Makita Spare Parts for Circular Saw DHS710Z
€4.68
Tax included
Makita Spare Parts for Circular Saw DHS710Z
We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Circular Saw DHS710Z.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Circular Saw DHS710Z
We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Circular Saw DHS710Z.
In the following table, look for the model of the Circular Saw and the respective parts of the code.
| CIRCOLAR SAW DHS710Z | ||
| # | Part Num. | Description |
| 1 | 266326-2 | SCREW 4x18 X MT601 |
| 2 | 454697-1 | BACK COVER |
| 3 | 643829-7 | PLUG BRUSH HOLDER BSS611R |
| 4 | 194928-3 | CHARCOALS CB-442 |
| 6 | 266326-2 | SCREW 4x18 X MT601 |
| 7 | 911258-5 | SCREW M5x35 4101R |
| 8 | 454693-9 | HOUSING MOTOR |
| 9 | 644503-0 | BRUSH HOLDER |
| 10 | 644504-8 | BRUSH HOLDER |
| 11 | 231469-9 | SPRING 4 X 6811DW |
| 12 | 419664-3 | LEVER BCS550R |
| 13 | 231469-9 | SPRING 4 X 6811DW |
| 14 | 650730-9 | SWITCH TG72BD-6 |
| 15 | 419665-1 | LEVER SWITCH BCS550R |
| 16 | 187768-6 | HANDLE |
| 17 | 620305-8 | REGULATOR |
| 18 | 632B66-0 | CABLE |
| 19 | 643899-6 | TERMINAL BATTERY |
| 20 | 688163-8 | FILTER LINE |
| 22 | 638571-3 | STATOR MAGNET PERMAN.BSS61 |
| 23 | 266292-3 | SCREW 4 X 65 X BJR240 |
| 24 | 454696-3 | BAFFLE |
| 25 | 688172-7 | FILTER LINE |
| 26 | 257349-1 | SOCKETS 12 |
| 27 | 942151-2 | WASHER 6 4101R |
| 28 | 210017-7 | BEARING 607DDW |
| 29 | 519332-9 | ARMATURE |
| 30 | 240045-8 | FAN 55 X AH3655 |
| 31 | 210059-1 | BEARING 6000 HR2010 |
| 32 | 344681-3 | LOCKING SHAFT X 5621RDW |
| 33 | 233117-6 | SPRING COMP. 6 X GA7010C |
| 34 | 911258-5 | SCREW M5x35 4101R |
| 36 | 961052-5 | RETAINING RING S12 |
| 37 | 911223-4 | HEAD SCREW CILIND. M5X16 |
| 38 | 453285-1 | PIPE INTAKE |
| 39 | 142365-5 | HEADSET DISC |
| 40 | 265594-4 | SCREW M6x18 |
| 41 | 266229-0 | SCREW M 5X8 X KP312S |
| 42 | 262552-1 | SOCKETS RUBBER X HS6101 |
| 43 | 251247-1 | SCREW M6X20 |
| 44 | 213512-6 | SEAL 39 XM / HK1800 |
| 45 | 210028-2 | BEARING 606ZZ |
| 46 | 227786-3 | GEAR 49 |
| 47 | 326357-4 | SPINDLE |
| 48 | 319088-2 | BEARING BOX |
| 49 | 911233-1 | HEAD SCREW M5X20 3600H |
| 50 | 211129-9 | BALL BEARING NSK 6201DD |
| 51 | 285852-2 | RETAINING BEARING 19-33 |
| 52 | 231877-4 | SPRING TENSION 4 |
| 53 | 319072-7 | PROTECTION CAP |
| 54 | 272258-3 | LEVER 37 |
| 55 | 265178-8 | SCREW M4x16 FOR BTP130 / 140 |
| 56 | 961155-5 | RETAINING RING S38 |
| 58 | 224473-5 | INTERNAL FLANGE 35 |
| 59 | 224409-4 | EXTERNAL FLANGE 35 BSS611R |
| 60 | 266925-0 | SCREW M6x18 |
| 62 | 257982-9 | RING RETAINING X HS6101 |
| 63 | 272279-5 | LEVER |
| 64 | 264096-7 | NUT M6 |
| 65 | 267100-1 | WASHER FLEXIBLE X 6201DW |
| 66 | 257669-3 | SOCKETS 6 X HS6101 |
| 67 | 267100-1 | WASHER FLEXIBLE X 6201DW |
| 68 | 141312-3 | DEPTH DRIVING ' |
| 69 | 251919-8 | SCREW M6X20 |
| 70 | 165670-3 | DRIVING BACK X HS6101 |
| 71 | 922137-2 | SCREW ESAG. INC. 4X20 |
| 72 | 256480-0 | PIN 6-7 BSS611R |
| 73 | 252126-6 | NUT M4-7 X BHS630 |
| 74 | 252103-8 | NUT X JR3020 |
| 75 | 345590-9 | DRIVING ANGLE BHS630 |
| 76 | 256480-0 | PIN 6-7 BSS611R |
| 77 | 318823-5 | LATCH X HS6101 |
| 78 | 213977-2 | RING 7 X GA5010 |
| 79 | 266734-7 | SCREW |
| 80 | 265571-6 | SCREW M6x10 BHS630 |
| 81 | 961012-7 | RETAINING RING E6 |
| 82 | 453165-1 | LEVER LOCK BHS630 |
| 83 | 233596-8 | SPRING TORSION 11 BHS630 |
| 84 | 911203-0 | SCREW M5X8 X 4101R |
| 85 | 453286-9 | GRADUATED SCALE |
| 86 | 257982-9 | RING RETAINING X HS6101 |
| 87 | 272272-9 | LEVER 45 X HS6101 |
| 88 | 266735-5 | SCREW M6X20 |
| 89 | 941151-9 | WASHER 6 X HM1303 |
| 90 | 266208-8 | SCREW M6 X 8 X LS0714FL |
| 91 | 266208-8 | SCREW M6 X 8 X LS0714FL |
| 92 | 266208-8 | SCREW M6 X 8 X LS0714FL |
| 93 | 318819-6 | BASE |
| 94 | 266208-8 | SCREW M6 X 8 X LS0714FL |
| 95 | 941151-9 | WASHER 6 X HM1303 |
| 96 | 252631-3 | BUTTERFLY M6 X N500 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
