Makita Spare Parts for Cordless Angle Grinder BGA450RFE

€5.00
Tax included

Makita Spare Parts for Cordless Angle Grinder BGA450RFE

We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Cordless Angle Grinder BGA450RFE.
ITEM CODE: 210042-8
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Cordless Angle Grinder BGA450RFE

We are MAKITA original spare parts Worldwide Dealers

 at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Cordless Angle Grinder BGA450RFE.

In the following table, look for the model and the respective parts of the code.


Cordless Angle Grinder BGA450RFE
# Part Num. Description
1 619217-0 ARMATURE BGA450R
2 317821-6 GEAR HOUSING COVER 9554NB
3 213445-5 RING 26 X 9554NB
4 961005-4 RETAINING RING S9
5 210042-8 BEARING 629LLB GD0600
6 227501-5 GEAR FOR BGA452S
7 417771-6 PIN CAP X MT952
8 233072-2 COMPRESSION SPRING 8 X 9541
9 266361-0 SCREW 4 X 30 X 9554NB
10 213960-9 RING 5 X 9554NB
11 256496-5 PIN 4 BGA452S
12 318051-2 GEARCASE BGA452S
13 263002-9 RUBBER PIN 4
14 210033-9 BEARING 696ZZ X 2107FK
15 961052-5 RETAINING RING S12
16 253744-3 FLAT WASHER 12 24B / 12N /14
17 227502-3 GEAR FOR 39 BGA452S
18 962151-6 RETAINING RING R32
19 211129-9 BALL BEARING NSK 6201DD
20 267238-2 WASHER 12 X MT952
21 213622-9 RING 45 X 9554NB
22 318331-6 BOX BEARING X 9554NB
23 911121-2 SCREW M4X14X N9500N
24 345464-4 LABYRINTH RING PC5000/01C/GA5 9554NB
25 254011-9 WOODRUFF 4
26 324489-1 SPINDLE 9554NB
27 265180-1 SCREW M5X16
28 123098-1 WHEEL COVER 115AK
29 224415-9 INNER FLANGE 42 GA95010
30 224554-5 LOCK NUT 14-45 X 9541
31 631714-6 LED CIRCUIT BGA452S
32 638627-2 YORK UNIT BGD800R
33 638921-2 BRUSHE HOLDER BGA452S-450
34 863434-6 LABEL MOD. BGA450R
35 266326-2 SCREW 4x18 X MT601
36 419566-3 BUTTON, SWITCH 9554NB
37 188762-1 HOUSING SET BGA450R
38 419519-2 LEVER SWITCH BGA452S
39 650579-7 SWITCH 1246.3223
40 631712-0 CONTROLLER FOR BGA450R
41 643847-5 BATTERY TERMINAL X BJR240 / BTD130
43 191971-3 CARBON BRUSHE SET CB-430
44 643807-7 HOLDER CAP 6347D
45 419518-4 CARBON BRUSH HOLDER CAP COVER P02
46 421977-0 RUBBER RING 13 X BGA452
48 213009-5 RING 4
