Hitachi Spare Parts for Demolition Hammer DH40MA
Hitachi-HIKOKI Original spare parts at the most competitive prices on the web, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance and repair issues for Demolition Hammer DH40MA.
In the following table, look for the model of the hammer and the respective parts of the code.
| Demolition Hammer DH40MA | ||
| # | Part Num. | Description |
| 1A | 313415 | FRONT CAP |
| 3 | 313413 | NEEDLE HOLDER |
| 4 | 313421 | NEEDLE ROLLER D8X20 |
| 7 | 313396 | O-RING (C) |
| 9 | 313419 | RETAINER SPRING |
| 11 | 313420 | RETAINING RING D38 |
| 12 | 313418 | SLEEVE (A) |
| 13 | 993040 | NYLOCK HIGH TENSION BOLT M7X25 |
| 19 | 981859 | URETHANE RING |
| 20A | 315868 | URETHANE RING HOLDER |
| 22 | 313409 | WASHER (A) |
| 25 | 944109 | FEATHER KEY 3X3X8 |
| 26 | 313050 | OIL SEAL (A) |
| 27 | 6002DD | BALL BEARING 6002DDCMPSZL |
| 28 | 313058 | WASHER |
| 29A | 313053 | WASHER (A) |
| 30 | 313055 | GEAR HOLDER |
| 34 | 313059 | SPACER |
| 37 | 313082 | NYLOCK BOLT (W/FLANGE) M5X16 |
| 38 | 991711 | DISTANCE PIECE (B) |
| 39 | 313083 | CRANK CASE COVER ASS’Y |
| 40 | 313084 | RUBBER SEAL |
| 42 | 939542 | RETAINING RING FOR D12 SHAFT (10 PCS.) |
| 43 | 313046 | CRANK SHAFT |
| 44 | 940533 | FEATHER KEY 3X3X10 |
| 45 | 6204VV | BALL BEARING 6204VVCMPSA2L |
| 49 | 939299 | NEEDLE BEARING (M661) |
| 50 | 313047 | FIRST GEAR |
| 57 | 313057 | NEEDLE PIN D6ÉX6 |
| 58 | 971750 | FEATHER KEY 3X3X20 |
| 60 | 313121 | CLUTCH SPRING |
| 64 | 986104 | O-RING |
| 65 | 981956 | CLUTCH |
| 66 | 981885 | PISTON |
| 67 | 980708 | PISTON PIN |
| 68 | 980707 | CONNECTING ROD ASS’Y |
| 69 | 980756 | NEEDLE BEARING (NSK AJ50 1203) |
| 71 | 993041 | NYLOCK BOLT (W/FLANGE) M6X25 |
| 72 | 956996 | O-RING (1AS60) |
| 73 | 993069 | NEEDLE BEARING (B) (NTN HMK4520) |
| 75 | 313078 | SIDE HANDLE |
| 76 | 313079 | HANDLE HOLDER |
| 77 | 313080 | HANDLE BOLT |
| 719 | 873095 | O-RING (P16) |
| 81 | 313412 | UNDER COVER |
| 82 | 313411 | SHAFT COVER |
| 85 | 313410 | LEVER |
| 86 | 307605 | SPRING |
| 87 | 313424 | SLEEVE |
| 88 | 313077 | NYLOCK BOLT (W/FLANGE) M5X25 |
| 89 | 6202VV | BALL BEARING 6202VVCMPSZ2L |
| 90 | 980700 | DUST WASHER (B) |
| 92 | 971097 | FAN |
| 93 | 360410E | ARMATURE ASS’Y 220V230V |
| 95 | 340361G | STATOR ASS’Y 220V230V |
| 96 | 930703 | BRUSH TERMINAL |
| 97 | 313086 | DUST WASHER (A) |
| 98 | 629VVM | BALL BEARING 629VVC2PS2I |
| 101 | 945161 | BRUSH CAP |
| 102 | 999073 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 103 | 958900 | BRUSH HOLDER |
| 105 | 313091 | BEARING HOLDER |
| 106 | 313090 | TAIL COVER |
| 109 | 313093 | SWITCH (C) (2P SCREW TYPE W/O LOCK) |
| 113 | 960266 | CORD CLIP |
| 118 | 958049 | CORD ARMOR D8.2 |
| 118 | 940778 | CORD ARMOR D10.7 |
| 119 | 313142 | PLUG (A) |
| 119 | 313092 | PLUG (A) |
| 120 | 313143 | PLUG (B) |
| 123 | 944525 | BEARING WASHER (C) |
| 124 | 316425 | BEVEL GEAR.PINION SET - DISCONTINUED |
| 502 | 981840 | GREASE (A) FOR HAMMER.HAMMER DRILL (30G) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
