Makita Spare Parts for Cordless Hammer DHR400PT2U
€141.97
Tax included
Makita Spare Parts for Cordless Hammer DHR400PT2U
We have the original Spares MAKITA for Cordless Hammer DHR400PT2U, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Cordless Hammer DHR400PT2U. All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Cordless Hammer DHR400PT2U
We have the original Spares MAKITA for Cordless Hammer DHR400PT2U, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
Fix Your Cordless Hammer DHR400PT2U. All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.
In the following table, look for the model of Cordless Hammer and the respective parts of the code.
| Cordless Hammer DHR400PT2U | ||
| 1 | 286292-7 | FRONT CAP |
| 2 | 233948-3 | RING 25 X HR5201C |
| 3 | 257308-5 | RING 28 X HM1101C |
| 4 | 454330-5 | CHUCK COVER |
| 5 | 262167-4 | RUBBER RING 30 |
| 6 | 326272-2 | CHUCK RING |
| 7 | 454331-3 | RELEASE COVER |
| 8 | 346670-4 | SPRING GUIDE |
| 9 | 234288-2 | COMPRESSION SPRING 46 |
| 10 | 346670-4 | SPRING GUIDE |
| 11 | 213615-6 | RING 46 X HR3000C |
| 12 | 922351-0 | SCREW M6 X 30 X HM1100C |
| 13 | 141956-9 | BARREL |
| 14 | 454337-1 | LOCK SLEEVE |
| 15 | 234290-5 | ELASTIC RING |
| 16 | 213707-1 | GASKET 65 X HR1800 |
| 17 | 267469-3 | WASHER 32 |
| 18 | 262168-2 | RUBBER RING 32 |
| 19 | 267469-3 | WASHER 32 |
| 20 | 310257-8 | TOOL RETAINER X HR3540C |
| 21 | 326268-3 | TOOL HOLDER |
| 22 | 213317-4 | RING 20 X HR4000C |
| 23 | 213392-0 | RUBBER RING 25 X HR4000C |
| 24 | 213317-4 | RING 20 X HR4000C |
| 25 | 213392-0 | RUBBER RING 25 X HR4000C |
| 26 | 326269-1 | IMPACT BOLT |
| 27 | 326274-8 | RING 17 |
| 28 | 262166-6 | RUBBER RING 18 |
| 29 | 454347-8 | SLIDE SLEEVE |
| 30 | 326270-6 | STRIKER |
| 31 | 213695-2 | RING 22 |
| 32 | 234289-0 | COMPRESSION SPRING 33 |
| 33 | 346673-8 | GUIDE RING |
| 34 | 256548-2 | PIN 6 |
| 35 | 346671-2 | CONNECTION PLATE |
| 36 | 313255-1 | SLEEVE |
| 37 | 257991-8 | RERAINING RING WR 32.5 |
| 38 | 257340-9 | RING 33 |
| 39 | 267470-8 | WASHER 33 |
| 40 | 234287-4 | COMPRESSION SPRING 34 |
| 41 | 267470-8 | WASHER 33 |
| 42 | 332063-1 | CYLINDER 28.5 |
| 43 | 257991-8 | RETAINING RING WR 32.5 |
| 44 | 213406-5 | GASKET 30 58NB / SB / HM1200 |
| 45 | 256197-5 | PIN 4 X HR4000C |
| 46 | 419004-5 | PISTON X HR4001C / HR4010C |
| 47 | 213379-2 | RING 21 X AN621 |
| 48 | 213695-2 | RING 22 |
| 49 | 454317-7 | ROD |
| 50 | 424560-2 | FRONT COVER |
| 51 | 141957-7 | COVER |
| 52 | 227613-4 | GEAR 26 |
| 53 | 454342-8 | SPRING GUIDE |
| 54 | 234286-6 | COMPRESSION SPRING 11 |
| 55 | 326273-0 | COUNTER WEIGHT |
| 56 | 234286-6 | COMPRESSION SPRING 11 |
| 57 | 213325-5 | RING 19 |
| 58 | 142289-5 | HOLDER COMPLETE |
| 59 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 60 | 454326-6 | CHANGE LEVER |
| 61 | 319652-9 | HOUSING ROD COVER |
| 62 | 458098-5 | SPRING HOLDER |
| 63 | 911128-8 | SCREW M4X16 X HR4000C |
| 64 | 234282-4 | COMPRESSION SPRING 12 |
| 65 | 454345-2 | LEVER |
| 66 | 213262-3 | GASKET 18 4100R |
| 67 | 424556-3 | FILTER COVER |
| 68 | 443182-9 | FILTER |
| 69 | 454319-3 | HOUSING ROD COVER |
| 70 | 911128-8 | SCREW M4X16 X HR4000C |
| 71 | 424559-7 | SEAL RING B |
| 72 | 232280-2 | PLATE SPRING |
| 73 | 458100-4 | CHANGE PLATE SUPPORT |
| 74 | 911511-9 | SCREW M4 X 10 X HR4001C / HR4010C |
| 75 | 266041-8 | SCREW PT 5X25 |
| 76 | 233603-7 | TORSION SPRING 7 |
| 77 | 454338-9 | GUIDE |
| 78 | 141953-5 | HOUSING ROD |
| 79 | 126290-8 | TORQUE LIMITER |
| 80 | 254239-9 | 4 X HR3000C KEY |
| 81 | 227612-6 | GEAR 7 |
| 82 | 211232-6 | BEARING X HK0500 |
| 83 | 141959-3 | TORQUE LIMITER |
| 84 | 324727-1 | WASHER B |
| 85 | 210005-4 | BALL BEARING 608 DDW |
| 86 | 253215-0 | FLAT WASHER 8 6510PBL / LVR |
| 87 | 961004-6 | RETAINING RING S8 |
| 88 | 326271-4 | ECCENTRIC SHAFT |
| 89 | 210183-0 | BALL BEARING 6004LLU |
| 90 | 961060-6 | RETAINING RING S20 |
| 91 | 227772-4 | GEAR 37 |
| 93 | 253180-3 | FLAT WASHER 10 X 6221DW |
| 94 | 424558-9 | SEAL RING A |
| 95 | 141955-1 | GEAR HOUSING |
| 96 | 213231-4 | OIL SEAL X HR4500C |
| 97 | 331596-3 | SLEEVE 12 X HR4500C |
| 98 | 211137-0 | BALL BEARING 6201LLU X HM0860C |
| 99 | 253744-3 | FLAT WASHER 12 24B / 12N / 14 |
| 100 | 519492-7 | ARMATURE CPL |
| 101 | 210005-4 | BALL BEARING 608 DDW |
| 103 | 265999-8 | SCREW 4X25 |
| 104 | 458099-3 | DEFLECTOR |
| 105 | 629335-6 | STATOR |
| 106 | 632L39-3 | CLAMP |
| 107 | 652031-1 | SCREW M3x6 |
| 108 | 620795-5 | REGULATOR B |
| 109 | 687B69-9 | FLANGE |
| 110 | 266490-9 | SCREW 2X6 |
| 111 | 454348-6 | GUARD 40 |
| 112 | 265999-8 | SCREW 4X25 |
| 113 | 458051-1 | MOTOR HOUSING |
| 114 | 347299-9 | GUIDE PLATE |
| 115 | 922111-0 | SCREW 4X10 |
| 116 | 256380-4 | PIN 4-6 |
| 117 | 422241-2 | RING |
| 118 | 620797-1 | ACCELEROMETER CIRCUIT |
| 119 | 251599-0 | SCREW M4x8 |
| 120 | 620796-3 | DIAL CIRCUIT |
| 121 | 620794-7 | CONTROLLER |
| 122 | 458054-5 | CONTROLLER COVER |
| 123 | 265999-8 | SCREW 4X25 |
| 125 | 232411-3 | COMPRESSION SPRING 8 |
| 126 | 183J10-3 | HANDLE CPL |
| 127 | 265999-8 | SCREW 4X25 |
| 128 | 458096-9 | LEVER BLOCK |
| 129 | 458097-7 | SWITCH LEVER |
| 130 | 651083-9 | C3XA-1PSPM SWITCH |
| 131 | 232418-9 | COMPRESSION SPRING 5 |
| 132 | 632L47-4 | CONNECTOR UNIT |
| 133 | 620549-0 | CIRCUIT LED |
| 135 | 644809-6 | TERMINAL X BLS713-BHP451 |
| 136 | 346783-1 | PLATE |
| 137 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 139 | 213218-6 | RING 16 X HR2800 |
| 141 | 183J86-0 | COVER |
| 142 | 232280-2 | PLATE SPRING |
