Lavor Original Parts for Pressure Cleaner Idro Planet 140
€6.84
Tax included
Lavor Original Parts for Pressure Cleaner Idro Planet 140
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner 81100005C - IDRO PLANET 140 230-240~50/60 -G/GR- TS EU +SP.L25 LWS.Fix Your Pressure Cleaner. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner Idro Planet 140
Fix Your Cold Water High Pressure Cleaner 81100005C - IDRO PLANET 140 230-240~50/60 -G/GR- TS EU +SP.L25 LWS.. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| 81100005C - IDRO PLANET 140 230-240~50/60 -G/GR- TS EU +SP.L25 Pag.1 | ||
| # | Part Num. | Description |
| 0 | 50010834C | MOTOP.SP.PT'03EVO 230/50 C/TERM.-ASP. 5'30 TS MOLLA 13KG (7645PF-KC) |
| 0 | 50110274 | ASS.SERBATOIO SPACE +TAPPO |
| 001 | 3.401.0178 | SWITCH 0/1 BLACK BOTTON IP55 12/10 |
| 002 | 5.011.0345 | ASSIEME CAREN. -GR- + COPERT.ANT. -G- PLANET C/TAMP.-LAVOR- |
| 003 | 4.008.1149 | BLACK CAP FOR ELECTRICAL BOX STORM II (P80.0425) |
| 004 | 4.008.1172 | AIR CONVEYOR FOR U76 |
| 005 | 4.012.0174C | CABLE H05VV-F 2X1 MT.5,4 F/F SCHUKO PLUG W/FASTON COVER |
| 006 | 4.008.2029 | MANICO SPACE PER AVV. -GR- RAL.7016 (PANT.432C) (P80.0612) |
| 007 | 4.008.1484 | BLACK HALF HOSE SIDE REEL WITHPIN RAL.9011 020567/020561 (8 |
| 008 | 4.008.1483 | BLACK HALF LEVER SIDE REEL RAL.9011 FOR 020567/020561(800071 |
| 009 | 5.011.0346 | ASSIEME MANOVELLA PER SPACE/IKON C/AVV. -GR- |
| 010 | 5.011.0274 | ASS.SERBATOIO SPACE +TAPPO |
| 011 | 4.008.1975 | PORTACCESSORI POSTERIORE SPACE -G- PANT.108C (P80.0612) |
| 012 | 4.008.1773 | GREY WHEEL WITH BLACK COAT SPACE |
| 013 | 4.013.0242 | CARENATURA POSTERIORE SPACE -GR- RAL.7016 (PANT.432C) (P80.0612) |
| 014 | 4.408.0008 | SUPPORT PAD |
| 015 | 5.001.0834C | MOTORPUMP PT'03EVO 230/50 W/THERMAL-SUCTION TS 5'30 (7645PF- |
| 016 | 4.008.0031 | INLET WATER FILTER H2O D.16 CONICAL |
| 017 | 7.100.2074 | MANUAL SPACE + CE LAVOR 27L A516F |
| 018 | 6.001.0130 | PISTOLA S'09 C/ATTACCO RAPIDO INTEGR. C/LEVA -GR- RAL.7046 |
| 019 | 4.018.0095 | HOSE 1/4 180BAR L=6000 M22x1,5D.15-RAPID FIX |
| 020 | 6.002.0361 | LANCIA S'12 S/TESTINA C/ATT.RAP.-COGETIL + SPILLO |
| 021 | 6.002.0636 | NOZZLE HEAD LANCE S'12 D.0,95(ORANGE) ADJUST.FAN JET W/QUI |
| 022 | 6.002.0346 | ROTOX NOZZLE HEAD LANCE S'12 D.1,025 WITH QUICK COUPLING |
| 023 | 6.002.0634 | SOAP HEAD LANCE S'12 W/QUICK COUPLING |
| 024 | 3.100.0082C | BLACK QUICK COUPLING INLET CONNECTOR (THREAD=9.5) |
| 025 | 3.601.0111 | YELLOW FLOOR BRUSH L25 WITH EXTENSION (D.1,1) |
| 50110274 - ASS.SERBATOIO SPACE +TAPPO Pag.2 | ||
| 001 | 4.008.1521 | BLACK PLUG FOR TANK -RAL.9011-(80007138) |
| 002 | 4.008.1776 | NEUTRAL TANK SPACE |
| 50010834C - MOTOP.SP.PT'03EVO 230/50 C/TERM.-ASP. 5'30 TS MOLLA 13KG Pag.3 | ||
| 0 | 50090839C | GRUPPO CORPO GUIDA C/TS-ASP.-VAL.COMP.-M.13KG +TESTATA (PT'03EVO) |
| 001 | 5.009.0979 | 7645PF-AL KC MOTOR 230/50 W/CAPACITOR-THERMAL |
| 002 | 4.008.1164 | RING FOR FLANGE X MOTOR U96AF/U76 -C- |
| 003 | 6.005.0311 | THRUST RING KIT (PT'03 U76) |
| 004 | 4.007.0205 | PIN 10X70 |
| 005 | 5.009.0726 | 5'30 WOBBLE PLATE ASSEMBLY W/CROWN Z 62 (PT'03) |
| 006 | 4.007.0328 | THRUST BEARING 35X55X12 PT'03 |
| 007 | 5.009.0839C | BODY GUIDE+HEAD ASSEMBLED TS WITH SUCTION (SPRING 13KG) -PT' |
| 50090839C - GRUPPO CORPO GUIDA C/TS-ASP.-VAL.COMP.-M.13KG +TESTATA Pag.4 | ||
| 0 | 50070249 | CORPO GUIDA PT'03EVO PIST.D.12 C/TS-VALV.COMP. C/ASP. MOLLA 13KG |
| 0 | 50080261 | TESTATA PT'03EVO D.12 |
| 001 | 5.007.0249 | BODY GUIDE ASSEMBLED PT'03EVOWITH TS/COMP.VALVE/SUCTION S.1 |
| 002 | 6.005.0282 | KIT 257 O-RING SEAL |
| 003 | 5.008.0261 | PT'03EVO HEAD D.12 |
| 50070249 - CORPO GUIDA PT'03EVO PIST.D.12 C/TS-VALV.COMP. C/ASP. Pag.5 | ||
| 001 | 4.005.0300 | PISTON BODY GUIDE PT'03EVO WITH SUCTION |
| 002 | 5.009.0716 | COMPLETED VALVE TS PT'03 CABLEL=530 SPRING 13KG (WHITE FAST |
| 003 | 6.005.0181 | KIT 167 LW PISTON |
| 004 | 6.005.0226 | KIT 209 O-RING |
| 006 | 6.005.0277 | KIT 252 |
| 007 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 50080261 - TESTATA PT'03EVO D.12 Pag.6 | ||
| 001 | 4.005.0298 | PT''03EVO PARTNER HEAD |
| 002 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
| 003 | 6.005.0380 | KIT 348 SPACER FOR WATER SEAL |
| 003 | 6.005.0588 | KIT LW VALV.ASP./MAND.+TAPPI PT' 03EVO |
| 004 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 005 | 6.005.0392 | KIT 358 LW HEAD VALVE KIT +CAPS PT'03EVO |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor Planet 140 81100005C
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
