Hitachi Spare Parts for Chainsaw CS 30EC
€43.53
Tax included
Hitachi Spare Parts for Chainsaw CS 30EC
Hitachi original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Chainsaw CS 30EC.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Chainsaw CS 30EC
Hitachi original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Chainsaw CS 30EC.
In the following table, look for the model of the Chainsaw and ripettivo spare part.
| Chainsaw CS 30EC | ||
| # | Part Num. | Description |
| 1 | 6687468 | SPARK PLUG CAP ASS'Y |
| 3 | 6685461 | CYLINDER SET |
| 4 | 6684682 | HEX. HOLE BOLT 4X15/PS |
| 5 | 6685726 | CYLINDER GASKET |
| 6 | 6686119 | PISTON RING |
| 7 | 6685881 | PISTON SET |
| 8 | 6684591 | PISTON PIN |
| 9 | 6684590 | CIR CLIP |
| 10 | 6686173 | CRANK SHAFT COMP. |
| 11 | 6692900 | CORD INSULATOR TUBE |
| 12A | 6601174 | IGNITION COIL ASS'Y |
| 15 | 6601179 | IGNITION COIL SET PN |
| 20 | 6685098 | SHIM S T0.2 |
| 20 | 6685099 | SHIM S T0.3 |
| 20 | 6686475 | SHIM 0.4 |
| 21 | 6685104 | FLYWHEEL NUT |
| 22 | 6685103 | BOLT WASHER M7 |
| 23 | 6687378 | MAGNETO ROTOR SET |
| 24 | 6693305 | STARTER PAWL |
| 25 | 6685105 | STARTER PAWL SPRING |
| 26 | 6685101 | D4E RETAINING RING |
| 27 | 6692304 | CLIP 4.5 |
| 28 | 6692412 | FUEL PIPE 2.5X4.5X175 |
| 29 | 6684597 | INSULATOR TUBE 50L |
| 30 | 6695046 | HEX. HOLE BOLT 5X16 |
| 30A | 6695046 | HEX. HOLE BOLT 5X16 |
| 31 | 6685226 | WASHER M5 (BLACK) |
| 33 | 6695169 | FLUNGE NUT 5 |
| 34 | 6686526 | CRANK CASE ASSY |
| 35 | 6684607 | OIL SEAL TB 12227 |
| 36 | 6686703 | CRANK CASE GASKET |
| 38 | 6685095 | NEEDLE ROLLER 2.5X9.8 |
| 39 | 6695514 | HEX.HOLE BOLT 5X22/WS |
| 50 | 6687328 | AIR DEFLECTOR ASS'Y |
| 51 | 6691466 | PIPE HOLDING GROMMET |
| 52 | 6689872 | INLET MANIFOLD GASKET |
| 53 | 6689819 | INLET MANIFOLD SPACER |
| 54 | 6689788 | INLE TMANIFOLD COMP. |
| 55 | 6689997 | CARB. FIXING PLATE |
| 56 | 6690811 | DUST COVER |
| 57 | 6692587 | CHOKE ROD HOLDING RUBBER |
| 58 | 6692515 | CHOKE BUTTOM COMP. |
| 59 | 6690679 | CARUB. SUPPORT PLATE |
| 60 | 6687960 | ADJUSTER CAP |
| 61 | 6687980 | IDLE GROMMET |
| 62 | 6695157 | U-NUT 5 |
| 63 | 6695484 | HEX. HOLE BOLT 4X10S |
| 64 | 6684864 | SMALL WASHER 5 |
| 70 | 6685247 | SHIELD TUBE |
| 71 | 6685198 | CLIP D6 |
| 72 | 6684661 | WASHER 5 |
| 73 | 6690919 | OIL FILTER |
| 74 | 6685249 | OIL FILTER BODY ASS'Y |
| 75 | 6685246 | PROTECTIVE COIL |
| 76 | 6692126 | PUMP FIXING PLATE |
| 77 | 6685139 | PRIMING PUMP COMP. |
| 78 | 6692413 | FUEL PIPE |
| 79 | 6692350 | FUIL PIPE 2.5X4.5X140 |
| 80 | 6692422 | FUEL GROMMET |
| 82 | 6691286 | RETURN GROMMET |
| 83 | 6687504 | STOP SWITCH COMP. |
| 84 | 6685180 | TANK CAP ASS'Y |
| 85 | 6685179 | TANK CAP PACKING |
| 87 | 6691368 | ENGINE CASE ASS'Y |
| 88 | 6685173 | AIR VENT VALVE (B) |
| 89 | 6692086 | AIR VENT ASS'Y |
| 90 | 6691380 | ENGINE CASE COVER |
| 91 | 6697756 | OIL TANK CAP ASS'Y |
| 92 | 6697888 | OIL TANK CAP PACKING |
| 100 | 6692912 | RECOIL STARTER ASS'Y |
| 101 | 6684679 | SET SCREW |
| 102 | 6685183 | DAMPER SPRING |
| 103 | 6685184 | STARTER PULLEY |
| 105 | 6685185 | SPRING CASE SET |
| 106 | 6685188 | STARTER HANDLE |
| 107 | 6686953 | FAN CASE COMP. |
| 108 | 6685191 | TAPPING SCREW D4.5X20 |
| 109 | 6692936 | CAM PLATE |
| 111 | 6690065 | CLEANER ELEMENT |
| 112 | 6686315 | CLEANER COVER |
| 113 | 6685228 | CLEANER KNOB |
| 120 | 6690651 | CARBURETOR ASS'Y WT-797A |
| 121 | 6684700 | INLET SCREEN |
| 122 | 6691438 | PUMP COVER |
| 123 | 6685210 | SCREW |
| 124 | 6685212 | PUMP GASKET |
| 125 | 6685213 | PUMP DIAPHRAGM |
| 126 | 6685217 | CONTROL LEVER |
| 127 | 6685218 | HINGE PIN SET SCREW |
| 129 | 6685219 | HINGE PIN |
| 131 | 6690827 | METERING DIAPHRAGM COMP. |
| 132 | 6685220 | DIAPHRAGM PACKING-METERING |
| 133 | 6685215 | NEEDLE VALVE |
| 134 | 6690766 | IDLE ADJUST SPRING |
| 135 | 6690736 | IDLE ADJUST SCREW |
| 136 | 6685223 | SET SCREW |
| 151 | 6686765 | OIL PUMP COVER |
| 152 | 6685150 | OIL PIPE (A) |
| 153 | 6685151 | SCREW GEAR |
| 154 | 6691401 | AIR VENT SPONGE |
| 155 | 6685135 | OIL PUMP CASE ASS'Y |
| 156 | 6685132 | PUMP GEAR COMP. |
| 157 | 6685131 | PUMP GEAR SPRING |
| 158 | 6685130 | OIL PUMP ADJUST CAP |
| 160 | 6685129 | ADJUSTER SPRING |
| 161 | 6685070 | BOLT WASHER M4 |
| 162 | 6685128 | OIL PUMP ADJUSTER |
| 163 | 6685133 | MACHINE SCREW M3X8 |
| 164 | 6692450 | MUFFLER SET |
| 165 | 6690959 | OIL ADJUST GROMMET |
| 166 | 6685149 | MACHINE SCREW (W/SP. WASHER) M4X14 |
| 167 | 6692734 | MUFFLER GASKET |
| 168 | 6695054 | HEX. HOLE BOLT 5X40 |
| 169 | 6684661 | WASHER 5 |
| 170 | 6685154 | FUEL PIPE |
| 171 | 6685155 | CHAIN CATCHER |
| 172 | 6692753 | MUFFLER COVER |
| 174 | 6685275 | TAPPING SCREW D5X14 |
| 175 | 6696077 | GUIDE PLATE A |
| 176 | 6685161 | TAPPING SCREW D4X10 |
| 200 | 6685166 | NUT |
| 201 | 6688560 | CLUTCH COMP. |
| 202 | 6685143 | NEEDLE BEARING |
| 203 | 6689037 | CLUTCH HOUSING COMP. |
| 204 | 6689635 | CLUTCH WASHER |
| 205 | 6689641 | CLUTCH WASHER |
| 207 | 6685161 | TAPPING SCREW D4X10 |
| 208 | 6690765 | GUIDE PLATE B |
| 209 | 6687074 | TENTION ADJUST BOLT COMP. |
| 210 | 6685168 | GEAR (A) |
| 211 | 6693485 | HAND GUARD WEIGHT |
| 212 | 6691198 | CRANK SHAFT COLLAR 6 |
| 213 | 6685069 | NUT M4 |
| 214 | 6685068 | MACHINE SCREW (W/SP. WASHER) M4X12 |
| 215 | 6686112 | SIDE CASE ASS'Y |
| 216 | 6689677 | BRAKE HANDLE |
| 217 | 6689713 | BRAKE LINK COVER |
| 218 | 6689707 | BRAKE SPRING |
| 219 | 6685119 | BRAKE SUPPORT PLATE COMP. |
| 220 | 6685141 | NEEDLE ROLLER 3X9.8 |
| 221 | 6685388 | BRAKE LINK |
| 222 | 6689729 | BRAKE BAND |
| 223 | 6690805 | CLEANER FIXING COLLAR |
| 224 | 6685120 | COLLAR |
| 225 | 6686049 | SIDE COVER COMP. |
| 226 | 6685122 | BRAKE LEVER SPRING |
| 227 | 6685148 | TAPPING SCREW D4X15 |
| 250 | 6695107 | TAPPING SCREW 5X35 |
| 251 | 6690805 | CLEANER FIXING COLLAR |
| 252 | 6695108 | TAPPING SCREW 5X40 |
| 253 | 6688480 | DAMPER COLLAR A |
| 254 | 6688117 | DAMPER A |
| 255 | 6685275 | TAPPING SCREW D5X14 |
| 256 | 6685074 | TAPPING SCREW D5X16 |
| 257 | 6685653 | REAR HANDLE B |
| 258 | 6688363 | TRIGGER LOCKOUT VERMILION |
| 259 | 6686395 | THROTTLE LEVER |
| 260 | 6686416 | THROTTLE LEVER SPRING |
| 261 | 6685628 | REAR HANDLE A |
| 262 | 6685148 | TAPPING SCREW D4X15 |
| 263 | 6688088 | FRONT HANDLE |
| 264 | 6693875 | THROTTLE WIRE COMP. |
| 265 | 6688262 | DAMPER COMP. |
| 502 | 6686632 | 4X50 MINUS DRIVER |
| 602 | 6694471 | STARTER MARK |
