Makita Spare Parts for Bench Saw With Lighting LS1040F

€71.79
Tax included

Makita Spare Parts for Compound Mitre Saw With Lighting LS1040F

We have the original Spares MAKITA for Compound Mitre Saw With Lighting LS1040F, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Compound Mitre Saw With Lighting LS1040F. All Spares are original and can be supplied at discounted prices
ITEM CODE: 125180-2
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Compound Mitre Saw With Lighting LS1040F

Fix Your Compound Mitre Saw With Lighting LS1040F. All Spares are original and can be supplied at discounted prices. Our Spares are Genuine Parts Guaranteed.

Makita LS1040F

Bench Saw Makita LS1040F
# Part NUm. Description
1 416004-6 COVER SET. X LS1040
2 211206-7 BEARING 6202V
3 253853-8 WASHER 15 X HR1800
4 343641-2 PIN LOCK X LS1030
5 241909-9 FAN X LS1040
6 516718-8 INDUCED LS1040
7 681640-9 INSULATOR X 2702
8 211061-7 BALL BEARING 6000DD X 6221
9 416442-2 PLATE BAFFLE LS1040
10 526068-3 STATORE 220 X LS1040
11 265995-6 SCREW M4X18 X 6408 / 6221DW
12 687052-4 CLAMP Cable tie X 6408
14 682540-6 SLEEVE JN1601
16 265995-6 SCREW M4X18 X 6408 / 6221DW
17 911383-2 SCREW M6 X60 X 2702
18 411478-6 BUTTON SWITCH 2414B
19 643650-4 PLUG BRUSH
20 181044-0 CHARCOALS CB-153 (CB-152.154)
21 153568-6 HOUSING MOTOR X LS1040F
22 651923-1 SWITCH TG70B X 5903R
23 231457-6 SPRING 3 X UH4510A / 6310A
24 416000-4 LEVER LOCK X LS1013
25 415999-0 LEVER SWITCH X LS1013
26 414546-4 CAM X LS10130
27 266029-8 SCREW M5X65
28 231297-2 SPRING 9 X LS1030
29 251667-9 SCREW M8x75 X LS1030
30 262511-5 REDUCTION RUBBER X HM1300
31 265995-6 SCREW M4X18 X 6408 / 6221DW
32 416007-0 COVER GUIDE X LS1040
33 226465-0 GEAR X LS 1040
34 316821-3 BEARING BOX X LS1040
35 211256-2 BEARING X AM4024LG
36 285685-5 STOP BEARING 64 X LS1040
37 322865-3 POST X LS1040
38 224333-1 FLANGE INTERNAL X LS1013
39 224333-1 FLANGE INTERNAL X LS1013
40 265355-2 SCREW M8X20 X LS1030
41 343639-9 X PLATE CENTRAL LS1030
42 345226-0 COVER CENTRAL X LS1013
43 265324-3 SCREW M8X12
44 231593-8 SPRING TORSION 36 X LS1030
45 416003-8 PROTECTION BLADE X LS1040
46 267136-0 FLAT WASHER 5
47 911213-7 SCREW M5X12 X 5143R
48 265985-9 BOLT M6 X LS1040
49 911223-4 HEAD SCREW CILIND. M5X16
51 151489-6 CAP BLADE COMPL. X LS1040
96 257137-6 RING 16 X LS1013
99 193730-1 LAMP X 2107FK
100 631588-5 CIRCUIT AVV.LENTO X LS1040F
101 266300-0 SCREW 4 X 18 X LS1040F
102 646073-5 COIL X LS1040F
103 645006-7 CAPACITOR X LS1013
104 654575-7 CLAMP X 5704R
105 651941-9 SWITCH X LS1013
110 266091-3 SPECIAL SCREW 4 X 50
111 125180-2 LAMP LIGHTING. X LS1040F
112 418072-5 SUPPORT LAMP X X LS1040F
900 344572-8 PLATE LOCK X LS1040F
901 323720-2 PIN 8 X LS1040F
902 231633-2 SPRING TWIST 8 X LS1040F
903 323721-0 AXIS 8 X LS1040F
904 421589-9 HOOD X LS1013
905 345803-8 LEVER FRAME LS1040F
906 911113-1 SCREW M4X10X LS1013
907 911113-1 SCREW M4X10X LS1013
908 424018-1 EXTENSION FOR LOCKOUT LEVER
52 265488-3 SCREW M8x30 X LH1040F
53 316826-3 GUIDE BLADE X LS1040
54 912342-9 SCREW M6 X25 X LS1040
55 253715-0 ROND.P.6 6510PBL / LVR / 43SB
56 150663-3 SUPPORT GUIDE X LS1040
57 344476-4 PLATE SUPPORT GUIDE LS1040
58 252014-7 NUT M6-10
59 251961-9 BOLT M6x10 X LS1040
60 257162-7 RING 7 X LS1030
61 253823-7 ROND. FLAT 7 X JS1600
62 265984-1 BOLT M6 X 2702
63 344377-6 PLATE ADJUSTMENT LS1040
64 265984-1 BOLT M6 X 2702
65 253823-7 ROND. FLAT 7 X JS1600
66 257162-7 RING 7 X LS1030
67 416006-2 LEVER 100 X LS1013
68 911113-1 SCREW M4X10 X LS1013
69 265437-0 BOLT M10 X LS1040
70 253024-7 WASHER 10 X LS1013
71 256836-7 AUCTION X LS1040
72 154463-3 ARM X LH1040F
73 322317-4 PIN X LS1013
74 213021-5 RETAINING RING 5 X LS1013
75 233152-4 SPRING COMP. 28 X LS1040
76 344464-1 COVER SPRING X LS1013
77 256280-8 PIN X LS1040
79 911113-1 SCREW M4X10 X LS1013
80 344385-7 STOP X LS1040
81 343799-7 PLATE LS1040
82 921452-1 HEXAGON BOLT 8X30
83 911213-7 SCREW M5X12 X 5143R
84 273495-2 KNOB 32 X LS1030
85 344381-5 SPRING SERRAGG.X LS1040 / LH1040F
86 150648-9 BASIC CPL X LS1040
87 316824-7 BASIC ROTATION X LS1040
88 416001-2 AUCTION BASE X LS1040
89 416001-2 AUCTION BASE X LS1040
90 921452-1 HEXAGON BOLT 8X30
91 931402-8 NUT M8 X LS1013
92 252105-4 NUT M8X13
93 253762-1 WASHER 8 X LS1040
94 931402-8 NUT M8 X LS1013
95 921452-1 HEXAGON BOLT 8X30
97 251887-5 BUTTERFLY SCREW M6x10 X N500
98 265708-5 SCREW M6 X 20 X LS1040
