Makita Spare Parts for Planer N1923B
€37.19
Tax included
Makita Spare Parts for Planer N1923B
MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Power Planer N1923B - 82 mm.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Planer N1923B
MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Power Planer N1923B - 82 mm.
In the following table, look for the model of Power Planer and the respective parts of the code.
| Planer Makita N1923B | ||
| 1 | 911546-0 | PAN HEAD SCREW M4X25 |
| 2 | 411019-8 | BELT COVER |
| 3 | 225071-8 | BELT 4-241 |
| 4 | 222125-2 | PULLEY 4-20L |
| 5 | 222126-0 | PULLEY 4-37 |
| 6 | 911136-9 | HEAD SCREW CILIND. M4x20 |
| 7 | 152198-0 | BRACKET COMPLETE |
| 8 | 263002-9 | PIN RUBBER 4 |
| 9 | 211062-5 | BEARING 6000 |
| 10 | 161045-4 | ROLL OUT |
| 11 | 961003-8 | RETAINING RING S7 |
| 12 | 210025-8 | BEARING X 4324 |
| 13 | 285637-6 | ARMATURE BEARING. RETAINER 7-21 |
| 14 | 241510-0 | FAN X 1902 |
| 15 | 511938-9 | ARMATURE |
| 16 | 911586-8 | SCREW M4x60 |
| 17 | 911153-9 | SCREW M4X28 |
| 18 | 411304-9 | COVER HANDLE |
| 19 | 645208-5 | CAPACITOR |
| 20 | 651239-4 | SWITCH |
| 21 | 251609-3 | BOLT M6X17 |
| 22 | 187676-1 | PLATE ROLL |
| 23 | 251246-3 | HEAD SCREW CILIND. M4x5 |
| 24 | 342430-2 | PLATE KNIFE |
| 25 | 263002-9 | PIN RUBBER 4 |
| 26 | 211061-7 | BALL BEARING 6000DD |
| 27 | 961015-1 | RING RETAINING E9 |
| 29 | 271231-0 | KNOB ADJUSTMENT |
| 30 | 681614-0 | INSULATION WASHER |
| 31 | 211028-5 | BALL BEARING 627 |
| 32 | 263014-2 | PIN RUBBER 4 |
| 33 | 599322-8 | STATOR |
| 34 | 411306-5 | PLATE |
| 35 | 911128-8 | SCREW M4x16 |
| 36 | 911133-5 | SCREW M4X18 |
| 38 | 682504-0 | CABLE SLEEVE 10/85 |
| 39 | 687001-1 | CLAMP cable tie |
| 40 | 156592-8 | HOUSING MOTOR |
| 41 | 941251-5 | FLAT WASHER 10 |
| 42 | 251812-6 | SCREW M5x10 |
| 43 | 342390-8 | DEPTH GUIDE |
| 44 | 941101-4 | FLAT WASHER 5 |
| 45 | 942101-7 | SPRING WASHER 5 |
| 46 | 924206-5 | BUTTERFLY SCREW M5x10 |
| 47 | 251228-5 | SCREW M5 |
| 50 | 643550-8 | PLUG BRUSH |
| 51 | 181021-2 | CARBON BRUSHE SET CB-51 |
| 52 | 421007-7 | BASE RUBBER |
| 53 | 411305-7 | SIDE COVER |
| 54 | 912117-6 | SCREW M4X12 |
| 55 | 164372-8 | HOLDER ROLLER |
| 56 | 911226-8 | HEAD SCREW CILIND. M5X18 |
| 57 | 341342-6 | COVER ROLLER |
| 58 | 231504-3 | SPRING 10 |
| 59 | 951051-5 | PIN FLEXIBLE 3/8 |
| 60 | 411650-0 | COVER CHIPS |
| 61 | 911128-8 | SCREW M4x16 |
| 62 | 911226-8 | HEAD SCREW CILIND. M5X18 |
| 63 | 312023-9 | BASE REAR |
| 64 | 231004-3 | SPRING 18 |
| 65 | 316587-5 | UP FRONT |
| 66 | 654018-9 | RING TERMINAL 72 |
| 500 | 122230-4 | DUST BAG |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
