Makita Cordless Hammer HM002G Parts
€3.31
Tax included
Makita Spare Parts for Cordless Hammer HM002G
MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Hammer HM002G.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Cordless Hammer HM002G
MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Hammer HM002G.
In the following table, look for the model of Hammer and the respective parts of the code.
| MAKITA HM002G CORDLESS DEMOLITION HAMMER PARTS | ||
| # | Part Num. | Description |
| 1 | 424165-8 | TOOL HOLDER CAP |
| 2 | 233973-4 | RING SPRING 26 |
| 3 | 267386-7 | FLAT WASHER 30 |
| 4 | 450894-7 | CHUCK COVER |
| 5 | 262147-0 | RUBBER RING 30 |
| 6 | 324987-5 | CHUCK RING |
| 7 | 450895-5 | RELEASE COVER |
| 8 | 310279-8 | TOOL RETAINER |
| 9 | 346015-6 | SPRING GUIDE |
| 10 | 234086-4 | COMPRESSION SPRING 56 |
| 11 | 961232-3 | RETAINING RING WR-45 |
| 12 | 450893-9 | CHANGE RING COVER |
| 13 | 324969-7 | CHANGE RING |
| 14 | 324988-3 | LOCK RING |
| 15 | 922456-6 | HEX. SOCKET HEAD BOLT M8X35 |
| 16 | 413268-3 | HOUSING COVER |
| 17 | 213664-3 | O RING 60 |
| 18 | 140Y02-5 | BARREL COMPLETE |
| 19 | 213720-9 | O RING 67 |
| 20 | 262148-8 | RUBBER RING 39 |
| 21 | 267387-5 | FLAT WASHER 39 |
| 22 | 233970-0 | RING SPRING 35 |
| 23 | 213079-4 | O-RING 35.5 |
| 24 | 324985-9 | TOOL HOLDER |
| 25 | 213980-3 | X-RING 21 |
| 26 | 213394-6 | O RING 23 |
| 27 | 213431-6 | FLUORIDE RING 28 |
| 28 | 136391-4 | IMPACT BOLT ASSY |
| 28 | INC. 25-27 | |
| 29 | 324993-0 | SHOULDER SLEEVE |
| 30 | 262149-6 | RUBBER RING 24 |
| 31 | 324993-0 | SHOULDER SLEEVE |
| 32 | 327739-3 | STRIKER |
| 33 | 213499-2 | O-RING 31.5 |
| 34 | 213581-7 | O-RING 44 |
| 35 | 450889-0 | ONE WAY VALVE GUIDE |
| 36 | 327741-6 | CYLINDER 40 |
| 37 | 911133-5 | PAN HEAD SCREW M4X18 |
| 38 | 413273-0 | CRANK CAP COVER |
| 39 | 443127-7 | FILTER |
| 40 | 413272-2 | CRANK CAP |
| 41 | 422658-9 | SEAL RING A |
| 42 | 140Y06-7 | CRANK HOUSING COMPLETE |
| 43 | 232662-8 | COMPRESSION SPRING 12 |
| 44 | 232664-4 | COMPRESSION SPRING 10 |
| 45 | 922363-3 | H.S.H.BOLT M6X40 WITH WR |
| 46 | 413277-2 | CONNECTING ROD |
| 47 | 450961-8 | PISTON |
| 48 | 268121-6 | PIN 12 |
| 49 | 213149-9 | O RING 35 |
| 50 | 213499-2 | O-RING 31.5 |
| 51 | 327740-8 | CRANK SHAFT |
| 52 | 210254-3 | BALL BEARING 6206LLB |
| 53 | 226691-1 | HELICAL GEAR 57 |
| 54 | 267398-0 | FLAT WASHER 12 |
| 55 | 422659-7 | SEAL RING B |
| 56 | 140Y03-3 | GEAR HOUSING COMPLETE |
| 57 | 213231-4 | OIL SEAL 15 |
| 58 | 413275-6 | SPRING PLATE |
| 59 | 232691-1 | COMPRESSION SPRING 15 |
| 60 | 324992-2 | COUNTER WEIGHT |
| 61 | 232691-1 | COMPRESSION SPRING 15 |
| 62 | 213953-6 | O RING 24 |
| 64 | 140Y04-1 | HOLDER COMPLETE |
| 66 | 210253-5 | BALL BEARING 6302DDW |
| 67 | 267397-2 | FLAT WASHER 15 |
| 68 | 519651-3 | ROTOR ASS'Y |
| 68 | INC. 66,67,69 | |
| 68-1 | 519651-3 | ROTOR ASS'Y |
| 68-1 | INC. 66,67,69 | |
| 69 | 210059-1 | BALL BEARING 6000DDW |
| 70 | 265995-6 | TAPPING SCREW 4X18 |
| 71 | 413271-4 | BAFFLE PLATE |
| 72 | 629A27-3 | STATOR |
| 73 | 620E26-2 | CONTROLLER B |
| 74 | 687B69-9 | STOPPER |
| 75 | 266490-9 | TAPPING SCREW PT 2X6 |
| 76 | 632R89-4 | LEAD UNIT |
| 77 | 652031-1 | PAN HEAD SCREW M3X6 |
| 78 | 413266-7 | MOTOR HOUSING |
| 79 | 256380-4 | SHOULDER PIN 4-6 |
| 80 | 412985-2 | BASE |
| 81 | 232643-2 | TORSION SPRING 13 |
| 82 | 140W48-9 | LEVER COMPLETE |
| 83 | 263046-9 | TAPPING SCREW 3X14 |
| 84 | 620E28-8 | SENSOR CIRCUIT |
| 85 | 265995-6 | TAPPING SCREW 4X18 |
| 86 | 620E29-6 | DIAL CIRCUIT |
| 87 | 140Y05-9 | MOTOR HOUSING COVER COMP LETE |
| C10 | 422660-2 | RUBBER SHEET |
| 88 | 266041-8 | TAPPING SCREW 5X25 |
| 89 | 183T10-3 | HOUSING SET |
| C10 | 263005-3 | RUBBER PIN 6 |
| C20 | 347755-9 | GUARD RAIL |
| C30 | 422646-6 | CAP 10 |
| C40 | 347782-6 | PLATE |
| 89 | INC. 101 | |
| 90 | 266041-8 | TAPPING SCREW 5X25 |
| 91 | 232663-6 | COMPRESSION SPRING 8 |
| 92 | 620E27-0 | LED CIRCUIT |
| 93 | 620E31-9 | CONTROLLER |
| 95 | 632R98-3 | TERMINAL UNIT |
| 96 | 232152-1 | LEAF SPRING |
| 97 | 412981-0 | TRIGGER LOCK |
| 98 | 458097-7 | SWITCH LEVER |
| 99 | 651083-9 | SWITCH C3XA-1PSPM |
| 100 | 232418-9 | COMPRESSION SPRING 5 |
| 101 | 183T10-3 | HOUSING SET |
| C10 | 263005-3 | RUBBER PIN 6 |
| C20 | 347755-9 | GUARD RAIL |
| C30 | 422646-6 | CAP 10 |
| C40 | 347782-6 | PLATE |
| 101 | INC. 89 | |
| 102 | 140F99-0 | CAP COMPLETE |
| C10 | 213218-6 | O RING 16 |
| C11 | 213A05-9 | O-RING16 |
| C20 | 818H07-8 | CAP LABEL |
| 103 | 265995-6 | TAPPING SCREW 4X18 |
| 104 | 265439-6 | HEX. BOLT M8X150 |
| 105 | 417003-1 | SIDE HANDLE |
| 106 | 252640-2 | WING NUT M8 |
| 107 | 417002-3 | SIDE HANDLE CAM |
| 108 | 318505-9 | SIDE HANDLE BASE 82A |
| 109 | 318506-7 | SIDE HANDLE BASE 82B |
| 110 | 951166-8 | SPRING PIN 5-24 |
| 111 | 135269-8 | SIDE HANDLE 82 ASS'Y |
| 111 | INC. 104-110 | |
| 112 | 8029M5-9 | XGT LOGO LABEL |
| 113 | 8029M4-1 | CLEAR LABEL |
| 114 | 858E35-3 | HM002G NAME PLATE |
| 115 | 858E41-8 | HM002G SERIAL NO. LABEL |
| 116 | 688163-8 | LINE FILTER |
| A01 | A-80787 | BULL POINT 280 SDS-MAX |
| A01-1 | D-34176 | BULL POINT FOR SDS-MAX 300 |
| A02 | 198993-4 | GREASE VESSEL SET |
| A03 | 443122-7 | CLOTH |
| A04 | 821848-5 | PLASTIC CASE |
| A05 | 8029X7-2 | HM002GZ03 PLASTIC CASE LABE L |
| B01 | 191N77-1 | HAMMER SERVICE KIT |
| C10 | 181490-7 | HAMMER GREASE 30G |
| C11 | 1914C5-7 | GREASE SET |
| B01 | INC. 1,2,8,25-27,33,49,50 | |
| E01 | 801092-0 | SOUND 101DB LABEL |
| F06 | 199143-4 | DUST EXTRACTOR ATT SET(EU) |
| F07 | 199144-2 | DUST EXTRACTOR ATT SET(EU) |
