Makita Spare Parts for Rotary Hammer HR3850B
€288.66
Tax included
Makita Spare Parts for Rotary Hammer HR3850B
Makita genuine spare parts or replacement parts for to repair Rotary Hammer HR3850B.Fix Your Rotary Hammer HR3850B. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Rotary Hammer HR3850B
Fix Your Rotary Hammer HR3850B. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Hammer and the respective parts of the code.
| Rotary Hammer HR3850B | ||
| # | Part Num. | Description |
| 1 | 212551-3 | ROLLER BEARING 4516 |
| 2 | 267057-6 | FLAT WASHER 40XHR3850B |
| 3 | 311674-5 | BARREL X HR3850 / B |
| 4 | 213655-4 | O Ring 56, HR3510 / 20 / HM12 - Hr3851 |
| 5 | 212551-3 | NEEDLE BEARING 4516 |
| 6 | 253832-6 | FLAT WASHER 45XHR3850B |
| 7 | 221347-1 | GEAR 36 X HR3850 / B |
| 8 | 321369-2 | STRIKER X HR3850B |
| 9 | 412038-7 | Piston Ring 34, Hr3851 |
| 10 | 412041-8 | INNER RING 30 |
| 11 | 412038-7 | Piston Ring 34, Hr3851 |
| 12 | 341743-8 | INNER RING PISTON 30 |
| 13 | 321370-7 | PISTON X HR3850 / B |
| 14 | 256029-6 | PIN 8 X HR3850 / B |
| 15 | 411709-3 | CRANK CAP HR3850 / B / HM0810 |
| 16 | 213654-6 | O-RING 60 HR3850B / HM0810 |
| 17 | 312956-8 | Rod, Hm0810B |
| 18 | 212108-0 | Needle Bearing 1212, Hr3851 |
| 19 | 321726-4 | CRANKSHAFT HR3850 / B |
| 20 | 254001-2 | WOODRUFF KEY 4 |
| 21 | 962203-3 | RETAINING RING R47 |
| 22 | 211306-3 | BALL BEARING 6204DD |
| 23 | 213606-7 | O-RING 48 HR3850 / B / HR2510 |
| 24 | 157307-6 | CRANK HOUSING HR3850 / B |
| 25 | 221689-3 | GEAR 33 X HR3850 / B |
| 26 | 212102-2 | NEEDLE BEARING BK 1210 |
| 27 | 212359-5 | NEEDLE BEARING 2216 |
| 29 | 134527-9 | TORQUE LIMITER HR3850 / B |
| 34 | 253314-8 | WASHER 15 X6906 / HR3850B |
| 35 | 421689-5 | O-RING 100 X HR3850 / B |
| 36 | 157306-8 | GEAR HOUSING X HR3850 / B |
| 37 | 263005-3 | RUBBER PIN 6 |
| 38 | 961011-9 | RETAINING RING E4 |
| 39 | 212011-5 | NEEDLE BEARING 609 |
| 40 | 213055-8 | O-RING 10 X HR3850 / B |
| 41 | 321727-2 | CHANGE SHAFT HR3850 / B |
| 42 | 342786-3 | PLATE X HR3850 / B |
| 43 | 216002-8 | Steel Ball 4.8, Wt01W |
| 44 | 231317-2 | SPRING 3 X HR3850 / B |
| 45 | 410331-3 | LEVER X HR3850 / B |
| 46 | 941052-1 | FLAT WASHER 4 |
| 47 | 922126-7 | SCREW M4x16 HR5000K / 3850B |
| 48 | 942101-7 | WASHER 5 |
| 49 | 922212-4 | SCREW M5x12 |
| 50 | 152335-6 | CYLINDER LINER 34 X HR3850 / B |
| 51 | 323718-9 | IMPACT BOLT X HR3850B |
| 52 | 216004-4 | Steel Ball 7.9, HR3520 / HR3850/B |
| 53 | 213428-5 | X RING 28 HR3850 |
| 54 | 213411-2 | O-RING 27 X HR3850 / B |
| 55 | 213411-2 | O-RING 27 X HR3850 / B |
| 56 | 213604-1 | O Ring 50, HR3850 / B - 6911D |
| 57 | 331301-8 | TOOL RETAINER HR3850B |
| 58 | 323717-1 | FRONT COVER NEW HR3850B |
| 59 | 231375-8 | SPRING 15 X HR3850B |
| 60 | 265321-9 | BOLT M8x12 X HR3850B |
| 61 | 922341-3 | SCREW M6X25 |
| 62 | 213459-4 | O Ring 32,HR3850B - 5007F |
| 63 | 211129-9 | BALL BEARING NSK 6201DD |
| 64 | 213160-1 | OIL SEAL 14 XHR3850 / B |
| 65 | 241634-2 | FAN 94 X HR3850 / B |
| 66 | 514773-4 | ARMATURE X HR3850 / B |
| 67 | 681646-7 | Insulation Washer, HM1200 / 3612BR - Hm1211B |
| 68 | 211087-9 | BALL BEARING 6200DDWNSK |
| 69 | 410163-8 | BAFFLE PLATE HM1200 / HR3850 |
| 70 | 265347-1 | SCREW M5X45 |
| 72 | 524633-2 | STATOR FIELD HM1200 / HR3850 / B |
| 73 | 213406-5 | O Ring 30, 58NB / SB / HM1200 - Hr5000 |
| 76 | 159034-1 | MOTOR HOUSING HM1200 / HR3850 / B |
| 77 | 643650-4 | Brush Holder Cap, 5007F |
| 78 | 181048-2 | Carbon Brush Set, CB155 (CB-161) |
| 79 | 284055-5 | REAR COVER HM1200 / HR3850 |
| 80 | 942101-7 | WASHER 5 |
| 81 | 922222-1 | SCREW M5X16 |
| 82 | 922376-4 | SCREW M6x55 |
| 83 | 941151-9 | WASHER 6 X HM1303 |
| 84 | 931301-4 | HEX NUT M6 |
| 85 | 942151-2 | WASHER 6 4101R |
| 86 | 941151-9 | WASHER 6 X HM1303 |
| 87 | 911243-8 | SCREW M5x25 HR2010 |
| 89 | 182077-8 | HANDLE SET XHM1200 / K |
| 90 | 911126-2 | SCREW M4x16 |
| 91 | 421265-5 | DUST COVER HR3850 / B |
| 92 | 273472-4 | KNOB 32 X HR3850 |
| 93 | 924321-5 | SCREW M6x18 |
| 94 | 261049-7 | RUBBER WASHER 5.5 X HR3850 / B |
| 95 | 261049-7 | RUBBER WASHER 5.5 X HR3850 / B |
| 96 | 164543-7 | GRIP BASE X HR3510 / 3850B |
| 97 | 164572-0 | GRIP HOLDER XHR3850 |
| 98 | 922316-2 | BOLT M6 X 14 |
| 100 | 343754-9 | PLATE XHR3850 / HR5000K |
| 102 | 321210-9 | Handle Shaft, 3850/B - Hr3851 |
| 103 | 682505-8 | CABLE SLEEVE 10/90 |
| 105 | 687001-1 | CABLE CLAMP |
| 106 | 911133-5 | SCREW M4X18 |
| 107 | 263002-9 | RUBBER PIN 4 |
| 108 | 263002-9 | RUBBER PIN 4 |
| 109 | 685700-9 | SPONGE SHEET X M802 / HR3850B |
| 110 | 645179-6 | CAPACITOR |
| 111 | 922341-3 | M6X25 SCREW |
| 113 | 651145-3 | SWITCH C3D-H-MS |
| 114 | 262051-3 | RUBBER RING 9-6 XHR3850 |
| 115 | 262052-1 | RUBBER RING 9-3 XHR3850 |
| 116 | 257636-8 | SLEEVE 6 HR3850 |
| 117 | 421596-2 | CAP X HR3850B |
| 118 | 254231-5 | Key 4x2,5x21,5-22, HR3520 / HR3850B - Hr3851 |
| 119 | 654020-2 | TERMINAL RING CB-5 94 |
| 999 | 193281-4 | SERVICE PACK HR3850 / B |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
