Makita Spare Parts for Percussion Drill 8419B.2

€49.69
Tax included

Makita Spare Parts for Percussion Drill 8419B.2

Makita original spare parts, sourced from the manufacturer, at the Lowest price on the web, for to Make Maintenance or Repair Broken parts for Percussion Drill 2 Speed 19 MM - 8419B.2.

- 2 gears
- Gears completely in steel, cast aluminum gearbox
ITEM CODE: 192877-8
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Percussion Drill 8419B.2

Makita original spare parts, sourced from the manufacturer, at the Lowest price on the web, for to Make Maintenance or Repair Broken parts for Percussion Drill 2 Speed 19 MM - 8419B.2.

In the following table, look for the model of Drill and the respective parts of the code.
Makita 8419B.2

PERCUSSION DRILL 2 SPEED 19 MM - 8419B.2
# Part Num. Description
2 192877-8 DRILL CHUCK S13
3 962151-6 RETAINING RING R-32
4 213301-9 DUST SEAL 20
5 211236-8 BALL BEARING 6002DDW X 5705R
6 323679-3 CHANGE RING 8419B-2/HP201
7 213458-6 O RING 34 HM1110/1111/AN510
8 223029-1 CAM A X 8419B-2
9 223030-6 CAM B X 8419B-2
10 159690-7 GEAR HOUSING 8419B
11 253798-0 FLAT WASHER 13 XM/HP2010N
12 961016-9 RETAINING RING E10
13 226038-9 GEAR 39-49
14 210025-8 BALL BEARING X 4324
15 263002-9 RUBBER PIN 4 GA7050/9050/5021
16 226039-7 GEAR 9-19-41
17 210025-8 BALL BEARING X 4324
18 263002-9 RUBBER PIN 4 GA7050/9050/5021
19 156441-9 GEAR HOUSING COVER 8419B-2
20 152135-4 SHIFTER ROD /8419B-2
21 231249-3 SPRING 5 8419B2/HP2010/N
22 411475-2 CHANGE LEVER /8419B-2
23 265029-5 SCREW M.4 8419B-2/HP2010/N
24 210005-4 BALL BEARING 608 DDW
27 515098-9 ARMATURE X 8419B-2
29 411456-6 BAFFLE PLATE
30 525088-4 FIELD X 8419B-2
31 681614-0 INSULATION WASHER /6807/HP2033/19
32 210025-8 BALL BEARING X 4324
33 263002-9 RUBBER PIN 4 GA7050/9050/5021/4107RH/6807/GA9020/
34 253192-6 FLAT WASHER 14
37 931102-0 HEX NUT M4 /DBN500/BUR181/BUM168
38 156953-2 MOTOR HOUSING /8419B-2
39 911266-6 P.H. SCREW M5X45/DLS713/MT362
40 181026-2 CARBON BRUSH SET CB-55
41 651204-3 SWITCH SGEL115CDY
42 643551-6 BRUSH HOLDER 002 /6300T/8419B
43 911124-6 SCREW M4X14X HM1301
44 911151-3 P.H. SCREW M4X28
45 411455-8 HANDLE COVER /8419B-2
47 645253-0 NOISE SUPPRESSOR /HR2641/HR2450/H
48 685725-3 SPONGE SHEET X UH3000
49 911133-5 SCREW M4X18
50 687001-1 STRAIN RELIEF /4107RH
51 682504-0 CORD GUARD 10-85 /6016/RT0700C/PJ
