Makita Spare Parts for Angle Grinder GA4540C
€4.99
Tax included
Makita Spare Parts for Angle Grinder GA4540C
Makita original spare parts for to replace broken parts for to fix Angle Grinder GA4540C.Fix Your Angle Grinder. All Spares are Ready For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Angle Grinder GA4540C
Fix Your Angle Grinder GA4540C. All Spares are Ready For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder GA4540C | ||
| # | Part Num. | Description |
| 1 | 168705-9 | GEAR BOX FOR GA |
| 2 | 252186-8 | NUT M6 X 9554NB |
| 3 | 253077-6 | ROND.P. 6 4300 / 01BV |
| 4 | 227591-8 | GEAR FOR 10 GA |
| 5 | 211142-7 | BEARING 6001LLB X GD0800C |
| 6 | 318835-8 | COVER GEAR BOX |
| 10 | 253084-9 | ROND.P.12 8419B / 5016NB |
| 11 | 240134-9 | FAN FOR 60 GA |
| 12 | 515373-3 | ARMATURE |
| 13 | 681656-4 | INSULATOR X GD0810C |
| 14 | 253823-7 | ROND. FLAT 7 X JS1600 |
| 15 | 210027-4 | BEARING 627DDW X 9561CV |
| 16 | 421738-8 | RING LABYRINTH 22 X 9561CV |
| 17 | 267756-0 | WAVY WASHER X BO6040 |
| 18 | 688117-5 | MAGNETIC COMPASS X GD0800C |
| 19 | 259039-2 | LOCKING 6 X 9566CV |
| 22 | 453367-9 | BAFFLE |
| 23 | 266258-3 | SCREW 4 X 70 X 9564 |
| 24 | 344871-8 | RETAINING X GD0800C |
| 25 | 626653-3 | STATOR 220-240V |
| 27 | 191978-9 | CARBON BRUSHES CB 318 (EX 310) |
| 28 | 266007-8 | SCREW M3 X10 HP2030 |
| 29 | 643769-9 | BRUSHE HOLDER |
| 30 | 453366-1 | HOUSING MOTOR |
| 31 | 266326-2 | SCREW 4x18 X MT601 |
| 32 | 687169-3 | STRAIN RELIEF HP1620 |
| 33 | 638947-4 | SWITCH SUPPORT |
| 35 | 682559-5 | CORD GUARD X 6822 |
| 36 | 266326-2 | SCREW 4x18 X MT601 |
| 38 | 453365-3 | BACK COVER C |
| 39 | 620127-6 | CONTROLLER |
| 40 | 651418-4 | SWITCH ST115A-40 X 9541 |
| 42 | 233071-4 | SPRING COMPRESSION 4 X 9541 |
| 43 | 453847-5 | LEVER SWITCH |
| 44 | 453368-7 | KEY SWITCH |
| 46 | 453369-5 | BUTTON |
| 47 | 234057-1 | SPRING COMPRRESSIONE 6 GA5021C |
| 48 | 266361-0 | SCREW 4 X 30 X 9554NB |
| 49 | 213032-0 | RING 4 X GA4530 |
| 50 | 256535-1 | PLUG FOR 6 GA |
| 51 | 263002-9 | RUBBER PLUG 4 |
| 52 | 210026-6 | BALL BEARING 696ZZ |
| 53 | 961005-4 | RETAINING RING S9 |
| 54 | 253180-3 | FLAT WASHER 10 X 6221DW |
| 55 | 310508-9 | COMPASS FOR GA |
| 56 | 346556-2 | C PLATE FOR GA |
| 57 | 227592-6 | GEAR FOR 38 GA |
| 58 | 313228-4 | JUNCTION FOR GA |
| 59 | 210302-8 | BEARING 6903ZZ FOR GA |
| 60 | 253744-3 | ROND.PIANA 12 24B / 12N / 14 |
| 61 | 263002-9 | RUBBER PLUG 4 |
| 62 | 213641-5 | RING FOR 51 GA |
| 63 | 318837-4 | BEARING BOX |
| 64 | 265490-6 | SCREW M4 X 16 X 9561CV |
| 65 | 211129-9 | BALL BEARING NSK 6201DD |
| 66 | 267279-8 | FLAT WASHER 21 X HR2450FT |
| 67 | 443124-3 | FELT RING 17 GD0600 |
| 68 | 285854-8 | RETAINING BEARING 20-33 |
| 70 | 326130-2 | SPINDLE FOR GA |
| 72 | 123144-0 | HEADPHONES DISCO GA SERIES |
| 73 | 224415-9 | RECIEVE WASHER 42 GA95010 |
| 74 | 224554-5 | CLAMP WASHER 14-45 X 9541 |
