Makita Spare Parts for Reciprocating Saw JR3070CT
We are Dealers of MAKITA original spare parts at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Reciprocating Saw JR3070CT.
In the following table, look for the model of the Reciprocating Saw and the respective parts of the code.
| Reciprocating Saw JR3070CT | ||
| # | Part Num. | Description |
| 1 | 165406-0 | SHOE JR3070CT |
| 2 | 421904-7 | INSULATION COVER JR3070CT |
| 3 | 424147-0 | PROTECTOR |
| 4 | 257952-8 | RETAINING RING 18 BJR181SF |
| 5 | 310285-3 | SLEEVE HOLDER LAMA X JR3050T |
| 6 | 268094-3 | PIN 3 X BJR240 |
| 7 | 331720-8 | SLEEVE GUIDE BJR181SF |
| 8 | 417791-0 | HOLDER GUIDE X BJR240 |
| 9 | 418311-3 | SLEEVE X JR3050T |
| 10 | 345214-7 | PLATE X BJR240 |
| 11 | 233025-1 | SPRING 2 X 6702DW |
| 12 | 231687-9 | SPRING TWIST 17 X JR3060T |
| 13 | 257742-9 | SLEEVE 14 X JR3060T |
| 14 | 213174-0 | RING 14 JR3030 |
| 15 | 911225-0 | SCREW M5X16 X JR180D |
| 16 | 418806-6 | CAP BUTTON LOCK JR3050T |
| 17 | 961012-7 | RETAINING RING E6 |
| 18 | 154551-6 | GEAR HOUSING COVER JR3060T |
| 19 | 961012-7 | RETAINING RING E6 |
| 20 | 154502-9 | BUSHE HOLDER JR3060T |
| 21 | 233038-2 | COMPRESSION SPRING 5 X JR3060T |
| 22 | 423343-7 | O-RING PLATE X JR3060T |
| 23 | 214170-1 | BEARING 14A X JR3060T |
| 24 | 168410-8 | SLIDER X JR3060T |
| 25 | 345487-2 | COVER SUP. BRONZ. JR3060T |
| 26 | 317842-8 | GEAR BOX X JR3060T |
| 27 | 154547-7 | BEARING X JR3060T |
| 28 | 345486-4 | PLATE B X JR3060T |
| 29 | 911225-0 | SCREW M5X16 X JR180D |
| 30 | 265530-0 | SCREW M5 X 8 X JR3060T |
| 32 | 911225-0 | SCREW M5X16 X JR180D |
| 33 | 317844-4 | BEARING BOX X JR3060T |
| 34 | 211131-2 | BALL BEARING 6001DD |
| 36 | 213726-7 | RING 62 X JR3060T |
| 37 | 154549-3 | TORQUE X JR3060T |
| 38 | 266373-3 | 5x35 SCREW FOR GA9020 |
| 39 | 265165-7 | SCREW M6X16 FOR BJR181SF |
| 40 | 345479-1 | GUIDE SHOE X JR3050T |
| 41 | 232222-6 | SPRING FLAT B X JR3050T |
| 42 | 911225-0 | SCREW M5X16 X JR180D |
| 43 | 345485-6 | PLATE X JR3060T |
| 44 | 265531-8 | SCREW M 6 X 14 X JR3060T |
| 45 | 154545-1 | ECCENTRIC X JR3060T |
| 46 | 257265-7 | RING 21 X JR3070CT |
| 47 | 313121-2 | COUNTER WEIGHT X JR3070CT |
| 48 | 154546-9 | BASE ECCENTRIC X JR3060T |
| 49 | 345489-8 | PLATE GUIDE X JR3070CT |
| 50 | 211251-2 | BEARING 6003LLB X DA6301 |
| 51 | 265148-7 | SCREW M 5 X 14 X JR3050T |
| 52 | 212957-5 | NEEDLE BEARING 710 JR3060T |
| 54 | 418991-5 | STOP X JR3060T |
| 55 | 231309-1 | SPRING COMPRESSION 5 |
| 56 | 272247-8 | LEVER 20 X JR3060T |
| 57 | 213021-5 | RETAINING RING 5 X LS1013 |
| 58 | 213021-5 | RETAINING RING 5 X LS1013 |
| 59 | 413095-8 | PLATE C X JR3060T |
| 60 | 421899-4 | O-RING X JR3060T |
| 61 | 268012-1 | NEW PIN JR3020 |
| 62 | 162236-0 | BUTTON LOCK X JR3050T |
| 63 | 232221-8 | SPRING FLAT A X JR3050T |
| 64 | 256158-5 | PIN 3 X T221DW |
| 65 | 233345-3 | SPRING COMPRES. 6 X BJR2240 |
| 66 | 256492-3 | PIN 5 X JR3060T |
| 67 | 961052-5 | RETAINING RING S12 |
| 68 | 253744-3 | HARD WASHER 12 24B / 12N / 14 |
| 69 | 211131-2 | BALL BEARING 6001DD |
| 70 | 253744-3 | HARD WASHER 12 24B / 12N / 14 |
| 71 | 285719-4 | RETAINING BEARING JR3060T |
| 72 | 241863-7 | FAN 70 |
| 73 | 513603-6 | ARMATURE JR3070CT |
| 74 | 681650-6 | INSULATOR X HR4000C |
| 75 | 210029-0 | BALL BEARING 608ZZ X MT601 |
| 76 | 266466-6 | SCREW 5x45 MT430 |
| 77 | 418817-1 | BAFFLE X JR3060T |
| 78 | 525718-7 | FIELD JR3070CT |
| 79 | 154498-4 | MOTOR HOUSING JR3050T |
| 80 | 650222-8 | SWITCH TG71ARS-1 JR3060T |
| 81 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 82 | 183933-5 | HANDLE SET JR3070CT |
| 84 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 85 | 687052-4 | STRAIN RELIEF 6408 |
| 86 | 682573-1 | CORD GUARD 10 X GA9010C |
| 87 | 645253-0 | CAPACITOR X 6408 |
| 88 | 645006-7 | CAPACITOR X LS1013 |
| 89 | 646049-2 | CHOKE COIL JR3000VT |
| 92 | 631651-4 | CONTROLLER X JR3070CT |
| 93 | 213261-5 | O-RING 17X9207SPC |
| 94 | 418905-4 | DIAL JR3070CT |
| 95 | 418518-1 | SLEEVE X GA9010C |
| 96 | 421448-7 | RUBBER BAND JR3020 |
| 98 | 191963-2 | CARBON BRUSCHE SET CB-303 |
| 99 | 643750-0 | BRUSH HOLDER PLUG |
| 100 | 125524-6 | GEAR HOUSING COVER ASSY JR3060 / 3070 |
