Lavor Original Parts for Pressure Cleaner NPX 1400 - 8.605.0086
€14.52
Tax included
Lavor Original Parts for Pressure Cleaner NPX 1400 - 8.605.0086
Lavor original spare parts for to replace broken parts for to fix Hot Water High Pressure Cleaner NPX 1400 230/50 TS - 8.605.0086.
Fix Your Pressure Cleaner NPX 1400. All Spares can be supplied at low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner NPX 1400 - 8.605.0086
Fix Your Hot Water High Pressure Cleaner NPX 1400 230/50 TS - 8.605.0086. All Spares can be supplied at low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| R86050086-3 - IDRO NPX 1400 220/50 + TOTAL STOP -G- Pag.1 | ||
| # | Part Num. | Description |
| 001 | 3.002.0122 | SCREW M6X12ZNT |
| 002 | 4.613.0094 | YELLEW UPPER FAIRING J.4 |
| 003 | 4.608.0062 | LOWER COACHWORK JOLLY 4/93 |
| 004 | 4.612.0030 | Sobstitued by 4.612.0046 CABLE HO5 3X1.5 L=5000S/FASTUM |
| 005 | 4.608.0074 | LONG SPACER FOR TANK JOLLY 4/9 3 |
| 006 | 4.008.0104 | Sostituit da 5.009.0159 PLASTIC CAP 3/8 OIL LOAD |
| 007 | 4.608.0073 | SHORT SPACER FOR TANK JOLLY 4/ 93 |
| 008 | 5.613.0096 | BOILER AXLE JOLLY 4/93 |
| 009 | 4.608.0082 | GAS OIL-CHEM TANK CAP |
| 010 | 3.002.0038 | Sostituit da 3.002.0022 SCREW TE M4X20 UNI 5739 |
| 011 | 3.006.0026 | Sostituit da 6.605.0168 WHEEL D.260X85 BLACK |
| 012 | 3.099.0019 | BLOCK WHEEL D.250x55 D.20 |
| 013 | 3.099.0096 | Sobstitued by 4.608.0434 WHEEL COVER |
| 014 | 5.009.0340 | QUICK COUPLING ASSY +GASKET+RING NUT |
| 015 | 3.100.0043 | 3/8 M ROTATING QUICK COUPLING |
| 016 | 4.618.0016 | HOSE L=10000 250BAR 5/16 |
| 017 | 6.001.0053 | Sostituit da 3.700.0036 HP SPRAY GUN S'02 3/8' |
| 018 | 3.701.0015 | LANCE INOX L.700 +PL4/1+WASHER+ QUICK CONN.M22 |
| 019 | 3.103.0050 | HIGH PRESSURE NOZZLE 1/8''M 15045 (C25045) |
| R8605X055-2 - IDRO NPX 1400 230/50 TS LBVM Pag.2 | ||
| 002 | 4.608.0079 | DASHBOARD '93 WITH COMPLETE SI LKSCREEN |
| 003 | 4.608.0019 | BLACK THERMOSTATE KNOB 3079/1 |
| 004 | 4.608.0018 | Sobstuited by 4.608.0019 BLACK COCK KNOB 3081/1 |
| 005 | 3.403.0001 | THERMOSTAT 30/150 BULB 6,5 |
| 006 | 3.105.0003 | DETERGENT REGULATING COCK WITH RUBBER HOLDER D.7 |
| 007 | 4.608.0065 | BOX DASHBOARD '93 |
| 008 | 4.608.0071 | GUIDING CABLE COVER DASHBOAR D '93 |
| 009 | 4.008.0122 | Sobstuited by 5.009.0165 SWITCH SEALING SURROUND |
| 010 | 4.008.0121 | Sobstuited by 5.009.0165 TIN SWITCH COVER |
| 011 | 3.401.0025 | MICRO BREAKER ABT WK 160 CO |
| 012 | 4.608.0066 | SWITCH HOLE CAP |
| 015 | 3.107.0004 | PRESS.GAUGE DIAM.50 0/250 1/4 REAR+CLAMP |
| 016 | 4.618.0014 | PRESSURE GAUGE TUBE DN 2X330TG |
| 017 | 4.008.0281 | ADJUSTING KNOB |
| 018 | 3.099.0282 | TWO-WIRES WRAPPER FOR 6X12 HOSE (15126) |
| 019 | 3.405.0023 | JUNCTION BOX |
| 020 | 4.608.0078 | GASKET |
| 022 | 3.400.0008 | Sostituit da 6.605.0172 TRANSFORMER 220-380V 24V 2A |
| 023 | 3.403.0004 | TOTAL STOP BOARD |
| 024 | 3.402.0001 | Sostituit da 3.402.0002 REMOTE CONTROL SWITCH 24V 5.5KW |
| 025 | 5.611.0027 | Substiutited by 5.611.0194 FLANGE FOR BURNER |
| 027 | 4.614.0004 | STANDARDIZED ELECTRODES COUPLE WITH ROD |
| 028 | 3.100.0017 | ELBOW 4 1/8 COPPER TUBE |
| 029 | 3.099.0015 | RING SEEGER I D.21 SP1 DIN 472 |
| 030 | 4.608.0002 | SITE GLASS DIAM.20 SP.1,8 |
| 031 | 4.605.0001 | WROUGHT BURNER FLANGE |
| 032 | 3.104.0004 | Substituited by 3.104.0028 DIESEL NOZZLE 1,25 45-B |
| 033 | 4.606.0066 | HOUSING FIXING ROD |
| 034 | 4.616.0001 | COPPER TUBE D.4 |
| 035 | 3.400.0013 | Sostituit da 6.605.0102 IGNITION TRANSFORMER 230/50 818C/S C/W WIRE L.600 |
| 036 | 4.607.0072 | MOTOR CLAMP |
| 038 | 4.608.0036 | FEEDING CABLE CONNECTOR |
| 039 | 4.608.0068 | GUIDING HANDLE COMPACT 4P |
| 040 | 5.613.0094 | HANDLE HOLDER JOLLY 4/93 |
| 047 | 3.004.0015 | PLAIN WASHER D.22X39X3 UNI6592 |
| 048 | 4.606.0013 | COIL FIXING NUT 1/2 BRASS SPE C. |
| 049 | 5.611.0043 | GAS OIL FILTER UNIT JOLLY 4/93 |
| 050 | 4.618.0035 | TUBE R1 PUMP/COIL TG480 |
| 051 | 4.618.0033 | TUBE R2 FROM COIL TO BLOCK JOL LY 4/93 |
| 052 | 5.611.0012 | EXTERNAL BURNER COVER DIAM.341 |
| 053 | 5.611.0099 | HIGH TENSION CABLE L=480XELEC TRODE UNIFIED W/PROT |
| 054 | 3.003.0010 | BLIND NUT E. M6 UNI 5721 BRASS |
| 055 | 3.004.0006 | PLAIN WASHER D.6.4X12X1.6 GALVANIZED UNI6592 |
| 056 | 5.613.0047 | Sobstitued by 5.613.0147 BOILER OUTWARD COVER |
| 057 | 5.613.0080 | Sobstitued by 5.610.0105 BUNCHER WITH TAPER D.82 WITH H OLES |
| 058 | 5.613.0027 | COMBUST.CHAMB.INWARD COVER CHI MM. L=110 |
| 059 | 4.604.0001 | COIL TOP H.335 |
| 060 | 5.613.0095 | BODY BOILER JOLLY 4/93 |
| 061 | 4.608.0116 | Sobstitued by 6.605.0247 REFRACTORY GROUND D.290X20 FOR BURNER |
| 063 | 4.607.0006 | COIL FIXING STRIP PLATE 20/1 0 |
| 064 | 4.608.0004 | Sobstitued by 4.608.0162 GASKET WITHOUT AMIANTH. FOR BO ILER ESP.2 |
| 065 | 5.613.0097 | BASE BOILER JOLLY 4/93 |
| 067 | 3.100.0018 | RAPID COUPLING 3/8M-1/2M 08 (GALVANIZED BRASS) |
| 068 | 4.606.0038 | ADJUSTING SCREW FOR SAFETY VALVE |
| 069 | 4.606.0087 | BULB ASSY |
| 070 | 3.004.0004 | ALUMINIUM WASHER 21X30XSP 1,5 |
| 071 | 3.100.0020 | REDUCTION M.GAS/M.GAS 1/2-3/8 |
| 072 | 5.613.0093 | Sobstitued by 5.613.0282 THERMOSTATE BULB HOLDER JOLLY 4/93 |
| 073 | 4.618.0036 | TUBO B.P. D.20X10 3/8M-3/8M L .570 |
| 074 | 4.606.0019 | SUCTION CONNECTOR M22 IDRO COM PACT |
| 075 | 4.008.0031 | INLET WATER FILTER H2O D.16 CONICAL |
| 076 | 5.609.0013 | Sobstitued by 5.613.028 THERMOSTAT BODY |
| R56010168-2 - MOTOPOMPA LWM 230/50 2P 135 H125 9.30' X NPX 1400 TS Pag.3 | ||
| 001 | 4.608.0017 | Sobstitued by 6.605.0086 PUMP SIDE HALF FEMALE SCREW GM V D.150 |
| 002 | 4.608.0083 | FAN PVC D.180 DOWNSWED HUB ESP.5 |
| 002 | 4.007.0080 | FAN FIXING RING D.25,5 |
| 003 | 3.002.0015 | AUTOTAPPING SCREW TCEI M6X25 Z NT |
| 004 | 4.608.0129 | Sobstitued by 6.605.0086 HALFCOVER MOTORSIDE |
| 005 | 3.002.0067 | AUTOTHREAD.SCREW TC-TC 3,2X26 RAP.FIX |
| 006 | 3.002.0060 | SELF TAPPING CROSS HEAD SCREW 3.9X16 RAPID FIX |
| 007 | 4.608.0022 | SETTING THROTTLE LEVER GMV 150 |
| 008 | 4.608.0021 | SETTING THROTTLE GMV 150 |
| 009 | 3.099.0012 | Sobstitued by 6.605.0173 GASOIL PUMP PLASTIC COUPLING |
| 010 | 3.414.0009 | 24V-50Hz BOBBIN FOR GAS-OIL DANFOSS PUMP |
| 011 | 3.551.0006 | Sobstitued by 3.551.0040 GAS OIL PUMP |
| 012 | 3.100.0057 | CONNECTION D.4X1/8'M VITON O-RING |
| 013 | 4.607.0257 | FAN CONNECTION |
| 014 | 4.607.0233 | MOTOR AIR CONVOY |
| 015 | 5.602.0027 | HOUSING LW.T 400/50 2P D.135 H130 |
| 016 | 3.001.0001 | BALL RADIAL BEARING 6204-2Z |
| 017 | 5.605.0033 | Sobstitued by 5.606.0143 ROT SHAFT 70H125 |
| 019 | 4.605.0034 | Sobstitued by 5.609.0072 MOT.FLAGE FOR BODY GUIDE |
| 020 | 3.201.0019 | OIL SEAL RING D.25X40X7 DOUBLE LIP |
| 021 | 5.609.0072 | MOTOR FRONT FLANGE FOR BODY GUIDE |
| 022 | 3.200.0002 | O-RING GASKET 90X2,5 |
| 023 | 3.001.0029 | BEARING |
| 024 | 4.605.0041 | PLATE 9.30' |
| 025 | 3.002.0003 | HEXAGON SOCKET HEAD CAP SCREW M8X25 UNI 5931 ZNT |
| 026 | 4.607.0208 | AXIAL BEARING |
| 027 | 5.009.0088 | PISTON ASSY D.15 CERAMIC |
| 028 | 4.007.0011 | PISTON RECALL SPRING D.15 30L .42 |
| 030 | 3.002.0032 | SCREW TCEI M8X30 UNI 5931 ZNT |
| 031 | 3.002.0004 | SCREW STEI 3/8 G.DIN 906 (OIL LOAD CAP) |
| 032 | 3.099.0003 | OIL LEVEL INDICATOR SLNS-3/8 H OBBY |
| 033 | 4.005.0184 | BEST BODY GUIDE WITH WINGS '01 |
| 034 | 3.099.0301 | OIL CAP ZIGRIN. WITH HOLEGOLD |
| 035 | 5.009.0207 | CAP ASSY |
| 036 | 3.201.0002 | O-RINGBADSLSF 15X25,4X5 /7 |
| 037 | 3.200.0019 | O-RING 12.4X1.78 SH.90 |
| 038 | 5.009.0346 | Sobstitued by 5.009.1006 SUCTION VALVE WITH PLATE AND SEAT |
| 039 | 5.009.0101 | CAP VALVE SUCTION DELIVERY-OR MOUNTED |
| 040 | 5.609.0064 | VALVE CAP ASSY + OR |
| 041 | 3.099.0136 | PIN 2X12 UNI 1708 |
| 042 | 4.606.0093 | Sobstitued by 4.606.0206 PRESSURE REGULATION KNOB |
| 044 | 3.200.0046 | O-RING 21,95X1,78 REF.2087 |
| 045 | 4.607.0207 | SPRING PRESSURE REGULATION |
| 047 | 4.607.0206 | PLATE FOR SPRING |
| 048 | 5.609.0151 | Sobstitued by 5.609.0205 ROD ASSY FOR BRASS HEAD |
| 049 | 5.609.0080 | SEAL SEAT ASSY +OR |
| 050 | 3.106.0001 | Sobstitued by 3.106.0034 SECURITY VALVE G1/4 M D6 200 BAR |
| 051 | 4.607.0263 | Sobstitued by 4.007.0181 REVOLVING JOIN 3/8 F-3/8 M 1/4 F |
| 052 | 5.609.0079 | OUTLET COUPLING FOR BRASS HEAD |
| 053 | 4.607.0259 | NO RETURN VALVE SPRING L=20 |
| 054 | 5.609.0041 | NON RETURN VALVE + OR ASSEMBLY |
| 055 | 4.606.0085 | BRASS HEAD |
| 056 | 4.606.0001 | 1/4G CAP |
| 057 | 3.002.0078 | HEXAGON SOCKET HEAD CAP SCREW M8X40 UNI 5931 ZNT |
| 058 | 3.004.0022 | WASHER SNHOR D.8X13 SP.0,8 |
| 059 | 5.609.0158 | ASSEMBLY CONNECTOR 1/8 G + CAP M7 TS |
| 060 | 5.609.0107 | BOX+MICRO+CABLE 3X1 FOR TS BRASS HEAD '99 |
| 065 | 3.704.0005 | AIR PRESSURE SWITCH PS2 1/4M 45BAR |
| 069 | 4.608.0105 | BRASS HEAD VALVE SPACER |
| 070 | 3.201.0018 | WATER SEAL RING |
| 071 | 4.608.0106 | ANTIEXTRUSION RING |
| 072 | 3.200.0003 | O-RING GASKET 25,12X1,78 REF.2 100 |
| 073 | 4.606.0040 | SECOND SEALING BUSHING 130/8 O T. ESP.4 |
| 074 | 3.201.0003 | WATER SEALING RING N.15X22X4 |
| 075 | 4.606.0041 | SECOND SEALING HOLDER RING 130 /8 ESP.1 |
| 076 | 4.008.0391 | OIL SEAL SPACER |
| 077 | 3.200.0004 | O-RING GASKET 12,4X1,78 REF.20 50 |
| 078 | 5.009.0561 | Sobstitued by 5.609.Y154 CONNECTOR X DETERGENT SUCTION D.1 + OR |
| 079 | 3.005.0001 | BALL INOX 420 DIAM.5 DEGREE OF ACCURACY G 500 |
| 080 | 4.007.0323 | SPRING FOR DETERGENT VALVE De4.5-7 L=7 WIRE D.0.4 INOX |
| 081 | 5.606.0053 | Sobstitued by 8.680.0088 MOTOR LW.M 230-50 |
| 082 | 5.007.0063 | CERAMIC PISTON BODY GUIDE |
| 083 | 5.008.0145 | BRASS HEAD '99 INIET.D.2,1 TS X HOT HICH PRESSURE CLEANER |
| 086 | 3.406.0020 | TIGHT ANTI-TEARING CABLE HOLDER PG.13,5 |
| 087 | 3.404.0007 | CAPACITOR 65mF 450V D.50XL120 W/WIRES AND FASTON MALE |
| 088 | 3.099.0054 | FEATHER KEY 5X5X20 UNI 6604 |
| 089 | 4.606.0114 | CONVEYOR THICKNESS FOR MOTOR D.135 |
| 090 | 4.608.0133 | GASKET FOR MOTOR CONVEYOR D135 |
| 091 | 3.099.0023 | CAPACITOR BLOCKAGE STRIP D.50 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor NPX 1400 - 86050086
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
