Makita Spare Parts for Cordles Angle Grinder BGA452SFE
search
  • Makita Spare Parts for Cordles Angle Grinder BGA452SFE
  • Makita Spare Parts for Cordles Angle Grinder BGA452SFE

Makita Spare Parts for Cordles Angle Grinder BGA452SFE

€34.02
Tax included

Makita Spare Parts for Cordless Angle Grinder BGA452SFE

Makita Genuine spare parts or replacement parts for to repair Cordless Angle Grinder BGA452SFE.

Fix Your Cordless Angle Grinder BGA452SFE. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

ITEM CODE: 188761-3
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Cordless Angle Grinder BGA452SFE

Fix Your Cordless Angle Grinder BGA452SFE. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Cordles Angle Grinder and the respective parts of the code.
Makita BGA452SFE

Cordles Angle Grinder BGA452SFE
# Part Num. Description
1 619218-8 ARMATURE BGA452S
2 317821-6 GEAR HOUSING COVER 9554NB
3 213445-5 O-RING 26 X 9554NB
4 961005-4 EXT DIN 471 CIRCLIP-9
5 210042-8 BALL BEARING 629LLB GD0600
6 227501-5 SPIRAL BEVEL GEAR 19 BGA452S
7 417771-6 BUTTON X MT952
8 233072-2 COMPRESSION SPRING 8 X 9541
9 266361-0 SCREW 4 X 30 X 9554NB
10 213960-9 O-RING 5 X 9554NB
11 256496-5 PIN 4 BGA452S
12 318051-2 GEAR BOX BGA452S
13 263002-9 PIN RUBBER 4
14 210033-9 BEARING 696ZZ X 2107FK
15 961052-5 RETAINER RING S12
16 253744-3 FLAT WASHER 12 24B / 12N / 14
17 227502-3 GEAR FOR 39 BGA452S
18 962151-6 RETAINER RING R32
19 211129-9 BALL BEARING NSK 6201DD
20 267238-2 WASHER 12 X MT952
21 213622-9 RING 45 X 9554NB
22 318331-6 BEARING BOX X 9554NB
23 911121-2 SCREW M4X14X N9500N
24 345464-4 RING DUST X 9554NB
25 254011-9 KEY 4
26 324489-1 SPINDLE X 9554NB
27 265180-1 SCREW M5X16
28 123098-1 WHEEL COVER 115AK
29 224415-9 RECIEVE WASHER 42 GA95010
30 224554-5 CLAMP WASHER 14-45 X 9541
31 631714-6 LED CIRCUIT BGA452S
32 638627-2 FIELD BGD800R
33 638921-2 CARBON BRUSHE HOLDER BGA452S-450
35 266326-2 SCREW 4x18 X MT601
36 419566-3 SWITCH BUTTON 9554NB
37 188761-3 MOTOR HOUSING BGA452S
38 419519-2 SWITCH LEVER BGA452S
39 650579-7 SWITCH 1246.3223
41 643838-6 BATTERY TERMINAL
43 191971-3 CARBON BRUSH SET CB-430
44 643807-7 HOLDER CAP 6347D
45 419518-4 COVER CAP BRUSH
46 421977-0 RUBBER RING 13 X BGA452
48 213009-5 RING 4
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
