Makita Spare Parts for Percussion Drill HP2033
We have the original Spares MAKITA for Percussion Drill HP2033 the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Percussion Drill HP2033
We have the original Spares MAKITA for Percussion Drill HP2033 the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
In the following table, look for the model of Drill and the respective parts of the code.
| MAKITA DRILL HP2033 Spare Parts |
||
| # | Part Num. | Description |
| 1 | 251464-3 | M6X22 SPINDLE SCREW X HP2033 |
| 2 | 194254-0 | CHUCK 13 |
| 3 | 921919-9 | M8X110 BOLT |
| 4 | 415485-1 | HANDLE SUPPORT X HP1500 |
| 5 | 266038-7 | M5 X 70 SCREW HP2030 |
| 5 | 266108-2 | SCREW |
| 6 | 317111-7 | GEARBOX X HP2032 |
| 7 | 213314-0 | OIL SEAL 19 HP2030 |
| 8 | 323854-1 | SHAFT HP2032 |
| 9 | 152489-9 | HANDLE 36 X HP1500 |
| 10 | 256251-5 | PIN 4 HP1500 |
| 11 | 213162-7 | GASKET 14 |
| 12 | 232143-2 | LEAF SPRING HP2030 |
| 13 | 344179-0 | GEAR PLATE HP2030 |
| 14 | 415621-9 | PLATE 12 HP2030 |
| 15 | 415620-1 | GEAR LEVER B HP2030 |
| 16 | 344178-2 | LOCK PLATE HP2030 |
| 17 | 216040-0 | BALL 3.5 |
| 18 | 256251-5 | PIN 4 HP1500 |
| 19 | 233091-8 | SPRING 16 X HP1500 |
| 20 | 211228-7 | BALL BEARING 6202DD |
| 21 | 962153-2 | RETAINING RING R35 |
| 22 | 226289-4 | GEAR 27-38 HP2030 |
| 23 | 223104-3 | CAM A HP2030 |
| 24 | 961055-9 | RETAINING RING S15 |
| 25 | 211012-0 | BALL BEARING 606ZZ |
| 26 | 226818-3 | GEAR 8-19-26 HP2030 |
| 27 | 211012-0 | BALL BEARING 606ZZ |
| 28 | 415619-6 | GEAR LEVER A HP2030 |
| 29 | 213162-7 | SEAL 14 |
| 30 | 322787-7 | GEAR PIN 8 HP2030 |
| 31 | 416747-0 | FORK COVER X HP2032 |
| 32 | 213759-2 | SEAL 72 HP2030 |
| 33 | 232053-3 | PLATE SPRING HP1020/6012/62DW |
| 34 | 344178-2 | BLOCK PLATE HP2030 |
| 35 | 151550-9 | GEARBOX COMPLETE X HP2032 |
| 36 | 210005-4 | BALL BEARING 608 DDW |
| 37 | 415618-8 | HOUSING HP2030 |
| 38 | 517103-8 | ARMATURE HP2030 |
| 39 | 681614-0 | WASHER INSULATOR |
| 40 | 210025-8 | BEARING X 4324 |
| 41 | 253707-9 | WASHER P.16 99B/6000R/8410B |
| 42 | 266060-4 | SCREW M4 X 65 JN1601 |
| 42 | 266113-9 | |
| 43 | 633413-6 | FIELD 220 X HP2032 |
| 44 | 415601-5 | MOTOR CASE HP2030 |
| 45 | 195015-1 | CARBON BRUSHES CB-419(406,407)418 |
| 46 | 643923-5 | CARBON BRUSH HOLDER X 6408 |
| 47 | 851534-4 | |
| 48 | 415622-7 | LOCK PLATE HP2030 |
| 49 | 266007-8 | SCREW M3 X10 HP2030 |
| 50 | 182724-1 | COMPLETE HANDLE HP2030 |
| 51 | 819063-3 | MAKITA LABEL X BFL300F |
| 52 | 421505-1 | SHOCK ABSORBER RING HP2030 |
| 53 | 182724-1 | COMPLETE HANDLE HP2030 |
| 54 | 651986-7 | SWITCH X 8450 |
| 55 | 266121-0 | SCREW M4X18 X 9524NB |
| 55 | 265995-6 | SCREW M4X18 |
| 56 | 645144-5 | CAPACITATOR 0.22MF |
| 56 | 645144-5 | 0.22MF CAPACITOR |
| 57 | 266121-0 | M4X18 SCREW X 9524NB |
| 57 | 265995-6 | M4X18 SCREW |
| 58 | 687063-9 | CABLE CLIP X 4304T |
| 59 | 666066-6 | |
| 60 | 682502-4 | CABLE SLEEVE 8/85 6408 |
| 1001 | 415486-9 | DEPTH GAUGE |
| 1002 | 824485-4 | PLASTIC CASE |
| 5003 | 654128-2 | EARTH TERMINAL |
| 5004 | 654556-1 | CONNECTOR |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
