Makita DHR281 Spare Parts

Name: Makita DHR281 Spare Parts
Brand: Makita
SKU: Makita DHR281
Price: 70.77 EUR
Availability: InStock

€70.77

Tax included

Makita DHR281 Cordless Combinaton Hammer Spare Parts

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Cordless Combination Hammer DHR281 .

ITEM CODE: 199138-7

199138-7
126882-3
144959-2
233360-7
265625-9
422258-5
458355-1
931302-2
458357-7
422255-1
161838-9
266351-3
144965-7
331890-3
211294-4
211012-0
347228-2
213278-8
135961-6
234264-6
457709-9
216019-1
144966-5
213344-1
332139-4
227360-7
234148-8
267153-0
257932-4
325783-4
325791-5
325792-3
234149-6
325793-1
213073-6
233979-2
325784-2
213258-4
327079-9
346036-8
324215-8
232449-8
265627-5
347344-0
922148-7
144960-7
257336-0
253186-1
226170-9
332125-5
310678-4
327078-1
219030-2
257321-3
346538-4
253077-6
961018-5
310869-7
319674-9
211032-4
347343-2
221599-4
213850-6
256536-9
135962-4
232436-7
443153-6
922118-6
213008-7
347230-5
234343-0
347229-0
346536-8
144964-9
210024-0
253835-0
519513-5
210022-4
629340-3
652069-6
266490-9
620815-5
135963-2
912207-5
264002-2
422257-7
183J31-5
263005-3
266326-2
422256-9
257438-2
346783-1
620549-0
233598-4
313226-8
644809-6
183J29-2
453124-5
651366-7
632L95-3
286288-8
233989-9
346221-3
233992-0
267437-6
424364-2
458358-5
327081-2
216022-2
346177-0
233916-6
327080-4
216013-3
231669-1
345334-7
418218-3
216018-3
345335-5
267270-6
233924-7
135965-8
199139-5
194683-7
331886-4
443122-7
195179-1
197280-8
839559-8
821552-6
453974-8
195833-7
195127-0
199557-7

Quantity

on 7/10 Business Days Approx

Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Description
Product Details
Attachments

Makita DHR281 Cordless Combinaton Hammer Spare Parts

MAKITA DHR281 28MM CRDLS COMBINATION HAMMER PARTS LIST
#	Parts Num.	Description
001	199134-5	TOOL HOLDER SET
001-1	199138-7	TOOL HOLDER SET
010	126882-3	GRIP ASSEMBLY
011	144959-2	LOCK BUTTON COMPLETE
012	233360-7	COMPRESSION SPRING 4
013	265625-9	THUMB SCREW M6X50
014	422258-5	SPONGE SHEET
015	458355-1	SIDE HANDLE BASE
016	931302-2	HEX. NUT M6
017	458357-7	GRIP 36
018	422255-1	CAP
019	161838-9	FIX PIN
020	266351-3	TAPPING SCREW 4X35
021	144965-7	GEAR HOUSING COMPLETE
C10	213345-9	OIL SEAL 25
C20	331890-3	CUP SLEEVE
022	211294-4	BALL BEARING 6806LLU
023	211012-0	BALL BEARING 606ZZ
024	233360-7	COMPRESSION SPRING 4
025	347228-2	LOCK PLATE
026	213278-8	O RING 17
027	135961-6	CHANGE LEVER ASSY
028	234264-6	COMPRESSION SPRING 3
029	457709-9	LOCK BUTTON
031	216019-1	STEEL BALL 3
032	144966-5	TOOL HOLDER GUIDE COMPLET
C10	213344-1	OIL SEAL 9
033	332139-4	DRIVING FLANGE
034	227360-7	SPUR GEAR 51
035	234148-8	COMPRESSION SPRING 31
036	267153-0	FLAT WASHER 30
037	257932-4	SPIRO LOCK WASHER 30
038	267153-0	FLAT WASHER 30
039	325783-4	SLEEVE 9B
040	325791-5	IMPACT BOLT B
041	325792-3	WASHER 10
042	234149-6	COMPRESSION SPRING 20
043	325793-1	O-RING CASE B
044	213073-6	O RING 9
045	233979-2	RING SPRING 28
046	325784-2	STRIKER
047	213258-4	O RING 17.5
048	327079-9	PISTON CYLINDER
049	346036-8	GUIDE PLATE
050	324215-8	PISTON JOINT
051	232449-8	COMPRESSION SPRING 14
052	265627-5	H.S.BUTTON HEAD BOLT M4X6
053	347344-0	SPRING GUIDE
054	922148-7	HEX. SOCKET HEAD BOLT M4X25
055	144960-7	INNER SUPPORT COMPLETE
056	257336-0	STOP RING EXT U-6
057	253186-1	FLAT WASHER 7
058	226170-9	SPUR GEAR 10
059	332125-5	CLUTCH CAM
059-1	310678-4	CLUTCH CAM
060	327078-1	CAM SHAFT
061	219030-2	SWASH BEARING 10
062	257321-3	RING 8
063	346538-4	WEIGHT HOLDER GUIDE
064	253077-6	FLAT WASHER 6
065	961018-5	STOP RING E-5
066	310869-7	COUNTER WEIGHT
067	922148-7	HEX. SOCKET HEAD BOLT M4X25
068	319674-9	BEARING BOX
069	211032-4	BALL BEARING 608ZZ
070	347343-2	BEARING RETAINER B
071	221599-4	SPIRAL BEVEL GEAR 32
072	213850-6	O-RING 74
073	256536-9	FLAT FILLISTER HD PIN 6
074	135962-4	INNER HOUSING ASSY
075	232436-7	COMPRESSION SPRING 10
076	443153-6	FELT
077	922118-6	HEX. SOCKET HEAD BOLT M4X12
078	213008-7	O RING 22.4
079	347230-5	CHANGE PLATE B
080	234343-0	COMPRESSION SPRING 5
081	347229-0	CHANGE PLATE A
082	346536-8	BEARING RETAINER A
083	144964-9	SPIRAL BEVEL GEAR 11 COMPLET
084	210024-0	BALL BEARING 608LLU
085	253835-0	FLAT WASHER 8
086	519513-5	ROTOR ASSY
086-1	619841-9	ROTOR
087	210022-4	BALL BEARING 626DDW
088	629340-3	STATOR
089	652069-6	FLAT HEAD SCREW M3X6
090	266490-9	TAPPING SCREW PT 2X6
091	620815-5	CONTROLLER
097	135963-2	HOOK ASSY
098	912207-5	COUNTERSUNK HEAD SCREW M5 X10
103	264002-2	SQUARE NUT M5
104	422257-7	BELLOWS
105	183J31-5	HOUSING SET
C10	263005-3	RUBBER PIN 6
106	266326-2	TAPPING SCREW 4X18
107	854J10-7	DHR281 NAME PLATE
108	422256-9	RUBBER RING 10
109	257438-2	SLEEVE 10
110	346783-1	PLATE
111	620549-0	LED CIRCUIT
112	183J31-5	HOUSING SET
C10	263005-3	RUBBER PIN 6
113	233598-4	TORSION SPRING 6
114	313226-8	OPENER
115	644809-6	TERMINAL
116	854J13-1	DHR281 SERIAL NO. LABEL
117	266326-2	TAPPING SCREW 4X18
118	183J29-2	HANDLE SET
119	453124-5	F/R CHANGE LEVER
120	651366-7	SWITCH C3JW-6B-24
121	632L95-3	LEAD UNIT
122	183J29-2	HANDLE SET
123	286288-8	CAP 35
124	233989-9	RING SPRING 14
125	346221-3	WASHER 16
126	233992-0	RING SPRING 15
127	267437-6	FLAT WASHER 17
128	424364-2	RUBBER WASHER 16
129	458358-5	CHUCK COVER
130	327081-2	STOPPER
131	216022-2	STEEL BALL 7.0
132	346177-0	GUIDE WASHER
133	233916-6	CONICAL COMP. SPRING 21-29
134	327080-4	TOOL HOLDER
135	216013-3	STEEL BALL 6
136	231669-1	TORSION SPRING 31
137	345334-7	CHANGE RING
138	418218-3	CHANGE COVER
139	216018-3	STEEL BALL 5.0
140	345335-5	LEAF SPRING
141	267270-6	FLAT WASHER 24
142	233924-7	RING SPRING 21
143	135965-8	TOOL HOLDER ASSY
A01	199135-3	DRILL CHUCK SET
A01-1	199139-5	DRILL CHUCK SET
A02	194683-7	GREASE VESSEL SET
A04	331886-4	DEPTH GAUGE
A05	443122-7	CLOTH
A06	195179-1	DUSTCUP SET
A09	***DC18RD	DC18RD TWO PORT FAST CHARGER
A10	197280-8	BATTERY BL1850B SET
A10-1	197280-8	BATTERY BL1850B SET
A11	839559-8	INNER TRAY
A12	821552-6	CONNECTOR PLASTIC CASE (TYPE 4 )
C10	453974-8	LATCH
A13	817L34-6	DHR281PT2J INDICATION LABEL
A14	817L31-2	DHR281PT2J PLASTIC CASE LABE L
B01	195833-7	HAMMER SERVICE KIT
C10	195127-0	OIL VESSEL SET
E01	818S15-5	CLEAR LABEL
F14-1	199557-7	FILTER SET
F18-1	199583-6	DX09DUST COLLECTION SYSTEM SET
A13	817L25-7	DHR281ZJ INDICATION LABEL
A14	817L22-3	DHR281ZJ PLASTIC CASE LABEL
