT SPRING FOR CHECK VALVE DETERG. De4, 5/6 L=7 WIRE D.0.3 INOX |
| 44 | 4.005.0207 | GUIDE BODY D.12 FOR COMP. VALVE W/O ADJUSTMENT FINISHED WORK |
| 45 | 5.609.0041 | EXT CHECK VALVE ASSEMBLY + OR |
| 46 | 4.007.0324 | EXT SPRING FOR VALVE RETAINER D.4.8-6 L= 20 WIRE 0.6 STAINLESS STEEL |
| 47 | 5.009.0334 | INJECTOR CONNECTOR D.1.8 FOR ALUMINUM HEAD COMPLETE WITH OR |
| 48 | 5.009.0333 | OUTLET CONNECTOR M22x1.5 COMPLETE WITH OR |
| 49 | 3.200.0013 | OR SEAL 11.1 X 1.78 REF. 114 |
| 50 | 3.201.0014 | OIL SEAL RING D.12x20X5/7 |
| 51 | 3.002.0094 | TCEI SCREW M6X30 ZNT TRILOBATE |
| 53 | 4.006.0109 | PLUG 1/8 GAS CONICAL |
| 54 | 3.200.0018 | OR SEAL 9.92X2.62 SHORE 90 |
| 55 | 3.200.0019 | OR SEAL 12.4X1.78 SH90 |
| 56 | 5.009.0101 | SUCTION/DEMAND VALVE CAP WITH OR MOUNTED |
| 57 | 5.009.0005 | SUCTION VALVE DELIVERY WORK 1 |
| 58 | 4.008.0031 | FILTER ASP.H2O D.16 CONICAL |
| 62 | 4.008.0657 | OIL SEAL SPACER D.12 PARTNER |
| 63 | 4.006.0251 | SEAL SUPPORT RING PARTNER D.12 LOW |
| 64 | 4.008.0695 | ANTI-EXTRUSION RING 12X18X1 FOR PARTNER D.12 |
| 65 | 3.201.0020 | WATER SEAL D.12X18X5 NBR SH. 90 (SP2898N) |
| 66 | 5.009.0015 | COMPLETE SUCTION VALVE T OP |
| 67 | 4.005.0187 | HEAD PARTNER '01 FOR PISTONS D.12 FINISHED WORK |
| 68 | 3.002.0130 | SCREW TCEI M6X70 CL.12,9 UNI5931 DACROMET |
| 83 | 5.008.0160 | HEAD PARTNER D.12 S/IND. |
| 84 | 5.007.0148 | GUIDE BODY PIST.D.12 +INJECTION D.1.8 V/COMP.S/REG.TS |
| 85 | 5.006.0157 | MOTOR'99 D.125 H110 230/50 2P RIGID BEARING FOR PARTNER |
| 87 | 3.406.0011 | RING FOR PG.11 TEAR-PROOF |
| 90 | 4.008.0728 | ELECTRIC BOX LID HW |
| 91 | 4.008.0726 | ELECTRIC BOX 2600W HW |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
