Makita Spare Parts for Jigsaw 4350CT

€82.13
Tax included

Makita Spare Parts for Jigsaw 4350CT

Makita Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance and repair issues for Jigsaw 4350CT.

ITEM CODE: 135060-4
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Jigsaw 4350CT

Makita Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance and repair issues for Jigsaw 4350CT.

In the following table, look for the model of jackhammers and the respective parts of the code.
Makita 4350CT

JIGSAW 4350CT
# Part Num. Description
1 188286-7 COMPLETE HANDLE 4350CT
3 266091-3 SCREW FOR SPECIAL 4 50
4 265995-6 SCREW M4PER18 FOR 6408 / 6221DW
5 442138-9 PACKING 4341FCT
6 214031-5 BUSH 40 6913DWH
7 232207-2 SPRING FLAT FOR 4341FCT
8 256117-9 PLUG FOR 4324
9 911111-5 HEAD SCREW CILIND. M4X10
10 911111-5 HEAD SCREW CILIND. M4X10
11 345240-6 GUIDE FOR STRAIGHT 4341FCT
12 345240-6 GUIDE FOR STRAIGHT 4341FCT
13 153338-3 COVER GEAR BOX 4341FCT
14 417839-8 SEALING PLATE FOR 4341FCT
15 231659-4 TORSION SPRING FOR 6 4341FCT
16 265026-1 BOLT M4
17 419820-5 RELEASE BLADE BJV140R
18 421817-2 DUST FOR 4341FCT
19 962068-3 RETAINING RING R-18 FOR 4341F
20 135060-4 CONNECTING ROD COMPLETE 4350CT
21 231660-9 TORSION SPRING FOR 15 4341FCT
22 310136-0 Blade holder FOR 4341FCT
23 310135-2 PLUG FOR 4341FCT
25 682559-5 SAVE CABLE FOR 6822
26 687260-7 FIXED CABLE FOR GA5010
27 265995-6 SCREW M4PER18 FOR 6408 / 6221DW
28 645149-5 CONDENSER 4350CT
29 266034-5 SCREW CT 4PER16
30 324233-6 PROTECTION SECURITY FOR 4341FCT
32 631768-3 REGULATOR FOR 4350CT
33 650202-4 SWITCH FOR 4340CT
34 654532-5 TERMINAL BLOCK 6E / 1DS
36 310134-4 SLEIGH FOR 4341FCT
37 961017-7 RING FOR 3-4305T
38 961004-6 RETAINING RING S8
39 212014-9 BEARING ROLLER 407
40 268090-1 PLUG FOR 4 4341FCT
41 265353-6 SCREW M 4 TO 12 TO 4341FCT
42 153336-7 ECCENTRIC FOR 4341FCT
43 313108-4 PLATE FOR BALANCE 4341FCT
44 153335-9 GEAR CPL. FOR 4341FCT
45 345235-9 PLATE 4341FCT
46 253877-4 FLAT WASHER 8 PER4301BV
47 266050-7 SCREW PT 4PER30
48 961018-5 RETAINING RING E5
49 286032-3 PLUG FOR 5 4341FCT
50 233139-6 COMPRESSION SPRING 4341FCT
51 272244-4 17 LEVER FOR 4341FCT
52 268063-4 PLUG FOR 4 4341FCT
53 153334-1 BLADE COMPLETE GUIDE TO 4341FCT
54 252171-1 NUT PANEL M 5-8 FOR 4341FCT
55 421816-4 PARA POWDER FOR BLADE 4341FCT
56 153337-5 GEAR BOX FOR 4341FCT
57 210005-4 BALL BEARING 608 DDW
58 241881-5 FAN 52 PER 6408
59 266052-3 SCREW PT 4PER60
60 417838-0 DEFLECTOR FOR 4341FCT
61 593508-6 STATOR FOR 4340CT
62 517398-3 ARMATURE FOR 4341FCT
63 191962-4 CHARCOALS CB-419 (406.407) 6408
64 643936-6 BRUSH 8450
66 863664-9 LABEL MOD. 4350CT
68 419886-5 HOUSING FOR MOTOR 4350CT
69 259039-2 6 FOR LOCKING 9566CV
70 688117-5 MAGNETIC COMPASS FOR GD0800C
71 267756-0 WAVY WASHER FOR BO6040
72 421494-0 RUBBER 19 PER 9521NB
73 211021-9 BEARING 607LLB
74 681636-0 INSULATING WASHER
75 232208-0 SPRING FLAT FOR 4341FCT
76 922226-3 SCREW M 5 x 18 FOR 4341FCT
77 345237-5 SHAPED PLATE FOR 4341FCT
78 317565-8 BASE 4341FCT
79 912107-9 SCREW M4 x 8
80 345238-3 BASE PLATE FOR 4341FCT
