Makita Spare Parts for Angle Grinder GA9012C
Distribution and Sale at attractive prices of Makita Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GA9012C.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder GA9012C | ||
| # | Part Num. | Description |
| 1 | 418517-3 | KEY LOCK-DISC X GA9010C |
| 2 | 231037-8 | SPRING 9607 7/09 / GA / 3612BR |
| 3 | 416972-3 | CAP 9079S |
| 4 | 318817-0 | CARCASS ING. X GA9010C |
| 5 | 266553-1 | SCREW 5X30 GA7012C-9012C |
| 7 | 210043-6 | BEARING FOR 608LLB LF1000 |
| 8 | 961055-9 | RETAINING RING S15 |
| 9 | 227457-2 | GEAR 43 X GA9010C |
| 10 | 285809-3 | BEARING 23-36 |
| 11 | 211228-7 | BALL BEARING 6202DD |
| 12 | 267215-4 | WASHER 15 X BTD200 |
| 13 | 213720-9 | SEAL 67 X HR2400 |
| 14 | 318376-4 | BEARING BOX X GA9010C |
| 15 | 922221-3 | SCREW M5X16 X HM1303 |
| 16 | 153785-8 | POST X GA9010C |
| 17 | 254011-9 | KEY 4 |
| 18 | 654532-5 | TERMINAL BLOCK 6E / 1DS |
| 19 | 122847-3 | HEADSET BLADE X GA9010C |
| 20 | 224415-9 | FLANGE INTERNAL 42 GA95010 |
| 21 | 224543-0 | FLANGE 9047F 9049F 9049SF |
| 22 | 213026-5 | RING 7 X GA9010C |
| 23 | 256483-4 | PIN 7 X GA7010C |
| 24 | 931303-0 | HEX NUT M6 |
| 25 | 227456-4 | GEAR 9 X GA9010C |
| 26 | 211106-1 | BALL BEARING 6201LLB |
| 27 | 253759-0 | ROND.P.12 JN / JS3200 |
| 28 | 317753-7 | COVER CARC.INGR. X GA9010C |
| 29 | 240070-9 | FAN 76 X GA9010C |
| 30 | 513568-2 | ARMATURE X GA9010C |
| 31 | 681660-3 | INSULATOR X PV7000C |
| 32 | 267281-1 | WASHER 8 X GA9010C |
| 33 | 210005-4 | BALL BEARING 608 DDW |
| 34 | 421720-7 | RING RUBBER 5604R |
| 35 | 266386-4 | 5X75 SCREW FOR GA7012C-GA9012C |
| 36 | 418516-5 | DEFLETTORE X GA9010C |
| 37 | 625824-9 | STATOR GA7012C-GA9012C |
| 38 | 153786-6 | HOUSING MOTOR GA9012C |
| 40 | 191957-7 | CARBON BRUSCHES CB-204 (201.202) |
| 41 | 643710-2 | BRUSH HOLDER X HM1500 |
| 43 | 631950-4 | REGULATOR GA7012C-GA9012C |
| 44 | 418518-1 | COMPASS X GA9010C |
| 45 | 651922-3 | SWITCH TG71B |
| 46 | 451637-0 | SWITCH HOLDER GA7012C |
| 47 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 48 | 188826-1 | REAR HANDLE GA7012CP12 |
| 49 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 50 | 687124-5 | CLAMP ties MT953 |
| 51 | 682573-1 | CABLE 10 X GA9010C |
| 53 | 233117-6 | SPRING COMP. 6 X GA7010C |
| 54 | 140358-6 | LEVER SWITCH CPL GA7012C |
