Alpina Brushcutter ABR 45 Spare Parts
ALPINA authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter ABR 45 (2021) 283420074/A21.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Brushcutter ABR 45 Spare Parts
ALPINA authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter ABR 45 (2021) 283420074/A21.In the following table, look for the model of the Brushcutter and the respective parts of the code.
| ALPINA ABR 45 (2021) 283420074/A21 | ||
| Motore Pag.1 | ||
| # | Part Num. | Description |
| 2 | 112760475/0 | Screw |
| 3 | 6981117 | Screw |
| 4 | 112728721/0 | Screw |
| 5 | 118805131/0 | Transmission Support Assy |
| 7 | 118805132/0 | Clutch Assembly |
| 8 | 112155010/0 | Nut |
| 9 | 112583500/0 | Grower |
| 10 | 122671653/0 | Washer |
| 11 | 118805565/0 | Flywheel |
| 13 | 118801197/0 | Oil Seal TC15X30X7 |
| 14 | 118805721/0 | Bearing |
| 15 | 2135130 | Screw |
| 16 | 118805134/0 | Crankshaft |
| 17 | 3151050 | Flywheel Key |
| 18 | 118801188/0 | Oil Seal |
| 19 | 118804079/0 | Crankcase Gasket |
| 20 | 118805135/0 | Starter Cup |
| 21 | 118805136/0 | Starter Ass.y |
| 22 | 6981118 | Screw Outfit |
| 24 | 2312010 | Washer |
| 25 | 118801180/0 | Screw |
| 26 | 118805137/0 | Piston Ring |
| 27 | 118805138/0 | Sbc 646-656 - Bpmr7a Spark Plug |
| 29 | 112760475/0 | Screw |
| 30 | 112760475/0 | Screw |
| 31 | 118805168/0 | M5x44 Dowel Screw |
| 32 | 112581500/0 | Washer M5 |
| 33 | 112154320/0 | Nut |
| 34 | 118805567/0 | Carburetor |
| 35 | 112726389/0 | Screw |
| 36 | 9699-0087-02 | Washer |
| 37 | 2135250 | Screw |
| 38 | 118805140/0 | Air Filter |
| 39 | 2135060 | Screw |
| 40 | 118805141/0 | Fuel Tank Assembly |
| 41 | 118805142/0 | Tank cap assembly |
| 42 | 112291000/0 | Nut |
| 44 | 9699-0087-02 | Washer |
| 45 | 118805563/0 | Guard |
| 46 | 118805104/1 | Cylinder-Piston Kit |
| 47 | 118805106/0 | Piston Kit |
| 48 | 118805108/0 | Sbc 646-656 Crankcase Kit |
| 49 | 118805109/1 | Sbc 646-656 Muffler Kit |
| 50 | 118805566/0 | Ignition Coil |
| 51 | 118805111/0 | Sbc 646-656 Prime Bulb Kit |
| 52 | 118805112/1 | Intake manifold |
| 53 | 118805113/1 | Sbc 646-656 Air Filter Base Kit |
| 54 | 118805114/1 | Sbc 646-656 Fuel Pipe Kit |
| 55 | 118805564/0 | Cylinder cover, GRAY |
| 56 | 118805116/0 | Sbc 646-656 Trans. Supp. Cover Kit |
| 57 | 112292100/0 | Nut |
| 58 | 118805166/0 | Sbc 646-656 Air Guide Cover |
| 59 | 118805167/0 | Spark Plug Cap Cover |
| 60 | 118805169/0 | Gray Air Filter Cover |
| 61 | 118805170/0 | Fuel Tank Lower Cover |
| 62 | 118805307/0 | Cylinder gasket |
| 63 | 118805718/0 | Choke lever |
| ALPINA ABR 45 (2021) 283420074/A21 | ||
| Trasmission Pag.2 | ||
| # | Part Num. | Description |
| 1 | 118805081/0 | Aluminium Shaft Assembly D. 28mm |
| 2 | 118805086/0 | Transmission Shaft D. 8mm |
| 3 | 1911-9259-01 | Double Harness Elite |
| 4 | 112727796/0 | Screw |
| 5 | 2132180 | Screw |
| 6 | 112728721/0 | Screw |
| 7 | 118805087/0 | Sbc 646-656 Rear Handle Assembly |
| 9 | 118805562/0 | Upper ring Nut |
| 10 | 118805561/0 | Lower ring Nut |
| 11 | 118805560/0 | Stabilizer Cup |
| 12 | 112727796/0 | Screw |
| 13 | 118805088/0 | Front Handle Assembly |
| 14 | 118805080/0 | Guard Assembly |
| 15 | 1911-9262-01 | 3T Blade |
| 16 | 1911-9229-01 | Nylon Head Easy Work 130mm |
| 17 | 118804890/0 | Line Retainer |
| 18 | 118805262/0 | Spring |
| 19 | 118805264/0 | Cover & Knob |
| 20 | 118805089/0 | Gearbox Assembly D=28 |
| 21 | 118805093/0 | Upper Ring Flange |
| 22 | 118805094/0 | Lower Ring Flange |
