Lavor Pressure Cleaner EQ20 Parts
€280.19
Tax included
Lavor Original Parts for Pressure Cleaner EQ20
Lavor original spare parts for to replace broken parts for to fix IDRO EQ20 '03 230-240/50 -N/G- TS EU 2L - 8.026.0903Fix Your Pressure Cleaner. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner EQ20
Lavor original spare parts for to replace broken parts for to fix IDRO EQ20 '03 230-240/50 -N/G- TS EU 2L - 8.026.0903In the following tables, look for the spare part and its respective code.
| IDRO EQ20 '03 230-240/50 -N/G- TS EU 2L -LAVOR- | ||
| Pag.1 | ||
| # | Part Num | Description |
| 0 | 5.001.0668 | MOTOP.PT'03 110h80 230-240/50 D.12 8°30 TS V.COMP. (FAN D.144) |
| 9 | 6.005.0253 | KIT 236 LW LOW PROFILE FAN+ RING |
| 11 | 3.001.0033 | RADIAL BALL BEARING 6003 2RS (17x35x10) |
| 14 | 4.005.0277 | FRONT FLANGE MOTOR D.110-'10 PT'03 FOR SELF-TAPPING SCREWS |
| 15 | 3.201.0008 | OIL SEAL RING D.17X35X7 |
| 16 | 3.001.0030 | RADIAL BALL BEARING 6303 (17X47X14) |
| 17 | 4.005.0278 | INCLINED PLATE 8°30 FOR PT'03 THRUST BALL BEARING |
| 19 | 4.007.0328 | EXT THRUST BALL BEARING 35X55X12 FOR PT'03 |
| 20 | 6.005.0181 | EXT KIT 167 LW 3 PISTONS + SPRINGS PT'03 |
| 22 | 6.005.0226 | ORD KIT "O-RING FOR PT'03" |
| 25 | 6.005.0079 | ORD KIT 79 LW OIL SEAL RINGS FOR PARTNER D.12/FIBER |
| 26 | 6.005.0184 | ORD KIT 170 LW SUCTION/DELIVERY VALVES PT'03 |
| 27 | 4.005.0210 | PT'03 LAV. HEAD |
| 28 | 6.005.0133 | ORD KIT 124 WATER SEAL RINGS PARTNER D.12 |
| 29 | 6.005.0282 | KIT 257 LW ALUMINUM SUPPORT RINGS+ SPACERS PT D.12 |
| 30 | 4.005.0234 | PISTON GUIDE BODY PT'03 W/O DETERGENT SUCTION HOLE |
| 31 | 5.009.0749C | EXT MOT.ASS.09 D110H80 230-240/50 2P W/THERMAL PROTECTION PT03 +PLATE.8°30 |
| 32 | 5.007.0192C | PT'03 PIST.D.12 GUIDE BODY W/ TS-VALVE.COMP.W/O SUCTION-M.13KG |
| 33 | 5.008.0182C | PT'03 HEAD D.12 -C- |
| 34 | 5.009.0716 | V.COMP. ASSY W/TS PT'03 CABLE L=530 SPRING 13KG (WHITE COVER) |
| 23A | 6.005.0281 | EXT KIT 256 LW CHECK VALVE ASSEMBLY W/O SUCTION PT'03C |
| Pag.2 | ||
| 1 | 4.008.0392 | EQ -G- PANT.108C AESTHETIC COVER |
| 2 | 4.008.0351 | BLACK EQ FIXED HANDLE |
| 3 | 4.013.0581 | BLACK AESTHETIC EQ OUTLET CASING |
| 4 | 4.008.0353 | BLACK EQ SLIDING HANDLE |
| 5 | 4.013.0581 | BLACK AESTHETIC EQ INLET CASING |
| 6 | 4.008.0316 | BLACK '96 EQ WHEEL |
| 7 | 4.008.0317 | EQ-VIPER -G- PANT.108C WHEEL COVER |
| 8 | 4.012.0149 | EXT H05VV-F CABLE 3X1 MT.5,4 SPLASHPROOF SCHUKO PLUG F/F |
| 9 | 3.401.0178 | EXT 0/1 SWITCH BLACK PUSH/BUTTON IP55 12/10 |
| 10 | 6.001.0076 | EXT S'09 GUN W/ INTEGRATED QUICK COUPLING W/LEVER -G- PANT.108C LAVOR |
| 11 | 4.018.0096 | EXT HOSE 1/4 18MPa L=8000 ROT.M22x1,5 D.15-QUICK COUPL.FOR S'09 W/SPIRAL H. |
| 12 | 6.002.0209C | EXT S'99 1,05 FIXED LANCE (GREY) L=460 |
| 13 | 6.002.0340 | EXT S'12 LANCE W/O HEAD W/QUICK COUPL.-COGETIL |
| 14 | 6.002.0347 | EXT ROTOX HEAD S'12 LANCE D.1,1 -GREEN- W/QUICK COUPL. |
| 15 | 6.002.0358 | FOAM DIFFUSER WITH TRANSPARENT TANK (DIFF.D.2,75) |
| 16 | 7.100.1464 | SPECIFIC MANUAL EQ + CE LAVOR 27L A5 12F |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor EQ20 - 8.026.0903
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
