Makita Spare Parts for Circular Saw HS6601J
search
  • Makita Spare Parts for Circular Saw HS6601J
  • Makita Spare Parts for Circular Saw HS6601J

Makita Spare Parts for Circular Saw HS6601J

€33.85
Tax included

Makita Spare Parts for Circular Saw HS6601J

Makita original spare parts, at discounted prices, we are a service center with after sales service able to quickly solve the maintenance and repair problems for Circular Saw HS6601J

Fix Your Circular Saw HS6601J. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Guarantee.
ITEM CODE: 142798-4
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Circular Saw HS6601J

Fix Your Circular Saw HS6601J. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Guarantee.

In the following table, look for the model of Circular Saw and the respective parts of the code.
Makita HS6601J

Circular Saw HS6601J
# Part Num. Description
1 266024-8 SCREW M6X20
2 224409-4 EXTERNAL FLANGE 35 BSS611R
3 224473-5 INTERNAL FLANGE 35
4 961155-5 RING SEGMENT S38
5 266034-5 SCREW CT 4X16
6 272258-3 LEVER 37
7 319307-6 SAFETY COVER
8 231893-6 TENSION SPRING 4
9 345391-5 THICKNESS RING MT582
10 326444-9 SHAFT HS7601
11 911226-8 CYLINDER HEAD SCREW. M5X18
12 319088-2 BEARING BOX
13 211129-9 BALL BEARING 6201DD NSK
14 285852-2 BEARING RETAINER 19-33
15 257173-2 RING 12 5604R
16 227793-6 GEAR 38 HS7601
17 961052-5 S12 RETAINING RING
18 210137-7 606ZZ BEARING
19 213512-6 GASKET 39 XM / HK1800
20 265117-8 SCREW M6X20 HS7601 / HS6601 / MT582
21 262502-6 RUBBER RING 6 56NB ETC.
22 143224-6 HOUSING BLADE
23 233117-6 SPRING COMPRESSION 6 X GA7010C
24 345317-7 LOCK SHAFT MT582
25 210059-1 BEARING 6000 HR2010
26 240064-4 FAN 70 MT582
27 513459-7 ARMATURE 240V
28 681644-1 INSULATED WASHER X 9227CB
29 210005-4 BALL BEARING 608 DDW
30 253192-6 FLAT WASHER 14
31 261109-5 RUBBER WASHER 13
32 455354-4 DEFLECTOR X HS7601
33 266418-7 SCREW 5X55 HR4002
34 593894-5 STATOR 240V
35 266326-2 SCREW 4X18 X MT601
37 265104-7 SCREW M5 X 40 MT240
38 643750-0 BRUSH HOLDER CAP
39 191963-2 CARBON BRUSH CB-303
40 142798-4 MOTOR BOX HS7601
41 682540-6 CORD GUARD JN1601
43 687124-5 CABLE CLAMP MT953
44 266326-2 SCREW 4X18 X MT601
45 455362-5 HANDLE COVER HS7601
46 650245-6 SWITCH SGE115CDY-10
47 654532-5 CLAMP 1P
48 645192-4 CAPACITOR
49 346311-2 LEVER MT582
50 257953-6 RING E-12 MT582
51 252199-9 NUT M8X13 MT582
52 941201-0 FLAT WASHER 8
53 161337-1 DEPTH GUIDE
54 266396-1 SCREW M8X24 MT582
56 346894-2 BASE
57 265118-6 SCREW M5 MT582
58 256480-0 PIN 6-7 BSS611R
59 346827-7 ANGULAR GUIDE X HS7601
60 252103-8 LUCK NUT X JR3020
61 265726-3 SCREW M6X15
62 319308-4 ANGULAR PLATE
63 941151-9 WASHER 6 X HM1303
64 942151-2 WASHER 6 4101R
65 265708-5 SCREW M6 X 20 X LS1040
67 453284-3 LOCK BUTTON X HS6101
68 231469-9 SPRING 4 X 6811DW
69 265708-5 SCREW M6 X 20 X LS1040
70 942151-2 WASHER 6 4101R
71 941151-9 WASHER 6 X HM1303
72 265726-3 SCREW M6X15
74 346847-1 HS7601 SUPPORT
75 346846-3 PLATE X HS7601
76 911106-8 SCREW M4X8
77 912107-9 SCREW M4X8
78 912107-9 SCREW M4X8
79 266436-5 SCREW M5X8
80 912212-2 SCREW 5 X 12 X LC1230
81 233376-2 SPRING COMPRESSION 8 X MT952
82 233376-2 SPRING COMPRESSION 8 X MT952
