Makita Spare Parts for Angle Grinder GA9061R

€36.83
Tax included

Makita Spare Parts for Angle Grinder GA9061R

Distribution and Sale at attractive prices of Makita Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GA9061R.
ITEM CODE: 122891-0
Quantity
on 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Angle Grinder GA9061R

Distribution and Sale at attractive prices of Makita Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GA9061R.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Makita GA9061R

Angle Grinder GA9061R
# Part Num. Description
1 456247-8 BUTTON PIN
2 234391-9 SPRING COMPRESSION 8
3 251489-7 SCREW 5X30
4 143485-8 GEAR BOX
5 456238-9 GA9060 DEFLECTOR
6 252194-9 NUT M8 FOR GA9020
7 227652-4 GEAR 13
8 211132-0 BALL BEARING 6301DD
9 262085-6 RUBBER RING 38 9079S
10 267299-2 WASHER 20 FOR GA9020
11 962211-4 RETAINING RING R42
12 513448-2 ARMATURE ASS'Y 220V
13 240161-6 FAN 86
14 681630-2 WASHER X 9029-9029SF.
15 211087-9 BALL BEARING 6200DDW NSK
16 456239-7 PLATE
17 621779-6 STATOR 240V
18 266044-2 SCREW PT.5X60
21 456240-2 MOTOR HOUSING
22 266192-7 SCREW 4 X 14 X HR4001C / HR4010C
23 143950-7 COVER BRUSH DX
24 197129-2 CARBON BRUSH CB-218
25 643715-2 BRUSH HOLDER
26 143949-2 COVER BRUSH SX
27 266192-7 SCREW 4 X 14 X HR4001C / HR4010C
30 645088-9 CAPACITOR FOR GA9020
31 620588-0 REGULATOR
32 251489-7 SCREW 5X30
33 265995-6 SCREW M4X18 X 6408 / 6221DW
35 682573-1 CORD GUARD 10 X GA9010C
36 632F79-5 SWITCH
37 687169-3 CABLE CLAMP HP1620
38 266192-7 SCREW 4 X 14 X HR4001C / HR4010C
39 183C62-2 HANDLE
41 213026-5 RING 7 X GA9010C
42 256571-7 PIN 7
43 211032-4 BEARING X 1902
44 961055-9 RETAINING RING S15
45 346980-9 BALANCER
46 346981-7 RING C33
47 346982-5 RING C29
48 326640-9 SLEEVE
49 213859-8 RING 19
50 227654-0 GEAR 54
51 911128-8 SCREW M4X16 X HR4000C
52 285742-9 BEARING CHAIN 59
53 253725-7 WASHER 17
54 211377-0 BEARING 6905LLB X BHR200
55 213760-7 GASKET 78 HR2010
56 143515-5 BEARING BOX
57 265541-5 SCREW M6X22 FOR GA9020
58 326641-7 SHAFT
59 122891-0 SPARK GUARD FOR GA9020
60 224490-5 INTERNAL FLANGE 42
61 224485-8 NUT 14-45

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
