Ama Spare Parts for Petrol Hedgetrimmer NG3 HT60R - 90525
€1.32
Tax included
Ama Spare Parts for Petrol Hedgetrimmer NG3 HT60R - 90525
Repair, replace and maintain your AMA NG3 HT60R hedge trimmer only with original spare parts. Choose to rely on expert hands, buy specific and original AMA spare parts at reduced prices. Enter a new reality, we offer you the possibility to choose and purchase every single part of the Hedge Trimmer comfortably with just a few clicks.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Ama Spare Parts for Petrol Hedgetrimmer NG3 HT60R - 90525
Repair, replace and maintain your AMA NG3 HT60R hedge trimmer only with original spare parts. Choose to rely on expert hands, buy specific and original AMA spare parts at reduced prices. Enter a new reality, we offer you the possibility to choose and purchase every single part of the Hedge Trimmer comfortably with just a few clicks.
In the following table, look for the model of the Trimmer and the respective parts of the code.
| AMA Garden Hedgetrimmer NG3 HT60R - 90525 | ||
| Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | Standard | Screw M5x18 |
| 2 | Gasket | |
| 3 | 92593 | Guide Cover |
| 4 | Standard | Screw M5x12 |
| 5 | Standard | Screw M5x16 |
| 6 | 92597 | Cylinder |
| 7 | 92614 | Gasket |
| 8 | 92617 | Piston ring |
| 9 | RSOF21 | Piston pin circlip |
| 10 | 92619 | Piston pin |
| 11 | 92622 | Piston |
| 12 | Crank shaft comp. | |
| 13 | 88264 | Key |
| 14 | Standard | Pin B4x8 |
| 15 | Standard | Bearing 6001-P6 |
| 16 | Crank case gasket | |
| 17 | Front half Crank Case | |
| 18 | 13554 | Oil Seal |
| 19 | 92627 | Clutch |
| 20 | Standard | Screw M5x20 |
| 21 | Rear half crank case | |
| 22 | Standard | Screw M5x20 |
| 23 | Standard | Screw M5x12 |
| 24 | 92629 | Ignition coil comp. |
| 25 | Standard | Screw M4x20 |
| 26 | Wire lead assy | |
| 27 | 92629 | Fly Wheel |
| 28 | Standard | Washer 8 |
| 29 | Standard | Washer 8 |
| 30 | Standard | Nut 8 |
| 31 | 92633 | Start reel |
| 32 | Standard | Screw M6x16 |
| 33 | 92634 | Starter comp. |
| 34 | Standard | Screw M5x18 |
| 35 | Standard | Screw M5x55 -12.9 |
| 36 | Muffler cover | |
| 37 | 88258 | Muffler |
| 38 | 92638 | Muffler Gasket |
| 39 | 64091 | Gasket |
| 40 | 76218 | Admitting pipe |
| 41 | Standard | Screw M5x30 |
| 42 | RSOF47 | Gasket |
| 43 | 92639 | Carburetor |
| 44 | 92641 | Inside cover |
| 45 | Standard | Screw M5x55 |
| 46 | 13715 | Filter net |
| 47 | 92642 | Outside cover |
| 48 | 92643 | Screw |
| 49 | 90054 | Fuel pipe 90mm |
| 50 | 13568 | Fuel pipe plug |
| 51 | 88342 | Fuel pipe 160mm |
| 52 | 92644 | Cleaner cover |
| 53 | 92645 | Fuel tank |
| 54 | Gasket | |
| 55 | 13758 | Fuel tank lid |
| 61 | Standard | Screw M5x16 |
| 62 | 56432 | Spark Plug |
| 63 | 6x70 pipe | |
| 64 | 92647 | Spring |
| 65 | 92648 | Cap |
| Blade Pag.2 |
||
| 1 | 92649 | Handgrip |
| 2 | 92652 | Handle, left |
| 3 | Standard | Screw M4x25 |
| 4 | 92653 | Spring |
| 5 | 92654 | Lever, Lock |
| 6 | 92656 | Switch |
| 7 | 92657 | Spring |
| 8 | 92658 | Lever, throttle |
| 9 | 92659 | Spring |
| 10 | 92662 | Lever, gyral |
| 11 | 92663 | Handle, right |
| 12 | Standard | Screw |
| 13 | 92664 | Lever |
| 14 | 92665 | Cable comp. |
| 15 | Spring | |
| 16 | Spring | |
| 17 | Seal 48.7 x 3.1 | |
| 18 | Frame | |
| 19 | Frame lid | |
| 20 | Gasket | |
| 21 | SL750S.1-10 | Pin |
| 22 | Cushion | |
| 23 | Standard | Screw M5x35 |
| 24 | Washer | |
| 25 | Pipe, exhaust | |
| 26 | Standard | Screw M5x10 |
| 27 | 92666 | Clutch drum comp. |
| 28 | Wheel box | |
| 29 | Standard | Nut M5 |
| 30 | Gasket | |
| 31 | Standard | Fuel cup M6 |
| 32 | Standard | Bearing 6001-2RS/P6 |
| 33 | 92667 | Gear shaft |
| 34 | Standard | Bearing 628/P6 |
| 35 | 92668 | Gasket |
| 36 | Case cover | |
| 37 | Standard | Screw M5x20 |
| 38 | Standard | Bearing 626/P6 |
| 39 | Cushion | |
| 40 | 92669 | Gear |
| 41 | Standard | Stop ring 28 |
| 42 | 92671 | Cam Shaft |
| 43 | 92672 | Blade Rivetting |
| 44 | Standard | Nut M5 |
| 45 | 92673 | Blade guard |
| 46 | 92674 | Plate, upper |
| 47 | 92676 | Cushion |
| 48 | Bracket | |
| 49 | Felt | |
| 50 | Standard | Screw M5x50 |
| 51 | Standard | Screw M5x25 |
| 52 | Spacer | |
| 53 | Washer 5 | |
| 54 | Cover | |
| 55 | Cushion | |
| 56 | 92667 | Handle front |
| 57 | Tube | |
