Makita Spare Parts for Plate Joiner PJ7000
We are makita original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Plate Joiner PJ7000.
In the following table, look for the model of Plate Joiner and the respective parts of the code.
| Plate Joiner PJ7000 | ||
| # | Part Num. | Description |
| 1 | 922422-3 | HEXAGON BOLT M8x16 |
| 2 | 941202-8 | FLAT WASHER 8 |
| 3 | 453218-6 | HANDLE PJ7000 |
| 4 | 266324-6 | SCREW M 4 X 22 X MT601 |
| 5 | 417771-6 | BUTTON X 9554NB |
| 6 | 234057-1 | SPRING COMPRRESSIONE 6 GA5021C |
| 7 | 252186-8 | NUT M6 X 9554NB |
| 8 | 227545-5 | GEAR FOR 10 GA4530 |
| 9 | 213445-5 | RING 26 X 9554NB |
| 10 | 211092-6 | BALL BEARING 629DD |
| 11 | 962105-3 | RETAINING RING R26 |
| 12 | 413126-3 | CONVEYOR FOR GA4530 |
| 13 | 240107-2 | FAN FOR 56 GA4530 |
| 14 | 517649-4 | ARMATURE FOR GA4530 |
| 15 | 681636-0 | INSULATION WASHER |
| 16 | 210034-7 | BEARING 607LLB X 9554NB |
| 17 | 421868-5 | RING RUBBER X 9554NB |
| 18 | 450796-7 | DEFLECTOR FOR GA4530 |
| 19 | 266325-4 | SCREW M 4 X 70 X MT952 |
| 20 | 635113-4 | STATOR FOR GA4530 |
| 22 | 266492-5 | SCREW M4X25-9527PB 9528PB |
| 23 | 643839-4 | BRUSH GA4530 |
| 24 | 194722-3 | CARBON BRUSH CB 459 X GA4530 |
| 25 | 650560-8 | SWITCH DPX-2110-R 9554NB |
| 26 | 687681-3 | CLAMP cable tie GA4530 |
| 27 | 266326-2 | SCREW 4x18 X MT601 |
| 28 | 638739-1 | CAPACITOR X JS1000 |
| 29 | 682502-4 | CABLE SLEEVE 8/85 6408 |
| 31 | 266326-2 | SCREW 4x18 X MT601 |
| 32 | 450794-1 | BACK COVER GA4530 |
| 33 | 450797-5 | LEVER SWITCH GA4530 |
| 34 | 233121-5 | SPRING COMPRESSION 4 X 9554NB |
| 35 | 450795-9 | HOUSING MOTOR GA4530 |
| 36 | 419566-3 | BUTTON SWITCH 9554NB |
| 37 | 213032-0 | RING 4 X GA4530 |
| 38 | 256510-7 | 4 PIN FOR GA4530 |
| 39 | 141327-0 | GEAR BOX PJ7000 |
| 40 | 210033-9 | BEARING 696ZZ X 2107FK |
| 41 | 233950-6 | RING 11 X GA5010 |
| 42 | 227546-3 | GEAR FOR 37 GA4530 |
| 43 | 962151-6 | RETAINING RING R32 |
| 44 | 211129-9 | BALL BEARING NSK 6201DD |
| 45 | 326120-5 | POST PJ7000 |
| 46 | 213561-3 | RING 42 FOR GA4530 |
| 47 | 318811-2 | BOX BEARING PJ7000 |
| 48 | 911136-9 | HEAD SCREW CILIND. M4x20 |
| 49 | 911136-9 | HEAD SCREW CILIND. M4x20 |
| 50 | 931203-4 | NUT ESAG. M5-8 XJS3200 |
| 51 | 266741-0 | SCREW M5x50 PJ7000 |
| 52 | 453406-5 | COVER BASE PJ7000 |
| 53 | 326145-9 | PIN 10 PJ7000 |
| 54 | 141247-8 | GUIDE FRONT PJ7000 |
| 55 | 961017-7 | RING-3 X 4305T |
| 56 | 256689-4 | PIN 4 |
| 57 | 318813-8 | BASE PJ7000 |
| 58 | 231282-5 | SPRING 2.4 X HP1300 |
| 59 | 216040-0 | BALL 3.5 |
| 60 | 318814-6 | STILL PJ7000 |
| 61 | 266264-8 | SCREW M5 X 6 X BSR730 |
| 62 | 266738-9 | SCREW M4 PJ7000 |
| 63 | 213008-7 | RING 26 |
| 64 | 415252-4 | PIPE ELBOW X 3901 |
| 65 | 265785-7 | SCREW M5x10 PJ7000 |
| 66 | 232131-9 | SPRING RETAINING X 3901 |
| 67 | 213023-1 | RING 4 X HR3000C |
| 68 | 266737-1 | SCREW M6X20 PJ7000 |
| 69 | 231282-5 | SPRING 2.4 X HP1300 |
| 70 | 216040-0 | BALL 3.5 |
| 71 | 231795-6 | SPRING TENSION |
| 72 | 272263-0 | LEVER 40 PJ7000 |
| 73 | 252159-1 | HEX NUT XM6 X 5621RDW |
| 74 | 961014-3 | RETAINING RING E-8 |
| 75 | 253804-1 | WASHER 6 X LS1013 |
| 76 | 224280-6 | FLANGE INTERNAL 40 X 3901 |
| 77 | 224505-8 | FLANGE EST. 10-40 |
| 78 | 318845-5 | PROTECTION BLADE PJ7000 |
| 79 | 424479-5 | RUBBER PJ7000 |
| 80 | 213023-1 | RING 4 X HR3000C |
| 500 | 123150-5 | DUST BAG ASSY |
