Mountfield MC 3720 Spare Parts
€1.56
Tax included
Mountfield MC 3720 Chainsaw Spare Parts
We supply original Mountfield spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance or repair issues for Chainsaw MC 3720 - 228116013/M15 - 2020. Open PDF Technical drawing to chose all spare parts.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Mountfield MC 3720 Chainsaw Spare Parts
We supply original Mountfield spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance or repair issues for Chainsaw MC 3720 - 228116013/M15 - 2020. Open PDF Technical drawing to chose all spare parts.
In the following table, look for the model of the Petrol Chainsaw and the respective parts of the code.
| Mountfield Chainsaw MC 3720 Spare Parts Pag.1 |
||
| Engine - Cylinder - Piston - Crank Shaft | ||
| Pos. | Code | Description |
| 1 | 118800242/0 | Cylinder Assy. |
| 2 | 123120014/0 | Nut |
| 3 | 112581500/0 | Grower |
| 4 | 123657013/0 | Washer |
| 5 | 112735654/0 | Screw |
| 6 | 118800243/0 | Plate |
| 7 | 118550582/0 | Muffler |
| 8 | 118550583/0 | Gasket Muffler |
| 9 | 118550584/0 | Screw |
| 10 | 2135030 | Screw |
| 11 | 3210024 | Spark Plug |
| 12 | 118550585/0 | Intake Manifold Gasket |
| 13 | 118550586/0 | Intake Manifold |
| 14 | 118550587/0 | Carburetor Gaskets |
| 15 | 118550588/0 | Cylinder Sealing Gasket |
| 16 | 118550589/0 | Piston Ring |
| 17 | 118800244/0 | Piston Pin |
| 18 | 118550590/0 | Piston Circlip |
| 19 | 118800245/0 | Piston |
| 20 | 118800246/0 | Needle Bearing Ring |
| 21 | 118550591/0 | Needle Bearing |
| 22 | 118800247/0 | Crankshaft |
| 23 | 118800959/0 | Woodruff Key 3 X 3.5 X 10 |
| 24 | 118800248/0 | Left Crankcase |
| 25 | 3112030 | Ball Bearing |
| 26 | 118800249/0 | Crankcase Gasket |
| 27 | 118800250/0 | Right Crankcase |
| 29 | 118550592/0 | Oil Seal |
| 30 | 2135050 | Screw |
| 31 | 118550593/0 | Screw |
| 34 | 118550596/0 | Spiked Grip |
| 35 | 2135180 | Screw |
| 36 | 118550597/0 | Chain Guard |
| 37 | 118800251/0 | Screw |
| 38 | 118550598/0 | Bar Plate |
| 39 | 123878020/0 | Screw |
| 40 | 118550599/0 | Oil Seal |
| 41 | 118804679/0 | Ignition Coil |
| 42 | 123878021/0 | Screw |
| 43 | 112581200/0 | Grower |
| 44 | 118550601/0 | Earth Cable |
| 45 | 123120008/0 | Nut |
| 46 | 118804678/0 | Flywheel Assy |
| 51 | 118550603/0 | Clutch Assy |
| 55 | 118800252/0 | Clutch Washer |
| 56 | 118550604/0 | Clutch Drum |
| 57 | 118550605/0 | Needle Bearing |
| 58 | 118550606/0 | Worm Gear |
| 59 | 118800253/0 | Oil Pump Cover |
| 60 | 118550607/0 | Oil Pump Assy. |
| 61 | 118800254/0 | Oil Outgoing Tube |
| 62 | 118550608/0 | Worm Washer |
| 63 | 118800255/0 | Oil Pick-up Tube |
| 65 | 118800256/0 | Oil tube Connection |
| 66 | 118550609/0 | Oil Filter Assy. |
| 67 | 118802952/0 | Oil Spry Nozzle |
| 70 | 8724091 | Diaphragm Gasket Set |
| 71 | 118800210/0 | Carburetor |
| 72 | 118800211/0 | Intake Manifold |
| 73 | 118800212/0 | Screw |
| 74 | 118804231/0 | Primer |
| 75 | 118800204/0 | Pump Tube |
| 76 | 3657050 | Spring Spark Plug |
| 77 | 3748880 | Spark Plug Cap |
| 78 | 118805029/0 | Engine Block Assy. |
| 79 | 118805099/0 | Cylinder Assy. |
| 80 | 118805101/0 | Piston Assy. |
| 81 | 118805103/0 | Muffler Assembly |
| Chassis Pag.2 |
||
| 1 | 118800183/0 | Black Clutch Cover Assy |
| 2 | 112728710/0 | Screw |
| 5 | 118800184/0 | Front Damper |
| 6 | 118800748/0 | Balance Weight |
| 7 | 123430572/0 | Spring |
| 8 | 118800747/0 | Spring |
| 10 | 112154320/0 | Nut |
| 11 | 323670001/0 | Plate |
| 12 | 118800745/0 | Spring |
| 13 | 118800257/0 | Tensioner Cover Plate |
| 14 | 123753001/0 | Pin |
| 15 | 383315051/0 | Chain Brake Lever |
| 17 | 123753000/0 | Pin |
| 18 | 323315067/0 | Brake Hook Lever |
| 20 | 118800185/0 | Brake Band |
| 21 | 123878023/0 | Screw |
| 25 | 118800186/0 | Nut |
| 26 | 118800187/0 | Air Filter Lock Nut |
| 27 | 118800258/0 | Washer |
| 28 | 118800260/0 | Red Air Filter Cover |
| 29 | 118800188/0 | Air Filter |
| 30 | 118800262/0 | Red Cylinder Cover |
| 31 | 118800742/0 | Dust Shield |
| 34 | 118800189/0 | Screw |
| 35 | 118800263/0 | Rubber |
| 37 | 118800264/0 | Idle Adjusting Guide Set |
| 38 | 118800190/0 | Choke Lever |
| 40 | 118800191/0 | Recoil Assembly Black |
| 44 | 118800192/0 | Starter Pulley |
| 46 | 118800278/0 | Starter Spring |
| 47 | 118800193/0 | Starter Handle |
| 50 | 112728450/0 | Screw |
| 51 | 118800266/0 | Self-tapping Screw 4.8 X 19 |
| 52 | 112735654/0 | Screw |
| 53 | 118800194/0 | Shock Absorber |
| 54 | 118800195/0 | Dust Cap |
| 55 | 118800196/0 | Spring |
| 56 | 118800197/0 | Front Handle |
| 59 | 323208402/0 | Plate |
| 60 | 118800198/0 | Breathing Valve Assy |
| 64 | 118800744/0 | Rubber |
| 65 | 112728124/0 | Screw |
| 66 | 118800255/0 | Oil Pickup Tube |
| 67 | 118800214/0 | Fuel Filter Assy |
| 68 | 118800200/0 | Handle Assy |
| 69 | 118800201/0 | Spring |
| 72 | 118800199/0 | Filter Fuel |
| 76 | 118800202/0 | Switch |
| 79 | 118800205/0 | Safety Lever |
| 80 | 118800206/0 | Spring |
| 81 | 118800207/0 | Throttle Lever |
| 82 | 118800208/0 | Spring |
| 83 | 118800209/0 | Handle Cover |
| 88 | 118800213/0 | Earth Cable |
| 89 | 118800752/0 | Engine Cover |
| 91 | 118800215/0 | Fuel Tank Cap |
| 92 | 118800216/0 | Oil Tank Cap |
| 93 | 118550594/0 | Tension Block |
| 94 | 118550595/0 | Screw |
| 95 | 118800128/0 | Guide Bar 16"-3/8"-0.050" |
| 96 | 118801745/0 | Chain 16"-3/8"-0.050"-57E |
| 97 | 118805030/0 | Front Handle Assy. |
| 98 | 118805031/0 | Engine support assembly |
| 200 | 1111-9228-01 | Mineral Chain Oil 1Lt |
| 201 | 1111-9229-01 | Mineral Chain Oil 5Lt |
| 202 | 1111-9276-01 | Biodegradable Chain Oil 1LT |
| 203 | 1111-9247-01 | Biodegradable Chain Oil 5LT |
| 300 | 1111-9230-01 | 2-Stroke Synthetic Engine Oil 1 Lt, Dozer |
| 301 | 1111-9231-01 | 2-Stroke Synthetic Engine Oil 0.1 Lt |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Castelgarden websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Castelgarden brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
