Lavor Original Parts for Pressure Cleaner SUPERWASH 160 - 80620908
€3.32
Tax included
Lavor Original Parts for Pressure Cleaner SUPERWASH 160 - 8.062.0908
We have the original Lavor Original Parts for Pressure Cleaner SUPERWASH 160, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Pressure Cleaner SUPERWASH 160 - 8.062.0908. All Spares are original and can be supplied at Low and discounted prices and Come with a Guarantee
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner SUPERWASH 160 - 8.062.0908
Fix Your Pressure Cleaner SUPERWASH 160 - 8.062.0908. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee
Open PDF File in this Page to choose Spare Parts for Pressure Washer Lavor.
| SUPERWASH 160 80620908-1 - CHASSIS Pag.1 | ||
| # | Part Num. | Description |
| 001 + 002 | 6.005.0324 | WHEELS + CAPS |
| 003 | 4.007.0290 | FIXING AXLE FOR WHEEL |
| 004 | 4.008.0986 | BACK COVER MACH FOR WHEELS D.180 |
| 005 | 4.013.0493 | YELLOW FRONT COVER MACH'05 (PANT.108C) WITH PAD S.WASH 160 |
| 006 | 4.008.0967 | LANCE SUPPORT FOR MACH |
| 008 | 4.008.0987 | Substituted by 6.005.0235 LANCE SUPPORT MACH |
| 010 | 5.009.0213 | SWITCH WITH PROTECTION 12(10) |
| 011 | 4.008.0785 | ACCESSORIES HOLDER |
| 012 | 4.008.0947 | HANDLE FOR TIGER'05 |
| 013 | 5.011.0081 | KIT HANDLE |
| 014 | 4.008.0517 | SUBSTITUITED BY 4.008.1216 WINDING WHEEL |
| 015 | 5.009.0619 | COMPLETE HOSE REEL + HOSE Mt10X MACH |
| 016 | 4.008.0172 | TRANSPARENT TUBE D.6X9 L.510 |
| 017 | 4.007.0334 | SUPPORT FOR H.P.HOSE COILER X SUPERWASH |
| 019 | 5.011.0084 | TANK COMPLETE MACH BLACK + TAP |
| 020 | 4.008.0786 | CABLE HOLDER |
| 021 | 6.001.0065 | GUN S'01DM WITH PRESSURE GAUGE |
| 023 | 3.601.0074 | BLACK/YELLOW ROTATING BRUSH |
| 024 | 3.601.0075 | CAR BOX LT0.5 LWS + CB8013298011490 NL/BE-SF-S-N-GR |
| 025 | 3.100.0082 | QUICK COUPLING INLET CONNECTOR(THREAD=11.5) |
| 026 | 3.100.0342 | BLACK/YELLOW FAST CONNECTION FOR HOSE 1/2G WITH WATER-STOP ( |
| 027 | 4.007.0114 | NOZZLE CLEANING PIN |
| 028 | 6.002.0304 | LANCE SY'03 D.1,15 (YELLOW)-BLACK HANDLE (PRESS. REGULATION |
| 029 | 6.X02.0222 | ROTOX BRASS LANCE S97 1,10 (YELLOW) new 6.002.0223 |
| 030 | 5.009.0595 | NOZZLE D.1.15 (YELOW) +O-RING |
| 031 | 4.014.0003 | SEAT FOR NOZZLE DIAM 11X3,2 ESP. 02 |
| 032 | 4.014.0004 | CERAMIC NOZZLE SPHERICAL RAY 2.5 |
| 033 | 4.012.0161 | ELECTRIC CABLE H05VV-F 3G1,5 MT.5,4 F/F GB PLUG |
| 034 | 4.018.0078 | HOSE 160 bar L=315mm (FROM PUMP TO H.P.HOSE COILER) |
| 035 | 7.100.1369 | MANUAL FOR SUPERWASH 160 LIDL'07-GR-GB/IRL-N-S-SF-BE/NL- |
| SUPERWASH 160 5Y010562-1 - MOTORPUMP Pag.2 | ||
| 000 | 5.Y01.0562 | Substituted by 5.001.0679 MOTORP.PT'03 125h100 240/50 D.12' TS IN.1,7 (MACH) |
| 001 | 3.404.0016 | CAPACITOR 45mF 450V D.45X90 WITHOUT CABLE FASTON M |
| 007 | 4.008.0922 | OVER FOR MOTOR FAN (MOTOR'96) |
| 009 | 6.005.0251 | KIT 168 LW RING+FAN |
| 011 | 3.001.0020 | RADIAL BEARING FOR POSTERIOR FLANGE 17X40X12 6203 2RS |
| 014 | 4.X05.0226 | FRONT FLANGE MOTOR D.125H100 PT'03 W/THREAD |
| 015 | 3.201.0001 | OIL SEAL 20/35/6/6,5 BABSL |
| 016 | 3.001.0031 | ANTERIOR RADIAL FOR CASING 20X52X15 - 6304 |
| 017 | 4.005.0225 | INCLINATED PLATE 12 DEGREE X PT'03 |
| 019 | 4.007.0328 | THRUST BEARING 35X55X12 PT'03 |
| 020 | 6.005.0181 | KIT 167 LW PISTON |
| 022 | 6.005.0226 | KIT 209 O-RING |
| 024 | 6.005.0183 | KIT 169 LW INJECTOR 1,7 |
| 025 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 026 | 6.005.0184 | KIT 170 LW HEAD VALVE KIT |
| 027 | 4.005.0210 | '03 PARTNER HEAD |
| 028 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
| 029 | 6.005.0134 | KIT 125 O-RING SEAL |
| 030 | 4.005.0211 | PISTON BODY GUIDE PT'03 WITH HOLE FOR SUCTION |
| 031 | 5.009.0631 | 99' MOTOR ASSEMBLY D.125H100 240/50 2P |
| 032 | 5.007.0203 | Substituted by 5.007.0229 GUIDE BODY PT'03 PISTONS D.12+ TS + ASPIRATION + SPRING17kg |
| 033 | 5.008.0182 | Substituted by 5.008.0182C - HEAD PARTNER PT'03 D.12 |
| 034 | 5.Y09.0596 | Substituted by 5.009.0596 COMPLETE VALVE TS PT'03 CABLEL=510 (SPRING 17kg) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor SUPERWASH 160 - 80620908
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
