Makita Spare Parts for Angle Grinder 9554HN

€3.34
Tax included

Makita Spare Parts for Angle Grinder 9554HN

Makita genuine spare parts or replacement parts for to repair Angle Grinder 115 mm 710W 9554 HN.

- With 710 Watt power input
- Disc Ø 115 mm
- No-load speed 10000 min
- Type M14
ITEM CODE: 210033-9
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Angle Grinder 9554HN

Makita genuine spare parts or replacement parts for to repair Angle Grinder 115 mm 710W 9554 HN.

In the following table, look for the model of the angle grinder and theirs spare parts codes.

ANGLE GRINDER 115MM 710 W 9554HN
# Part Num. Description
1 621713-6 STATOR FIELD 9554NB
2 418795-5 VANE X 9554NB
3 421868-5 RUBBER RING X 9554NB
4 210034-7 BEARING 607LLB X 9554NB
5 681636-0 INSULATOR
6 515619-7 ARMATURE X 9554NB
7 240076-7 FAN 56 X 9554NB
8 317821-6 COVER GEAR BOX X 9554NB
9 213445-5 RING 26 X 9554NB
10 210042-8 BEARING FOR 629LLB GD0600
11 227541-3 GEAR 10
12 252186-8 NUT M6 X 9554NB
13 417771-6 BUTTON X MT952
14 233376-2 SPRING COMP. 8 X MT952
15 266050-7 SCREW 4X30 PT
16 213960-9 RING 5 X 9554NB
17 256486-8 PIN LOCK DISC 9557NB
18 317814-3 GEAR BOX X 9554NB
19 263002-9 RUBBER PIN 4
20 210033-9 BEARING 696ZZ X 2107FK
21 961052-5 RETAINING RING S12
22 267794-2 WAVY WASHER 12 X 9554NB
23 227542-1 GEAR 37
24 962151-6 RETAINING RING R32
25 211129-9 BALL BEARING NSK 6201DD
26 267238-2 WASHER 12 X MT952
27 213622-9 RING 45 X 9554NB
28 318331-6 BOX X BEARING 9554NB
29 265099-4 SCREW M4 X 14 X 9554NB
30 345464-4 DUST RING X 9554NB
31 254011-9 KEY CRESCENT 4
32 324489-1 POST X-9554NB
33 265180-1 SCREW M5x16
34 123098-1 CAP DISC 115AK
35 224415-9 RECIEVE WASHER 42 GA95010
36 224554-5 CLAMP WASHER 14-45 X 9541
37 266325-4 SCREW M 4 X 70 X MT952
39 266007-8 SCREW M3 X10 HP2030
40 643760-7 CARBON BRUSH HOLDER BO6040
41 194074-2 CARBON BRUSHE SET CB-325 X-9554NB
43 651947-7 SWITCH 9527PB-9528PB
44 687124-5 CLAMP MT953 ties
45 265995-6 SCREW M4X18 X 6408 / 6221DW
46 645233-6 CAPACITOR X 9554NB
47 682559-5 CORD ARMOR X 6822
49 419566-3 BUTTON SWITCH 9554NB
50 451126-5 MOTOR HOUSING X 9554NB
51 643760-7 CARBON BRUSH HOLDER BO6040
52 233121-5 COMPRESSION SPRING 4 X 9554NB
53 418796-3 SWITCH LEVER X 9554NB
54 418726-4 BACK COVER X 9554NB
55 265995-6 SCREW M4X18 X 6408 / 6221DW
56 213009-5 RING 4

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita 9554HN
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS APPROX
MORE INFO:
info@bricoutensili.com
New

Download

Diagram Makita 9554HN

Diagram Makita 9554HN

Download (48.02KB)
