Makita Hammer HM1205C Parts
€3.31
Tax included
Makita Spare Parts for Demolition Hammer SDS Max HM1205C
Makita original spare parts for to replace broken parts for to fix Demolition Hammer SDS Max HM1205C.Fix Your Demolition Hammer SDS Max HM1205C. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Demolition Hammer SDS Max HM1205C
Fix Your Demolition Hammer SDS Max HM1205C. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Hammer and the respective parts of the code.
| MAKITA HM1205C DEMOLITION HAMMER PARTS | ||
| # | Part. Num. | Description |
| 1 | 424165-8 | TOOL HOLDER CAP |
| 2 | 233973-4 | RING SPRING 26 |
| 3 | 267386-7 | FLAT WASHER 30 |
| 4 | 450894-7 | CHUCK COVER |
| 5 | 262147-0 | RUBBER RING 30 |
| 6 | 324987-5 | CHUCK RING |
| 7 | 450895-5 | RELEASE COVER |
| 8 | 310279-8 | TOOL RETAINER |
| 9 | 346015-6 | SPRING GUIDE |
| 10 | 234086-4 | COMPRESSION SPRING 56 |
| 11 | 961232-3 | RETAINING RING WR-45 |
| 12 | 450893-9 | CHANGE RING COVER |
| 13 | 324969-7 | CHANGE RING |
| 14 | 324988-3 | LOCK RING |
| 15 | 922243-3 | HEX. SOCKET HEAD BOLT M5X25 |
| 16 | 450903-2 | HOUSING COVER |
| 17 | 233970-0 | RING SPRING 35 |
| 18 | 158858-2 | BARREL COMPLETE |
| 19 | 922456-6 | HEX. SOCKET HEAD BOLT M8X35 |
| 20 | 213720-9 | O RING 67 |
| 21 | 262148-8 | RUBBER RING 39 |
| 22 | 267387-5 | FLAT WASHER 39 |
| 23 | 213079-4 | O-RING 35.5 |
| 24 | 324985-9 | TOOL HOLDER |
| 25 | 213980-3 | X-RING 21 |
| 26 | 213431-6 | FLUORIDE RING 28 |
| 27 | 213394-6 | O RING 23 |
| 28 | 324990-6 | IMPACT BOLT |
| 29 | 324993-0 | SHOULDER SLEEVE |
| 30 | 262149-6 | RUBBER RING 24 |
| 31 | 324993-0 | SHOULDER SLEEVE |
| 32 | 326355-8 | STRIKER |
| 33 | 213499-2 | O-RING 31.5 |
| 34 | 213581-7 | O-RING 44 |
| 35 | 450889-0 | ONE WAY VALVE GUIDE |
| 36 | 331925-0 | CYLINDER 40 |
| 37 | 268121-6 | PIN 12 |
| 38 | 213499-2 | O-RING 31.5 |
| 39 | 450961-8 | PISTON |
| 40 | 213149-9 | O RING 35 |
| 41 | 450890-5 | CONNECTING ROD |
| 56 | 450899-7 | CRANK CAP COVER |
| 57 | 911133-5 | PAN HEAD SCREW M4X18 |
| 58 | 443127-7 | FILTER |
| 59 | 450898-9 | CRANK CAP |
| 60 | 424166-6 | SEAL RING |
| 62 | 318364-1 | CRANK HOUSING |
| 63 | 266482-8 | H.S.BUTTON HEAD SCREW M6X4 |
| 64 | 419008-7 | FIX GUIDE |
| 65 | 423366-5 | CUSHION PLATE |
| 66 | 324994-8 | CRANK SHAFT |
| 67 | 211424-7 | BALL BEARING 6206LLU |
| 68 | 226691-1 | HELICAL GEAR 57 |
| 69 | 267398-0 | FLAT WASHER 12 |
| 70 | 424167-4 | SEAL RING |
| 71 | 158859-0 | GEAR HOUSING COMPLETE |
| 72 | 213231-4 | OIL SEAL 15 |
| 73 | 331596-3 | SLEEVE 12 |
| 74 | 211249-9 | BALL BEARING 6302LLU |
| 75 | 267397-2 | FLAT WASHER 15 |
| 76 | 240003-4 | FAN 80 |
| 77 | 517818-7 | ARMATURE ASS'Y 220-240V |
| 77 | INC. 73-76,78,79 | |
| 78 | 681642-5 | INSULATION WASHER |
| 79 | 211289-7 | BALL BEARING 6000DDW |
| 80 | 450900-8 | BAFFLE PLATE |
| 81 | 266095-5 | TAPPING SCREW 5X55 |
| 82 | 636303-2 | FIELD 220-240V |
| 83 | 450904-0 | MOTOR HOUSING |
| 84 | 638447-4 | BRUSH HOLDER UNIT |
| 84-1 | 632D00-2 | BRUSH HOLDER UNIT |
| 85 | 195844-2 | CARBON BRUSH CB-175 |
| 86 | 450901-6 | REAR COVER |
| 87 | 266041-8 | TAPPING SCREW 5X25 |
| 88 | 265995-6 | TAPPING SCREW 4X18 |
| 89 | 266192-7 | TAPPING SCREW 4X14 |
| 89-1 | 266300-0 | TAPPING SCREW 4X18 |
| 89-2 | 265678-8 | TAPPING SCREW 4X18 |
| 90 | 631869-7 | CONTROLLER |
| 91 | 638650-7 | LEAD UNIT |
| 92 | 419010-0 | LENS |
| 99 | 232209-8 | LEAF SPRING |
| 100 | 450891-3 | LEVER STOPPER |
| 101 | 814S61-6 | HM1205C NAME PLATE |
| 102 | 266041-8 | TAPPING SCREW 5X25 |
| 103 | 450897-1 | SLIDE LEVER |
| 106 | 450907-4 | HANDLE |
| 107 | 263027-3 | RUBBER PIN 4 |
| 108 | 651423-1 | SWITCH |
| 108-1 | 651423-1 | SWITCH |
| 109 | 423379-6 | SPONGE SHEET |
| 110 | 654531-7 | TERMINAL BLOCK 2P |
| 111 | 682560-0 | CORD GUARD 10 |
| 112 | 695123-3 | POWER SUPPLY CORD 1.5-2-4.0 |
| 113 | 687169-3 | STRAIN RELIEF |
| 114 | 265995-6 | TAPPING SCREW 4X18 |
| 115 | 450908-2 | HANDLE COVER |
| 116 | 265995-6 | TAPPING SCREW 4X18 |
| 117 | 265439-6 | HEX. BOLT M8X150 |
| 118 | 417002-3 | SIDE HANDLE CAM |
| 119 | 318505-9 | SIDE HANDLE BASE 82A |
| 120 | 951166-8 | SPRING PIN 5-24 |
| 121 | 318506-7 | SIDE HANDLE BASE 82B |
| 122 | 417003-1 | SIDE HANDLE |
| 123 | 417002-3 | SIDE HANDLE CAM |
| 124 | 252640-2 | WING NUT M8 |
| 125 | 267164-5 | FLAT WASHER 15 |
| 127 | 135269-8 | SIDE HANDLE 82 ASS'Y |
| 127 | INC. 117-124 | |
| 128 | 801Y75-0 | CLEAR LABEL |
| A01 | A-80787 | BULL POINT 280 SDS-MAX |
| A01-1 | D-34176 | BULL POINT FOR SDS-MAX 300 |
| A02 | 194683-7 | GREASE VESSEL SET |
| A02-1 | 198993-4 | GREASE VESSEL SET |
| A03 | 443122-7 | CLOTH |
| A04 | 824876-9 | PLASTIC CARRYING CASE |
| C10 | 162271-8 | LATCH |
| C20 | 325637-5 | SHAFT |
| C30 | 450990-1 | HANDLE |
| A04-1 | 143519-7 | PLASTIC CASE COMPLETE |
| C10 | 162271-8 | LATCH |
| C20 | 325637-5 | SHAFT |
| C30 | 450990-1 | HANDLE |
| C40 | 835200-1 | SPONGE 40-40 |
| A05 | 802G97-5 | HM1205C PLASTIC CASE LABEL |
| B01 | 195114-9 | HAMMER SERVICE KIT |
| C10 | 181490-7 | HAMMER GREASE 30G |
| C11 | 1914C5-7 | GREASE SET |
| B01 | INC. 1,21,23,25-27,30,33,38, | |
| B01 | INC. 40,85 | |
| E01 | 801091-2 | SOUND 98DB LABEL |
| E01-1 | 8066Y1-5 | SOUND LABEL |
| F03-1 | 199143-4 | DUST EXTRACTOR ATT SET(EU) |
| F04-1 | 199143-4 | DUST EXTRACTOR ATT SET(EU) |
| F06-1 | 199144-2 | DUST EXTRACTOR ATT SET(EU) |
| C10 | 417765-1 | FRONT CUFF 22 |
| C20 | 417766-9 | FRONT CUFF 38 |
| C30 | 415021-3 | HOSE JOINT |
| F07-1 | 199144-2 | DUST EXTRACTOR ATT SET(EU) |
| C10 | 417765-1 | FRONT CUFF 22 |
| C20 | 417766-9 | FRONT CUFF 38 |
| C30 | 415021-3 | HOSE JOINT |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
