Lavor Original Parts for Pressure Cleaner Idro Tuono 20
€14.81
Tax included
Lavor Original Parts for Pressure Cleaner Idro Tuono 20
Fix Your Cold Water High Pressure Cleaner 80740801 - Idro Tuono 20 230-240/50 -GR/G- TS EU AVV. (ARM.) LWS. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner Idro Tuono 20
Fix Your Cold Water High Pressure Cleaner 80740801 - Idro Tuono 20 230-240/50 -GR/G- TS EU AVV. (ARM.) LWS. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| 80740801 - IDRO TUONO 20 230-240/50 -GR/G- TS EU AVV. (ARM.) LWS - pag.1 | ||
| # | Part Num. | Description |
| 0 | R50010805 | MOTOP.PT'03 110h100ALL 230-240/50 D.12 8°30 TS IN.1,7 |
| 0 | R50110129 | ASSIEME AVVOLG. COMPLETO+MANICO TEMPESTA C/ADATT. PIST.S'09 |
| 001 | 4.013.0784 | CARENATURA ANT.RUNNER -GR- RAL.7046 (X MOT.INDUZ.) C/TAMP.LAVOR |
| 002 | 4.007.0291 | FIXING CLAMP FOR MOTOR PUMP D.110 |
| 003 | 4.008.0922 | COVER FOR MOTOR FAN (MOTOR'96) |
| 004 | 6.005.0323 | ACCESSORY HOLDER KIT |
| 005 | 3.401.0178 | SWITCH 0/1 BLACK BOTTON IP55 12/10 |
| 006 | 6.005.0237 | 220 HANDLE RUNNER |
| 007 | 5.001.0805 | MOTORPUMP.PT'03 110h100AL 230-240/50 D.12 8°30 TS W/SUCTION |
| 008 | 5.011.0086 | DETERGENT TANK |
| 009 | 4.012.0149 | CABLE H05VV-F 3X1 SCHUKO PLUGMT.5,4 F/F rev 04 |
| 010 | 6.005.0324 | WHEELS KIT |
| 011 | 4.007.0290 | FIXING AXLE FOR WHEEL |
| 012 | 4.008.0986 | BACK COVER MACH FOR WHEELS D.180 |
| 013 | 6.001.0073 | GUN S'09 WITH INTEGRAL QUICK JOINT LAVOR |
| 014 | 4.018.0089 | TUBO 1/4 210BAR L=8000 R1 GOMMA 1/4F-90'3/8F TEMPOR./TEMPES. |
| 015 | 6.002.0215C | Substituted by 6.002.0191C LANCE S'99 1.025 H/L |
| 017 | 6.002.0340 | LANCE S'12 WITHOUT NOZZLE HEADWITH QUICK COUPLING/COGETIL |
| 025 | 6.005.0233 | KIT 216 LW |
| 026 | 4.018.0090 | HOSE 1/4 210BAR L=750 FOR HOSEREEL |
| 027 | 3.404.0094 | CAPACITOR 32mF 450V |
| 80740801 - IDRO TUONO 20 230-240/50 -GR/G- TS EU AVV. (ARM.) LWS - pag.2 | ||
| 001 | 6.005.0237 | KIT 220 HANDLE RUNNER |
| 002 | 6.005.0233 | KIT 216 LW |
| 003 | 4.018.0090 | HOSE 1/4 210BAR L=750 FOR HOSEREEL |
| 004 | 4.018.0089 | TUBO 1/4 210BAR L=8000 R1 GOMMA 1/4F-90'3/8F TEMPOR./TEMPES. |
| 005 | 5.009.0751 | ADAPTER FOR GUN S'09 1/4 +OR |
| 80740801 - IDRO TUONO 20 230-240/50 -GR/G- TS EU AVV. (ARM.) LWS - pag.3 | ||
| 0 | R50090703C | GRUPPO CORPO GUIDA C/TS-ASP.-VAL.COMP.-M.13KG+TESTATA (PT'03) |
| 0 | R50091015 | ASS.MOTORE D.110H100ALL 230-240/50 2P +PIATT.8°30 |
| 001 | 6.005.0253 | KIT 236 LW FAN + RING |
| 002 | 5.009.1015 | ASS.MOTORE D.110H100ALL 230-240/50 2P +PIATT.8°30 |
| 003 | 3.001.0033 | BALL BEARING 6003 2RS (17x35x10) |
| 009 | 4.007.0328 | THRUST BEARING 35X55X12 PT'03 |
| 010 | 5.009.0703C | BODY GUIDE+HEAD ASSEMBLED TS WITH SUCTION (SPRING 13KG) -PT |
| 80740801 - IDRO TUONO 20 230-240/50 -GR/G- TS EU AVV. (ARM.) LWS - pag.4 | ||
| 001 | 5.002.0148 | HOUSING '02 D110 H100AL 230-240/50 2P |
| 002 | 3.001.0020 | RADIAL BEARING FOR POSTERIOR FLANGE 17X40X12 6203 2RS |
| 003 | 5.005.0071 | ROTOR FOR 110H100AL |
| 005 | 4.005.0219 | FRONT FLANGE D.110 PT'03 |
| 006 | 3.201.0008 | OIL SEALING RING D. 17X35X7 |
| 007 | 3.001.0030 | RADIAL |
| 008 | 4.005.0278 | WOBBLE PLATE 8'30 PT'03 |
| 80740801 - IDRO TUONO 20 230-240/50 -GR/G- TS EU AVV. (ARM.) LWS - pag.5 | ||
| 0 | R50070187C | CORPO GUIDA PT'03 PIST.D.12 C/ TS-ASP.-VALV.COMP.-M.13KG |
| 0 | R50080182C | TESTATA PT'03 D.12 -C- |
| 001 | 5.007.0187C | PISTON BODY GUIDE PT'03 WITH TS/COMP.VALVE/SPRING 13KG/SUCTI |
| 002 | 5.008.0182C | PUMP HEAD PARTNER '03 D.12 |
| 002 | 6.005.0282 | KIT 257 O-RING SEAL |
| 80740801 - IDRO TUONO 20 230-240/50 -GR/G- TS EU AVV. (ARM.) LWS - pag.6 | ||
| 001 | 5.009.0716 | COMPLETED VALVE TS PT'03 CABLEL=530 SPRING 13KG (WHITE FAST |
| 002 | 6.005.0183 | KIT 169 LW INJECTOR 1,7 |
| 003 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 004 | 6.005.0226 | KIT 209 O-RING |
| 005 | 4.008.1176 | GASKET PISTON BODY GUIDE-HEADPT'03 29.7X12.9X2.7 |
| 006 | 6.005.0181 | KIT 167 LW PISTON |
| 80740801 - IDRO TUONO 20 230-240/50 -GR/G- TS EU AVV. (ARM.) LWS - pag.7 | ||
| 001 | 6.005.0184 | KIT 170 LW HEAD VALVE KIT |
| 002 | 4.005.0210C | '03 PARTNER HEAD |
| 003 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
| 004 | 6.005.0282 | KIT 257 O-RING SEAL |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor Tuono 20 80740801
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
